Q-tran QOM-eLED+DMX Installation Manual

QOM-eLED+DMX
LED POWER SUPPLY 100W–300W
1
PRODUCT
QOM-eLED
Sample Part Number: QOM-eLED-100W-UNV-24VDC-DMX-BK
1
PRODUCT
QOM-eLED
5
CONTROL
DMX
COMPATIBLE LEDS
STATIC WHITE
SW24/1.5-4.0
SW24/5.0, SW-HE, SW-HE+
SD-SW24/1.0-4.0
SD-SW24/6.0
SW-IA
SW-XT
© 2023 Q-Tran Inc. All rights reserved | 155 Hill St. Milford, CT 06460 | 203-367-8777 | sales@q-tran.com | www.q-tran.com
Utilizes a 100W constant voltage LED Driver from Thomas Research and the LINEARdrive DMX decoder from eldoLED
Designed for outdoor use with its exterior rating
Can accommodate up to 300W of power and control within a single enclosure
Comes prewired with all decoders connected together using terminal blocks
Suitable for connecting RGB or RGBW wires for color control
2 3
WATTAGE PRIMARY VOLTAGE
UNV
2
WATTAGE
100W
200W
300W
6
COLOR
BK Black Powder Coat Finish
SS 316 Marine Grade Stainless Steel
OTHER
DW-HE Tunable Applications
DW-HE Warm Dim Applications
WD
SC
RGB
RGBW, RGBW-HE
4
SECONDARY VOLTAGE
24VDC
3
PRIMARY VOLTAGE
UNV Universal (120-277V)
SHEETS
Q-SHEETS SW
Q-SHEETS DW Tunable Applications
Q-SHEETS DW Warm Dim Applications
Q-SHEETS RGB
Q-SHEETS RGBW
5 6
CONTROL COLOR
DMX
4
SECONDARY VOLTAGE
24VDC
MICRO 5
MICRO 5-SW
MICRO 5-DW Tunable Applications
MICRO 5-DW Warm Dim Applications
MICRO 5-RGB
Specification subject to change. Rev-08-09-23
