- Page 1 5MP Anti-Vandal Dome 2.8-12mm Motorised Lens SEE375 © 2021 System Q Ltd ZipDVR.com...
-
Page 2: Table Of Contents
Table of Contents Part 1 Introduction 1 SEE375 ..........................1 Part 2 Tools & Handy Extras Part 3 Connections Part 4 4-In-1 Technology Part 5 Mounting 1 Anti-Vandal Dome ......................3 Part 6 Motorised Lens Part 7 OSD Menu 1 5MP OSD Menu ....................... -
Page 3: Part 1 Introduction
This Anti-Vandal Dome with a tough metal exterior is ideal for both outdoor and indoor uses. This 5MP model is a perfect match for higher spec DVRs such as the new Zip Supa DVR that can record in 5MP quality. Pick this model for finer detailing if your business relies on its CCTV to protect employees or stock. -
Page 4: Part 3 Connections
xSEE615 Connections The camera has a 2.1mm socket which requires 12V DC, use a regulated power supply rated above the current draw of the camera. The camera is polarity sensitive so connections must be correctly made. The camera has a standard BNC connector for the 4-in-1 video output, the output can be changed to AHD, CVI or CVBS if required. -
Page 5: Part 5 Mounting
Mounting Mounting 5.1 Anti-Vandal Dome A template is provided in the box for marking the hole positions for the fixing screws. © 2021 System Q Ltd ZipNVR.com... -
Page 6: Part 6 Motorised Lens
xSEE615 Motorised Lens To access the Motorised Lens via coaxitron:- 1. Click on the image in Live view 2. Click on the PTZ button at the bottom of the screen 3. Use Zoom + and - to zoom in and out, the camera should automatically focus when Zoom +/- is released ©... -
Page 7: Part 7 Osd Menu
OSD Menu OSD Menu Access to the camera menu is by Coaxitron. For the ZIP DVRs, ZIP Coaxitron is set as default. To access the Cameras Menu via coaxitron:- 1. Click on the image in Live view 2. Click on the PTZ button at the bottom of the screen 3. -
Page 8: 5Mp Osd Menu
xSEE615 7.1 5MP OSD Menu BRIGHTNESS 0 ~ 100 (Default 31) EXPOSURE MODE GLOBAL / BLC / FLC 0 ~ 7 (Default 4) RETURN AF MODE SEMI / AUTO / MANUAL ZOOM - / + FOCUS - / + BOOT MODE SAVE POS / WIDE END / TELE END / TDN AD OPEN / CLOSE... - Page 9 OSD Menu 0 ~ 20 (Default 19) RETURN VIDEO SETTING NO ADJUSTMENT SEE 4-IN-1 SWITCH STANDARD 5MP 20 / 4MP 25 / 4MP 30 / 1080P 25 / 1080P 30 / REBOOT & APPLY RETURN LANGUAGE ENGLISH / SIMPLIFIED CHINESE / TRADITIONAL CHINESE / RUSSIAN / SPANISH / FRENCH / POLISH / ITALIAN / PORTUGUESE OFF / ON...
-
Page 10: Key Menu Settings
xSEE615 7.2 Key Menu Settings Exposure Mode - AUTO / GLOBE / GLOBAL sets the required shutter speed for the current light level. The shutter speed will automatically detect the required length of time to keep the digital sensor exposed to light. FLK option sets the shutter speed to stop synchronisation with lighting so that pulsing effect is minimised. -
Page 11: Part 8 Troubleshooting
B. If set to CVBS, then this is a low quality video output for legacy systems (analogue - CVBS), when using a 2 MegaPixel DVR or above then use another video format, like HD-TVI. C. Reset the camera menu via Zip Coaxitron – OSD Menu D. - Page 12 xSEE615 D. Ensure that the BNC – BNC lead that is connected between the camera and DVR has no shorts between the ground and the centre core (positive) or open circuits along the centre core (positive) or open circuits along the ground. ©...
-
Page 13: Part 9 General Maintenance
General Maintenance General Maintenance · Routinely clean the camera to prevent dust build up as this can effect the performance of the camera. It is recommended to use a damp non-abrasive microfibre cloth. · Routinely check the connections for power and data to ensure no water ingress and corrosion. ·... -
Page 14: Part 10 Specification
Specification 10.1 SEE375 Resolution Lens Type 2.8-12mm Motorised Lens Image Output 1 Volt Peak-Peak 75 ohm Min.Illumination 0 Lux IR On Day/Night Mechanical (True Day-Night) IR Range Input Voltage 12V DC Current Consumption 500mA (IR On) IP Rating IP66... -
Page 15: Part 11 Conditions
WEE/CG0783SS collection point as defined by your local council. 11.3 Copyright © Copyright 2021 Zip is a registered trademark of System Q Ltd, Chesterfield. Derbyshire. S40 2WB © 2021 System Q Ltd ZipNVR.com... -
Page 16: Index
