SilverSATA™ V SJ
Table of Contents
Before Installation
Contents of the box
Identifying the parts of the product
Installing hard drives
Connecting to a computer
Usage with Macs
Usage with Windows computers
Warnings and Notices
Technical Specifications
S i l v e r S A T A V S J U s e r M a n u a l
USER'S MANUAL
Revised 9/21/2006
Features
• Connects through fast eSATA. When configured
in a software RAID, we've seen data transfer
speeds as fast as 220MB/sec!
• Hot-swappable trays allow you to quickly change
out drives. Trays are interchangeable with other
products in the SilverSATA series.
• Port multiplying allows it to connect through a
single cable. This means less clutter on your
desktop.
• Its attractive design takes up little desktop space,
occupying a tiny footprint for so much storage
capability (up to 3.75 Terabytes).
• Sturdy aluminum case provides excellent heat
dissipation and rugged durability.
• Handle provides easy portability.
• Simple, plug and play configuration with Windows
2000/XP/Server 2003 and Mac OS X.
2
2
2
3
4
5
5
6
6
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for WiebeTech SIS5-SJ
Summary of Contents for WiebeTech SIS5-SJ
- Page 1 SilverSATA™ V SJ Table of Contents Before Installation Contents of the box Identifying the parts of the product Installing hard drives Connecting to a computer Usage with Macs Usage with Windows computers Warnings and Notices Technical Specifications S i l v e r S A T A V S J U s e r M a n u a l USER’S MANUAL Revised 9/21/2006 Features...
-
Page 2: Before Installation
WiebeTech LLC Before Installation Check the accessories with your SilverSATA V. Please contact WiebeTech if any parts are missing or damaged. The box should contain the following items: SilverSATA V SJ enclosure Removable trays (contained in the unit) eSATA cable... -
Page 3: Installing Hard Drives
WiebeTech LLC Installing Hard Drives If you purchased your SilverSATA V with drives pre-installed and pre-configured, you may skip ahead to the next section. Remove a tray from the SilverSATA V enclosure. Insert the included key into the lock hole to release the tray’s handle then slide the tray straight out. - Page 4 WiebeTech LLC Install your SATA hard drive into the tray. Lay the drive into the frame of the removable tray, making sure it lays flat. Align the 4 screw positions then use the included screws (#6-32) to secure the drive into position.
- Page 5 WiebeTech LLC Usage with Macintosh computers Compatibility The SilverSATA V is fully plug-and-play under Mac OS X. The unit must be used with a fully SATA2 compliant host that supports Port Multiplying. Mounting and Ejecting Volumes When you connect the unit to the Mac for the first time and turn on the power, you’ll probably see a message saying that the disks are unreadable.
-
Page 6: Technical Specifications
(1-866-744-8722). After 90 days, email support is available at support@wiebetech.com. SilverSATA V is a trademark of WiebeTech LLC. Other marks are the property of their respective owners. © 2005, 2006 WiebeTech LLC. All rights reserved. FCC Compliance Statement: “This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”...
