Summary of Contents for BOERPLAY Uneven bridge
- Page 1 Uneven bridge SPTE100.300...
- Page 2 3,10 m 1,33 m 1,25 m 1,08 m 1,00 m 0,00 m Benaming TOE SPT 100 300 Ongelijke brug Title Tekening Opmerking Trimbaan Drawing Comment BOER Datum Hoofdafmetingen Main dimensions 8-4-2015 Date SPEELTOESTELLEN...
- Page 3 0,25 m 1,40 m 1,40 m 0,25 m Benaming TOE SPT 100 300 Ongelijke brug Title Tekening Opmerking Trimbaan Drawing Comment BOER Datum Bodemplan Groundplan 8-4-2015 Date SPEELTOESTELLEN...
- Page 4 Geleverde modules: Supplied modules: Zie tabel See table Montageinstructie: Assembly instruction: - De hoofdmaten geven de maten van de staanders en vloeren aan - The main dimensions indicate the dimensions of the posts and floors - De detailtekeningen geven specifiek de maten van de verbindingen aan - The detailed dimensions show the specific dimensions of the connections - The modules which contain tubes are dimensioned at the top of the flanges - De modules met buizen zijn op de tekeningen bemaat op bovenkant kopplaat...
- Page 5 LOGBOOK Type indication Article number SPTE100.300 Product Name Uneven bridge Maximum fall height 0,6 m Construction year 2024 Certificate 0183402366 Inspection body Manufacturer name Boer Speeltoestellen Hyacintstraat 2 - 4255 HX Nieuwendijk Phone: +31 (0)183 40 23 66 Fax: +31 (0)183 40 35 64...
- Page 6 LOGBOOK Inspection and maintenance Date of Time of Name Name Parts to be inspection inspection executor of executor of Found defects replaced maintenance maintenance inspection maintenance Accidents Date Age of Measures taken Probable cause of injury Occurred injury accident victim after accident...
-
Page 7: Inspection And Maintenance Intervals
Inspection and maintenance intervals months Nr. Inspection Maintenance between inspections Verify equipment's stability, junctions and Add missing parts, secure joints, apply missing parts. Inspect bolts, screws and nuts for missing fixing agent and replace absence, jams, corrosion and wear. corroded parts. Replace worn parts and/or remove non- Check suspension for wear. - Page 8 7. Remember that bad maintenance leads to unsafe conditions and notably faster impoverishment of the playground area. 8. Replacement parts can be ordered at the manufacturer with the OEM part numbers on the module drawing. Drawings can be found in the user guide. 9.
- Page 9 Dit toestel is geen speeltoestel conform het warenwetbesluit attractie- en speeltoestellen, en is dus niet als zodanig gecertificeerd. This equipment is not playground equipment, so it has not been certified as such.
- Page 10 Grondmarkering Ground level marker Type Progr. Volgnr Bew. Rev. Benaming Opmerking L=2025 Rebo Ø145 Rebo Ø145 L=1775 Rebo Ø145 L=3100 2025 1775 Gaten Ø46 tenzij anders vermeld Benaming Rebopakket MOD SPT 100 300 Title Tekening Opmerking SPT.100.300 Drawing Comment BOER Datum Samenstelling module Assembly module 8-4-2015...
- Page 11 Type Progr. Volgnr Bew. Rev. Benaming Opmerking Vulschijf art.nr.80395000040 Zebra Pias 4,8x25 - VZ 8.8 KoppelbuisØ31.8 art.nr.80096030000 Inslagdop grijs Vulring art.nr.80395000050 Benaming MOD JGP 008 051 systeembuis hoh 153 Title Tekening Opmerking Sport Drawing Comment Datum Samenstelling module Assembly module 8-4-2015 Date...
