E2S D2xS2F Series Instruction Manual

INSTRUCTION MANUAL
D2xS2
Alarm Horn Sounder
Class I, Zone 2 & 22
1) Product Table
Unit Type Code
Input Voltage
D2xS2FDC024-A
D2xS2FAC230-A
D2xS2HDC024-A
D2xS2HAC230-A
*Max = Tone 4
†
Nom. = Tone 44
The table shows the input current taken by the various sounders.
The current levels shown above are for the 440Hz Continuous tone @ nominal input voltage.
Nominal current at nominal voltage.
Table 1: Electrical Ratings.
2) Warnings:
DO NOT OPEN WHEN AN EXPLOSIVE
ATMOSPHERE IS PRESENT
DO NOT OPEN WHEN ENERGISED
POTENTIAL ELECTROSTATIC CHARGING
HAZARD - CLEAN ONLY WITH A DAMP
CLOTH
Avertissement:
NE PAS OUVRIR UN PRESENCE
D'ATMOSPHERE EXPLOSIVE
NE PAS OUVRIR ENERGIE
DANGER POTENTIEL CHARGE
ÉLECTROSTATIQUE - NETTOYER
UNIQUEMENT AVEC UN CHIFFON HUMIDE
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. D252-00-001-IS
D2xS2F
Nominal Nominal
Current P2
12Vdc 289mA
24Vdc 324mA
48Vdc 195mA
115Vac 125mA
230Vac 78mA
12Vdc 289mA
24Vdc 324mA
48Vdc 195mA
115Vac 125mA
230Vac 78mA
Issue 1
D2xS2H
Nominal
Voltage Range
Current P3
356mA
740mA
391mA
282mA
100-240Vac 50/60Hz
167mA
356mA
740mA
391mA
282mA
100-240Vac 50/60Hz
167mA
3) Marking & Rating Information
3.1 UL Certification
All Sounders comply with the following standards:
UL 464A (Ed 1) – Audible Signal Appliances for General Signaling Use
CSA C22.2 No. 205-17 (Ed 3) –Signal Equipment
D2xS2-DC024-A Sounders also comply with the following standards:
UL 464 (Ed 10) – Audible Signaling Devices for Fire Alarm and
Signaling Systems, Including Accessories.
CAN/ULC-S525 (Ed 4) – Audible Signaling Devices for Fire Alarm and
Signaling Systems, Including Accessories.
See relevant sections further down.
The D2xS2 Alarm Horns comply with the following standards for
hazardous locations:
21-12-2023
Pressure Level dB(A)
Max* P2/P3
11.5-54Vdc
120/123
11.5-54Vdc
126/129
www.e2s.com Tel: +44 (0)208 743 8880
Sound
.†
Nom P2/P3
117/120
123/126
Sheet 1 of 7
