INSTRUCTION MANUAL
D1xC1 & D1xC2
Alarm Horn Sounder & Strobe
Class I, Zone 1, 2, 21 & 22
1) Product Table
Unit Type Code
D1xC1X05RDC024-A
D1xC1X05RAC115-A
D1xC1X05RAC230-A
D1xC1X10RDC024-A
D1xC1X10RAC115-A
D1xC1X10RAC230-A
D1xC1X05FDC024-A
D1xC1X05FAC115-A
D1xC1X05FAC230-A
D1xC1X10FDC024-A
D1xC1X10FAC115-A
D1xC1X10FAC230-A
D1XC2X05RDC024-A
D1xC2X05RAC115-A
D1xC2X05RAC230-A
D1XC2X05DC024-A
D1xC2X05FAC115-A
D1xC2X05FAC230-A
D1xC2X10RDC024-A
D1xC2X10RAC115-A
D1xC2X10RAC230-A
D1xC2X10FDC024-A
D1xC2X10FAC115-A
D1xC2X10FAC230-A
*Max = Tone 4
The table shows the input current taken by the various sounders.
The current levels shown above are for the 440Hz Continuous tone @ nominal input voltage.
Nominal current at nominal voltage.
Table 1: Electrical Ratings.
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. D190-00-301-IS
D1xC1-R & D1xC2-R
Nominal
Input Voltage
24Vdc
115Vac
230Vac
24Vdc
115Vac
230Vac
24Vdc
115Vac
230Vac
24Vdc
115Vac
230Vac
24Vdc
P2/P3: 647/1063mA
115Vac
P2/P3: 255/415mA
230Vac
P2/P3: 157/246mA
24Vdc
P2/P3: 647/1063mA
115Vac
P2/P3: 255/415mA
230Vac
P2/P3: 157/246mA
24Vdc
P2/P3: 997/1413mA
115Vac
P2/P3: 372/532mA
230Vac
P2/P3: 199/288mA
24Vdc
P2/P3: 997/1413mA
115Vac
P2/P3: 372/532mA
230Vac
P2/P3: 199/288mA
†
Nom. = Tone 44
Issue 2
D1xC1-F
Nominal
Voltage Range
Input Current
508mA
20-28Vdc
200mA
110-120Vac 50/60Hz
127mA
220-240Vac 50/60Hz
858mA
20-28Vdc
317mA
110-120Vac 50/60Hz
169mA
220-240Vac 50/60Hz
508mA
20-28Vdc
200mA
110-120Vac 50/60Hz
127mA
220-240Vac 50/60Hz
858mA
20-28Vdc
317mA
110-120Vac 50/60Hz
169mA
220-240Vac 50/60Hz
20-28Vdc
110-120Vac 50/60Hz
220-240Vac 50/60Hz
20-28Vdc
110-120Vac 50/60Hz
220-240Vac 50/60Hz
20-28Vdc
110-120Vac 50/60Hz
220-240Vac 50/60Hz
20-28Vdc
110-120Vac 50/60Hz
220-240Vac 50/60Hz
17-03-2022
D1xC2-F
Sound
Pressure Level dB(A)
.†
Max*
Nom
110
105
115
110
P2/P3
P2/P3
112/114
107/109
P2/P3
P2/P3
120/123
115/118
P2/P3
P2/P3
112/114
107/109
P2/P3
P2/P3
120/123
115/118
www.e2s.com
Tel: +44 (0)208 743 8880
Sheet 1 of 9
