SilverSATA™ IV SJ
Table of Contents
Before Installation
Contents of the box
Identifying the parts of the product
Hardware Setup
Installing hard drives
Connecting to a computer
LED Indicators
Usage with Macs
Usage with Windows computers
Warnings and Notices
Technical Specifications
S i l v e r S A T A I V S J U s e r M a n u a l
USER'S MANUAL
Revised 9/21/2006
Features
• Connects through fast eSATA. When configured in a
software RAID, we've seen data transfer speeds faster
than 200MB/sec!
• Each SATA hard drive has its own data channel for
maximum speed.
• Hot-swappable trays allow you to quickly change out
drives. Trays are interchangeable with other products in
the SilverSATA series.
• Its attractive design takes up little desktop space,
occupying a tiny footprint for so much storage capability
(up to 3 Terabytes).
• Sturdy aluminum case provides excellent heat dissipation
and rugged durability.
2
2
2
3
3
4
5
5
5
6
6
- 1 -
Advertisement
Table of Contents
Related Manuals for WiebeTech SIS4-SJ
Summary of Contents for WiebeTech SIS4-SJ
- Page 1 SilverSATA™ IV SJ Table of Contents Before Installation Contents of the box Identifying the parts of the product Hardware Setup Installing hard drives Connecting to a computer LED Indicators Usage with Macs Usage with Windows computers Warnings and Notices Technical Specifications S i l v e r S A T A I V S J U s e r M a n u a l USER’S MANUAL Revised 9/21/2006...
-
Page 2: Before Installation
WiebeTech LLC Before Installation Check the accessories with your SilverSATA IV. Please contact WiebeTech if any items are missing or damaged. The box should contain the following items: SilverSATA IV enclosure Removable trays (inside enclosure) eSATA cables Power cord Packet of keys and drive screws Manual and Warranty information Familiarize yourself with the parts of your SilverSATA IV. -
Page 3: Hardware Setup
Install the appropriate drivers for the card. These are usually found on the CD or diskette that came with the card. The drivers for WiebeTech cards are found on the “Product Information & Manuals” CD. Browse to the folder PCIe Host Cards”... - Page 4 WiebeTech LLC Install your SATA hard drive into the tray. Lay the drive into the frame of the removable tray, making sure it lays flat. Align the 4 screw positions then use the included screws (#6-32) to secure the drive into position.
-
Page 5: Led Indicators
WiebeTech LLC LED Indicators • HDD Access LED will flash blue when the computer accesses data on the hard drive. • Power LED will glow blue if the power is turned on. • Fail LED will light red if the internal temperature exceeds 60° C or the fan fails. -
Page 6: Warnings And Notices
WiebeTech offers free phone support for 90 days after purchase (1-866-744-8722). After 90 days, email support is available at support@wiebetech.com. SilverSATA is a trademark of WiebeTech LLC. Other marks are the property of their respective owners. © 2006 WiebeTech LLC. All rights reserved. - Page 7 Use a power supply with an RFI reducing ferrite approximately 5 inches from the DC plug. If you have any questions or problems, please contact you are interested in purchasing more WiebeTech products, check our website or contact sales@wiebetech.com. We appreciate being able to serve you!
