SilverSATA™ II SJ
Table of Contents
Before Installation
Contents of the box
Identifying the parts of the product
Hardware Setup
Installing hard drives
Connecting to a computer
LED Indicators
Usage with Macs
Usage with Windows computers
Warnings and Notices
Technical Specifications
S i l v e r S A T A I I S J U s e r M a n u a l
USER'S MANUAL
Revised 9/13/2006
Features
• Connects to your computer through a fast eSATA
connection. Also features a USB port for wide
compatibility.
• Each SATA hard drive has its own data channel
for maximum speed.
• Hot-swappable trays allow you to quickly change
out drives. Trays are interchangeable with other
products in the SilverSATA series.
• Its attractive design takes up little desktop space,
occupying a tiny footprint for so much storage
capability (up to 1.5 Terabytes).
• Sturdy aluminum case provides excellent heat
dissipation and rugged durability.
2
2
2
3
3
4
5
5
5
6
6
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for WiebeTech SIS2-SJ
Summary of Contents for WiebeTech SIS2-SJ
- Page 1 SilverSATA™ II SJ Table of Contents Before Installation Contents of the box Identifying the parts of the product Hardware Setup Installing hard drives Connecting to a computer LED Indicators Usage with Macs Usage with Windows computers Warnings and Notices Technical Specifications S i l v e r S A T A I I S J U s e r M a n u a l USER’S MANUAL Revised 9/13/2006...
-
Page 2: Before Installation
WiebeTech LLC Before Installation Check the accessories with your SilverSATA II SJ. Please contact WiebeTech if any items are missing or damaged. The box should contain the following items: SilverSATA II SJ enclosure Removable trays (inside enclosure) eSATA cables Power cord... -
Page 3: Hardware Setup
Install the appropriate drivers for the card. These are usually found on the CD or diskette that came with the card. The drivers for WiebeTech cards are found on the “Product Information & Manuals” CD. Browse to the folder PCIe Host Cards”... - Page 4 WiebeTech LLC Install your SATA hard drive into the tray. Lay the drive into the frame of the removable tray, making sure it lays flat. Align the 4 screw positions then use the included screws (#6-32) to secure the drive into position.
-
Page 5: Led Indicators
WiebeTech LLC LED Indicators • HDD Access LED will flash blue when the computer accesses data on the hard drive. • Power LED will glow blue if the power is turned on. Usage with Macintosh computers Mounting and Unmounting Volumes When you connect the unit to the Mac for the first time and turn on the power, you may see a message saying that the disks are unreadable. -
Page 6: Warnings And Notices
90 days of free phone support (1-866-744-8722). After 90 days, email support is available at support@wiebetech.com. SilverSATA is a trademark of WiebeTech LLC. Other marks are the property of their respective owners. © 2005-2006 WiebeTech LLC. All rights reserved. - Page 7 Use a power supply with an RFI reducing ferrite approximately 5 inches from the DC plug. If you have any questions or problems, please contact you are interested in purchasing more WiebeTech products, check our website or contact sales@wiebetech.com. We appreciate being able to serve you!
