- Page 1 Instruction Manual SEE995 © 2023 System Q Ltd ZipNVR.com...
-
Page 2: Table Of Contents
SEE995 Table of Contents Introduction SEE995 ..........................3 Tools & Handy Extras Connections & Dipswitches Dipswitch 4-In-1 Technology Mounting Eyeball ........................... 5 Motorised Lens OSD Menu 5MP OSD Menu Motorised ....................8 Key Menu Settings ......................10 Troubleshooting Camera Rebooting / Turning Off ................... 11 Poor Quality Images ..................... -
Page 3: Introduction
Index Introduction 1.1 SEE995 The SEE995 has a motorised lens so that you can set the zoom and focus from the DVR. With 4-in-1 technology design means you can set the output signal to either TVI, CVI, AHD or CVBS. -
Page 4: Connections & Dipswitches
SEE995 Connections & Dipswitches The camera has a 2.1mm socket which requires 12V DC, use a regulated power supply rated above the current draw of the camera. The camera is polarity sensitive so connections must be correctly made. The camera has a standard BNC connector for the 4-in-1 video output, the output can be changed to AHD, CVI or CVBS if required. -
Page 5: Mounting
Index Mounting 5.1 Eyeball A template is provided in the box for marking the hole positions for the fixing screws. © 2023 System Q Ltd ZipDVR.com... -
Page 6: Motorised Lens
SEE995 Motorised Lens To access the Motorised Lens via coaxitron:- 1. Click on the image in Live view 2. Click on the PTZ button at the bottom of the screen 3. Use Zoom + and - to zoom in and out, the camera should automatically focus... -
Page 7: Osd Menu
Index OSD Menu Access to the camera menu is by Coaxitron. For the ZIP DVRs, ZIP Coaxitron is set as default. To access the Cameras Menu via coaxitron:- 1. Click on the image in Live view 2. Click on the PTZ button at the bottom of the screen 3. -
Page 8: 5Mp Osd Menu Motorised
SEE995 7.1 5MP OSD Menu Motorised BRIGHTNESS 0 ~ 100 (Default 34) EXPOSURE MODE GLOBAL / 0 ~ 7 (Default 4) RETURN AF MODE SEMI / AUTO / MANUAL ZOOM - / + FOCUS - / + BOOT MODE SAVE POS / WIDE END / TELE END /... - Page 9 Index 2DNR AUTO / MANUAL 0 ~ 20 (Default 19) RETURN VIDEO SETTING NO ADJUSTMENT SEE 4-IN-1 SWITCH STANDARD 5MP 20 / 4MP 25 / 4MP 30 / 1080P 25 / 1080P 30 / REBOOT & APPLY RETURN LANGUAGE ENGLISH / SIMPLIFIED CHINESE / TRADITIONAL CHINESE / RUSSIAN / SPANISH / FRENCH / POLISH / ITALIAN / PORTUGUESE OFF / ON...
-
Page 10: Key Menu Settings
SEE995 7.2 Key Menu Settings Exposure Mode - AUTO / GLOBE / GLOBAL sets the required shutter speed for the current light level. The shutter speed will automatically detect the required length of time to keep the digital sensor exposed to light. FLK option sets the shutter speed to stop synchronisation with lighting so that pulsing effect is minimised. -
Page 11: Troubleshooting
- CVBS), when using a 2 MegaPixel DVR or above then use another video format, like HD-TVI. C. Reset the camera menu via Zip Coaxitron – OSD Menu D. Check if the DVR (digital video recorder) supports the resolution of the camera. -
Page 12: General Maintenance
SEE995 D. Ensure that the BNC – BNC lead that is connected between the camera and DVR has no shorts between the ground and the centre core (positive) or open circuits along the centre core (positive) or open circuits along the ground. -
Page 13: Specification
Index Specification 10.1 SEE995 Resolution Lens Type 2.8-12mm Motorised Image Output 1 Volt Peak-Peak 75 ohm Min.Illumination 0 Lux IR On Day/Night Mechanical (True Day-Night) IR Range Input Voltage 12V DC Current Consumption 500mA (IR On) IP Rating IP66 Video Connection... -
Page 14: Conditions
WEE/CG0783SS collection point as defined by your local council. 11.3 Copyright © Copyright 2023 Zip is a registered trademark of System Q Ltd, Chesterfield. Derbyshire. S40 2WB 24/10/2023 ZipDVR.com...
