MORTEX E30 Series User's Information Manual

USERS INFORMATION MANUAL
DOWNFLOW
SINGLE AND TWO STAGE
ELECTRIC FURNACE
MODELS: E30 SERIES
1 - General
2 - Safety
3 - Owners Information & Seasonal Information
1 - Safety
2 - Furnace Maintenance
3 - Furnace Controls
4 - Sequence of Operation
1 - Circuit Breaker Locations
2 - Return Air Louvered Door Air Filter Location
3 - Return Air Louvered Door Air Filters
4 - Coil Cabinet Top Pleated Filter Location
5 - Coil Hanging Filter Location
6 - Replacing the Coil Cabinet Front Door
7 - Control Box Cover
8 - Blower Assembly and Mounting Screw Location
1 - Constant Torque Motor Terminal Connections
2 - Blower Performance 1/3 HP - Constant Torque Motor
3 - Blower Performance 1/2 HP - Constant Torque Motor
4 - Blower Performance 1/2 HP - Constant Torque Motor
5 - Blower Performance 3/4 HP - Constant Torque Motor
Contact us by mail: Manufactured and Distributed by
SECTION I: GENERAL
The following list includes important facts and information regarding
the electric furnace and its inclusions.
1. Furnace is rated at 240 volts AC at 60 Hertz
2. Furnace is the same cabinet size for all models
3. All furnaces are equipped with a blower for A/C or Heat Pump
operation.
4. This furnace is designed for downflow and horizontal
application.
5. This furnace must not be operated without furnace door
installed.
NOTE: This furnace and its components listed on the A/C and Heat
Pump equipment sticker were listed in combination as a system by
ETL for the United States.
BLOWER MOTOR SPEED TAP INFORMATION
The constant torque motor is designed with 5 speed taps. The speed
taps are designed to be used as shown below:
Tap 5 is used for HIGH SPEED Cooling operation.
Tap 4 is used for MED-HIGH SPEED Cooling or Heating operation.
Tap 3 is used for MEDIUM SPEED Cooling or Heating operation.
Tap 2 is used for MED-LOW SPEED Heating operation.
MORTEX PRODUCTS INC
LIST OF SECTIONS - USERS INFORMATION MANUAL
LIST OF SECTIONS - SERVICE AND MAINTENANCE MANUAL
LIST OF FIGURES
LIST OF TABLES
CONTACT INFORMATION
FORT WORTH, TX 76106
For Installation In:
1. Manufactured (Mobile) Home
3. Modular Homes & Buildings
1 4 - Start Up & Shutdown Instructions
2 5 - Owner Maintenance
3
7 5 - Trouble Shooting
8 6 - Blower Performance
9 7 - Accessories and Replacement Parts Lists
9 8 - Replacement Parts
3 9 - Component Locations
5 10 - Constant Torque Motor Terminal Locations
5 11 - Heater Contactor Terminal Designations
Blower Mounting Plate and Screw Locations
6 12 -
6 13 - Replacement Parts Drawing 1/3 HP Constant Torque Motor
6 14 - Replacement Parts Drawing 1/2 HP Constant Torque Motor
8 14 - Replacement Parts Drawing 3/4 HP Constant Torque Motor
8
11 6 - Accessory Parts List
12 7 - Replacement Parts List 1/3 HP - Constant Torque Motor
13 8 - Replacement Parts List 1/2 HP - Constant Torque Motor
14 9 - Replacement Parts List 3/4 HP - Constant Torque Motor
15
Mortex Products Inc.
501 Terminal Rd
Fort Worth, TX 76106
Tap 1 is used for LOW SPEED Constant Circulation operation
ONLY. This speed tap circulates around 200 CFM and is energized
by the "G" thermostat terminal. Tap 1 does not circulate enough air
to support the heating or cooling operation. If used for cooling the
evaporator coil will freeze up. If used for heating the limits will open
very quickly.
FIRE OR ELECTRICAL HAZARD
Failure to follow the safety warnings exactly could result in
serious injury, death, or property damage.
A fire or electrical hazard may result causing property
damage, personal injury or loss of life.
USERS MUST READ ALL INSTRUCTIONS IN THIS
MANUAL AND THIS MANUAL MUST BE SAVED FOR
FUTURE REFERENCE
2. Recreational Vehicle
4. Residential Homes
www.mortx.com
4
4
10
12
16
17
9
10
11
11
17
18
19
16
17
18
19
Page 1
