BOERPLAY SPTE100.280 Manual

Climbing equipment
Hide thumbs

Advertisement

Quick Links

Download this manual
Climbing equipment
SPTE100.280

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPTE100.280 and is the answer not in the manual?

Questions and answers

Related Manuals for BOERPLAY SPTE100.280

Summary of Contents for BOERPLAY SPTE100.280

  • Page 1 Climbing equipment SPTE100.280...
  • Page 2 3,30 m Benaming TOE SPT 100 280 Spring / rektoestel Title Tekening Opmerking Trimbaan Drawing Comment BOER Datum Hoofdafmetingen Main dimensions 4-11-2015 Date SPEELTOESTELLEN...
  • Page 3 3,96 m Opvangzone Impact area Obstakelvrije zone Obstacle free zone Benaming TOE SPT 100 280 Spring / rektoestel Title Tekening Opmerking Trimbaan Drawing Comment BOER Datum Obstakelvrije zone Obstacle free zone 4-11-2015 Date SPEELTOESTELLEN...
  • Page 4 1,65 m 1,50 m 1,50 m 1,65 m Grondmarkering Ground level marker Benaming TOE SPT 100 280 Spring / rektoestel Title Tekening Opmerking Trimbaan Drawing Comment BOER Datum Bodemplan Groundplan 4-11-2015 Date SPEELTOESTELLEN...
  • Page 5 Geleverde modules: Supplied modules: Zie tabel See table Montageinstructie: Assembly instruction: - De hoofdmaten geven de maten van de staanders en vloeren aan - The main dimensions indicate the dimensions of the posts and floors - De detailtekeningen geven specifiek de maten van de verbindingen aan - The detailed dimensions show the specific dimensions of the connections - The modules which contain tubes are dimensioned at the top of the flanges - De modules met buizen zijn op de tekeningen bemaat op bovenkant kopplaat...
  • Page 6 LOGBOOK Type indication Article number SPTE100.280 Product Name Climbing equipment Maximum fall height 1,5 m Construction year 2023 Certificate 0183402366 Inspection body Manufacturer name Boer Speeltoestellen Hyacintstraat 2 - 4255 HX Nieuwendijk Phone: +31 (0)183 40 23 66 Fax: +31 (0)183 40 35 64...
  • Page 7 LOGBOOK Inspection and maintenance Date of Time of Name Name Parts to be inspection inspection executor of executor of Found defects replaced maintenance maintenance inspection maintenance Accidents Date Age of Measures taken Probable cause of injury Occurred injury accident victim after accident...

  • Page 8: Inspection And Maintenance Intervals

    Inspection and maintenance intervals months Nr. Inspection Maintenance between inspections Verify equipment's stability, junctions and Add missing parts, secure joints, apply missing parts. Inspect bolts, screws and nuts for missing fixing agent and replace absence, jams, corrosion and wear. corroded parts. Replace worn parts and/or remove non- Check suspension for wear.
  • Page 9 7. Remember that bad maintenance leads to unsafe conditions and notably faster impoverishment of the playground area. 8. Replacement parts can be ordered at the manufacturer with the OEM part numbers on the module drawing. Drawings can be found in the user guide. 9.
  • Page 10 Dit toestel is geen speeltoestel conform het warenwetbesluit attractie- en speeltoestellen, en is dus niet als zodanig gecertificeerd. This equipment is not playground equipment, so it has not been certified as such.
  • Page 11 !"#" %&"'(' %&"'''...
  • Page 12 Type Progr. Bew. Rev. Benaming Volgnr Opmerking 4,8x25 - VZ 8.8 Zebra Pias Inslagdop grijs Inslagring grijs Vulring art.nr.80395000050 Vulschijf art.nr.80395000040 Pijp Ø 31.8x2.6 L = 1135 Benaming MOD SPT 001 006 Stang staander/ligger Title Tekening Opmerking h.o.h. 960 mm Drawing Comment BOER...
  • Page 13 Type Progr. Volgnr Bew. Rev. Benaming Opmerking Borgdopmoer M6 - RVS A2-70 Veiligheids Bout Pin-Torx - RVS A2-70 Zebra Pias 4,8x25 - VZ 8.8 Inslagdop grijs Inslagring grijs Vulring art.nr.80395000050 Vulschijf art.nr.80395000040 Klembeugel blauw 32mm 80095001015 Pijp Ø 31.8x2.6 L = 1135 Afdichtplaat Sport 280 Benaming...
  • Page 14 Type Progr. Volgnr Bew. Rev. Benaming Opmerking Zebra Pias 4,8x25 - VZ 8.8 Inslagdop grijs Inslagring grijs Afdichtdop JP-buis Pijp Ø31.8 x 2.6 L=280 mm Benaming MOD SPT 001 008 Handgreep Title Tekening Opmerking Drawing Comment BOER Datum Samenstelling module Assembly module 4-11-2015 Date SPEELTOESTELLEN...
  • Page 15 1150 1650 2150 1025 2650 3150 2125 2125 3300 All holes Ø46 unless otherwise stated. All holes pierce unless otherwise stated. All the holes in the heart of the post, unless otherwise stated. Type Progr. Volgnr Bew. Rev. Benaming Opmerking Alle gaten Ø46 tenzij anders vermeld.
