- Page 1 Klimnet SPTEROB.917...
- Page 2 0,00 m 2,10 m 2,00 m 1,66 m 0,32 m 0,00 m Benaming TOE SPT ROB 917 Klimnet Title Tekening Opmerking Stormbaan Drawing Comment Datum Afmetingen Dimensions 22-4-2020 Date...
- Page 3 5,89 m Opvangzone Impact area Obstakelvrije zone Obstacle free zone Benaming TOE SPT ROB 917 Klimnet Title Tekening Opmerking Stormbaan Drawing Comment Datum Obstakelvrije zone Obstacle free zone 22-4-2020 Date...
- Page 4 2,30 m 1,84 m 0,5 x 0,12 m 2,19 m 2,10 m Grondmarkering Ground level marker 0,62 m Benaming TOE SPT ROB 917 Klimnet Title Tekening Opmerking Stormbaan Drawing Comment Datum Bodemplan Groundplan 22-4-2020 Date...
- Page 5 Montagevolgorde: Assembly sequence: 1 - Graaf de gaten volgens het bodemplan 1 - Dig the holes in the ground plan 2 - Plaats 4 2 - Place 4 3 - Plaats 1 3 - Place 1 4 - Plaats 5 op 4 en 1 4 - Place 5 and attach it to 4 and 1 5 - Plaats 3 op 4 5 - Place 3 and attach it to 4...
- Page 6 0,00 m 0,47 m 0,52 m 0,72 m 0,77 m 0,97 m 1,02 m 1,22 m 1,27 m 1,47 m 1,52 m 1,72 m 1,77 m 2,19 m 2,00 m 1,57 m 0,20 m 0,12 m 0,10 m 0,00 m Benaming TOE SPT ROB 917 Klimnet...
- Page 7 LOGBOOK Type indication Adventure Play Article number SPTEROB.917 Product Name Klimnet Maximum fall height 2,0 m Construction year 2024 Certificate 0183402366 Inspection body Manufacturer name Boer Speeltoestellen Hyacintstraat 2 - 4255 HX Nieuwendijk Phone: +31 (0)183 40 23 66 Fax: +31 (0)183 40 35 64...
- Page 8 LOGBOOK Inspection and maintenance Date of Time of Name Name Parts to be inspection inspection executor of executor of Found defects replaced maintenance maintenance inspection maintenance Accidents Date Age of Measures taken Probable cause of injury Occurred injury accident victim after accident...
- Page 9 Inspection and maintenance intervals months Nr. Inspection Maintenance between inspections Verify equipment's stability, junctions and Add missing parts, secure joints, apply missing parts. Inspect bolts, screws and nuts for missing fixing agent and replace absence, jams, corrosion and wear. corroded parts. Replace worn parts and/or remove non- Check suspension for wear.
- Page 10 7. Remember that bad maintenance leads to unsafe conditions and notably faster impoverishment of the playground area. 8. Replacement parts can be ordered at the manufacturer with the OEM part numbers on the module drawing. Drawings can be found in the user guide. 9.
- Page 11 Dit toestel is geen speeltoestel conform het warenwetbesluit attractie- en speeltoestellen, en is dus niet als zodanig gecertificeerd. This equipment is not playground equipment, so it has not been certified as such.
- Page 12 Afronden R > 3 mm Type Progr. Volgnr. Bew. Rev. Benaming Opmerking 5 x 70 - RVS A2-70 Schroef Assy Paal 14-16 Lengte =900 Standaard plank 120x20 Lengte = 500 Benaming MOD PST 007 031 A Stapstam Ø14-16 Title Tekening Opmerking Adventure Play Drawing...
- Page 13 A ( 1 : 4 ) Type Progr. Volgnr. Bew. Rev. Benaming Opmerking BORGMOER M12 - RVS A2-70 Sluitring D-sluiting 5 MM RVS Dop zwart Beschermdop M10-M12 RING KUNSTSTOF Slotbout met lip M12x150 Balanceernet Adventure Play Benaming MOD PST 013 131 Klimnet Title Tekening...
- Page 14 A ( 1 : 4 ) Type Progr. Volgnr. Bew. Rev. Benaming Opmerking BORGMOER M12 - RVS A2-70 Sluitring D-sluiting 5 MM RVS Dop zwart Beschermdop M10-M12 RING KUNSTSTOF Slotbout met lip M12x150 Klimnet Adventure Play Benaming MOD PST 013 241 Klimnet Title Tekening...
- Page 15 2000 Type Progr. Volgnr. Bew. Rev. Benaming Opmerking Draadeind+borgm.+ringen+dop M12, L= 280, RVS A2-70 Schroef Assy 5 x 70 - RVS A2-70 Paal 14-16 Lengte =2200 Paal 14-16 Lengte =2600 Standaard plank 120x20 Lengte = 2100 Benaming MOD PST 016 245 Klimsporten Title Tekening...
- Page 16 2391 Type Progr. Volgnr. Bew. Rev. Benaming Opmerking Draadeind+borgm.+ringen+dop M12, L= 260, RVS A2-70 Paal 10-12 Lengte =2500 Benaming MOD PST 016 246 Balk 2,5 m Title Tekening Opmerking ø100 - 120 Drawing Comment Datum Samenstelling module Assembly module 1-2-2019 Date...
