UNIGUARD 4&8 HDD Series
16CH, 32CH, 64CH, H.265, 12MP NVR
Quick Installation Guide
Copyright © EverFocus Electronics Corp.
Release Date: March 2023
All the images including product pictures or screen shots in this document are for example only. The
images may vary depending on the product and software version. Information contained in this
document is subject to change without notice.
EverFocus Taiwan:
2F., No.12, Ln. 270, Sec. 3, Beishen Rd., Shenkeng Dist., New Taipei City 222, Taiwan
TEL: +886 2 2662 2338 FAX: +886 2 2662 3632
www.everfocus.com sales@everfocus.com.tw
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EverFocus UNIGUARD 4 HDD Series
Summary of Contents for EverFocus UNIGUARD 4 HDD Series
- Page 1 UNIGUARD 4&8 HDD Series 16CH, 32CH, 64CH, H.265, 12MP NVR Quick Installation Guide Copyright © EverFocus Electronics Corp. Release Date: March 2023 All the images including product pictures or screen shots in this document are for example only. The images may vary depending on the product and software version. Information contained in this document is subject to change without notice.
-
Page 2: Rear Panel
Note: 1. Equipment configurations and supplied accessories vary by country. Please consult your local EverFocus office or agents for more information. Please also keep the shipping carton for possible future use. 2. Contact the shipper if any items appear to have been damaged in the shipping process. -
Page 3: Basic Installation
1.3 Dimensions 2. Basic Installation • Prepare a 1# or 2# Philips screwdriver, a pair of antistatic gloves or a wrist strap. • Disconnect power before installation. 2.1 Remove Upper Cover 1. Loosen the screws on the upper cover. 2. Slide the upper cover backward, then lift it up to remove the cover. - Page 4 2.2 Install Disk The installation steps for devices with mounting plate and disk bracket are different. Choose the installation method according to your device model. Device with mounting plate 1. Loosen the screws of the mounting plate on the side panels. 2.
-
Page 5: Hard Disk Compatibility List
Power cable Data cable 2.3 Hard Disk Compatibility List Please go to the product page (Download) on EverFocus’ Website www.everfocus.com to see the latest Storage Compatibility List. It’s recommended to use the hard disk models listed on the Storage Compatibility List to ensure your hard disks are compatible. -
Page 6: Basic Connection
3. Connect microphones to the audio input ports to transmit audio from the NVR to the remote sites (Web browser of NVR, eFVMS App or EverFocus CMS). Note that the microphones with a (built-in) amplifier and external power supply are required. -
Page 7: Turning On/Off The Power
If you have never configured the email settings, please mail the MAC Address, Serial Number and the Model Name to ts@everfocus.com.tw to get a temporary password. - Page 8 5. P2P Function The P2P function allows users to add NVRs to Guard Viewer App through QR code. 1. Install Guard Viewer App. For Android users, go to Google Play Store. For iOS users, go to Apple Store. After the installation process is complete, start the App. 2.
- Page 9 3.Scan the NVR’s QR code on the Network page of the P2P menu. Than input the NVR ID, password and Media. Tap Save. 4.The NVR is now added and connected to the App. You can start accessing the NVR. P/N:...
