E2S BE DCS110-L1D Series Instruction Manual

1) Introduction
The BExDCS110-L1D is a flameproof combined sounder /
LED beacon which is certified to meet the requirements of the
ATEX directive 94/9/EC and the IECEx Scheme. The
combined unit produces both loud audio warning signals and
visual warning signals that can be used in hazardous areas
where potentially flammable atmospheres may be present.
Thirty-two different first stage audio alarm sounds can be
selected by internal switches, and each one can be externally
changed to a second or third stage alarm sound (see tone
table on Page 5). The sounder produces output levels in the
110dB(A) range. The beacon section has nine different
selectable flash patterns including a steady ON state and can
also be remotely switched to a second and third flash pattern
(see flash pattern table on page 5). The unit can be used in
Zone 1 and Zone 2 areas with gases in groups IIA and IIB
and with Temperature Classifications of T1, T2, T3 and T4
and can also be used in Zone 21 and Zone 22 areas for
combustible dusts and has an IP rating of IP 67 and a surface
temperature rating of T115ºC (T100ºC at +55ºC).
2) Marking
All units have a rating label, which carries the following
important information:-
BExDCS110-L1D
Unit Type No.
Input Voltage: DC Units
AC Units
Codes: Ex d IIB T4 for Ta –50°C to +70ºC
Ex tD A21 IP6X T115°C based on max Ta of +70°C
KEMA 01ATEX2223X
Certificate No.
IECEx KEM 10.0025X
Epsilon x:
Equipment Group
and Category:
CE Marking:
Notified Body No.
"Warnings"
DO NOT OPEN WHEN AN EXPLOSIVE
GAS ATMOSPHERE IS PRESENT
COVER BOLTS CLASS A4-80
USE HEAT RESISTING CABLES AND
CABLE GLANDS (Rated 110ºC) AT
AMB. TEMPERATURES OVER 40ºC
Year of Construction /
Serial No.
3)
Type Approval Standards
The units have an EC Type examination certificate issued by
KEMA and have been approved to the following standards:-
_______________________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. IS 2469-P Issue C
INSTRUCTION MANUAL (ATEX / IECEx)
Flameproof Combined Sounder / LED Beacon
12V or 24V or 48V
230V or 115V
II 2G
0518
i.e. 10 / 1DCS52000001
23-04-10
BExDCS110-L1D
EN60079-0:2006 IEC60079-0:2004 (Ed4)
EN60079-1:2007 IEC60079-1:2007 (Ed6)
EN61241-0:2006 IEC61241-0:2004 (Ed1)
EN61241-1:2004 IEC60079-1:2004 (Ed1)
4)
Installation Requirements
The unit must be installed in accordance with the latest
issues of the relevant parts of the EN60079 specifications or
the equivalent IEC specifications – Selection, Installation and
maintenance of electrical apparatus for use in potentially
explosive atmospheres (other than mining applications or
explosive processing and manufacture):-
EN60079-14:2008
IEC60079-14:2007 (Ed4)
EN60079-10:2003
IEC60079-10:2008 (Ed1)
The installation of the unit must also be in accordance with
any local codes that may apply and should only be carried
out by a competent electrical engineer who has the
necessary training.
4)
Zones, Gas Group, Category and Temperature
Classification
The BExDCS110-L1D unit has been certified Ex d IIB T4 for
Ta –50°C to +70ºC for gas and Ex tD A21 IP6X T115ºC
based on max. Ta of +70ºC for dust. This means that the
units can be installed in locations with the following
conditions:-
Area Classification:
Zone 1
Zone 2
Gas Groupings:
Temperature Classification:
Ambient Temperature Range:
Sheet 1 of 6
Electrical Installations in Hazardous
Areas (other than mines)
Classification of Hazardous Areas
Explosive gas air mixture likely to occur in
normal operation.
Explosive gas air mixture not likely to occur,
and if it does, it will only exist for a short time.
Group IIA Propane
Group IIB Ethylene
o
T1 400 C
o
T2 300 C
o
T3 200 C
o
T4 135 C
-50°C to +70°C
sales@e-2-s.com Tel: +44 (0)208 743 8880
www.e-2-s.com Fax: +44 (0)208 740 4200
General Requirements
Flameproof Enclosure 'd'
Dust General
Requirements
Dust Enclosures tD
