Gas Oven Repair Guide
[ FX710*, FX510*]
Ver. Aug-2013
Ignition
• Cooktop ignition
Failure
• Oven ignition
Heating
• Oven
defect
• Cooktop
Abnormal
• Button, Motors
Flame
• Lamp
• Smell, Smoke, Noise
Others
• No Display, Key Panel
Error
• Sensors
Code
• Temperature control
- 1/36 -
Advertisement
Related Manuals for Samsung FX710 Series
Summary of Contents for Samsung FX710 Series
- Page 1 All manuals and user guides at all-guides.com Gas Oven Repair Guide [ FX710*, FX510*] Ver. Aug-2013 Ignition • Cooktop ignition Failure • Oven ignition Heating • Oven defect • Cooktop Abnormal • Button, Motors Flame • Lamp • Smell, Smoke, Noise Others •...
- Page 2 All manuals and user guides at all-guides.com #1. Symptom : Ignition Defect (Cooktop) 1-1. Repair Schematic Chassis Project Basic Model Type FX710 Gas Oven Vulcan FX510 Block Check-1 Cause Check-2 Code Electrode defect Crack & clip fastening Electrode Clip ...
- Page 3 All manuals and user guides at all-guides.com #2. Symptom : Ignition Defect (Oven) Repair 계통도 2-1. Repair Schematic Chassis Project Basic Model Type FX710 Gas Oven Vulcan FX510 Block Check-1 Cause Check-2 Code HSI defect HSI Crack inspection Wire ...
- Page 4 All manuals and user guides at all-guides.com #3. Symptom : Heating Defect (Oven) 3-1. Repair Schematic Chassis Project Basic Model Type FX710 Gas Oven Vulcan FX510 Block Check-1 Cause Check-2 Code Temp. Selection Temp. Selection Program defect inspection Temp. Sens. defect ...
- Page 5 All manuals and user guides at all-guides.com #4. Symptom : Heating Defect (Cooktop) 4-1. Repair Schematic Chassis Project Basic Model Type FX710 Gas Oven Vulcan FX510 Block Check-1 Cause Check-2 Code Orifice defect Orifice Diameter Nozzle inspection Orifice check for debris Gas leak / Regulator Gas Line...
- Page 6 All manuals and user guides at all-guides.com #5. Symptom : Flame Defect (Cooktop) 5-1. Repair Schematic Chassis Project Basic Model Type FX710 Gas Oven Vulcan FX510 Block Check-1 Cause Check-2 Code Cooktop Burner/Cap defect Burner, Cap mounting Burner inspection Flame Defect ...
- Page 7 All manuals and user guides at all-guides.com #6. Symptom : Other Defects 6-1. Repair Schematic Chassis Project Basic Model Type FX710 Gas Oven Vulcan FX510 Block Check-1 Cause Check-2 Code Gas Leak Gas Line Gas main pipe connection area leakage check ...
- Page 8 All manuals and user guides at all-guides.com #6. Symptom : Other Defects 6-2. Repair Schematic Chassis Project Basic Model Type FX710 Gas Oven Vulcan FX510 Block Check-1 Cause Check-2 Code Breaker / Power Wire harness coating Power cord defect condition check cord ...
- Page 9 All manuals and user guides at all-guides.com #7. Symptom : Error Code 7-1. Repair Schematic Chassis Project Basic Model Type FX710 Gas Oven Vulcan FX510 Block Check-1 Cause Check-2 Code Key panel Key panel surface Main (Membrane switch) damage Panel ...
- Page 10 All manuals and user guides at all-guides.com Tip 1-1. Electrode Inspection “Electrode wire and fastening Clip conditions” inspection. Check Point Step 1 ① Check if power comes on. ② Check if any Sparks are coming from the Electrode. Step 2 ①...
- Page 11 All manuals and user guides at all-guides.com Tip 1-2. Spark Module Inspection “Spark module state and Wire connection state” inspection. Check Point Step 1 ① Check if power comes on. ② Check if any Sparks are coming from the Electrode. Step 2 ①...
- Page 12 All manuals and user guides at all-guides.com Tip 1-3. Switch Ignition Inspection “Switch ignition state and Wire connection state” inspection. Check Point Step 1 ① Check if power comes on. ② Check if any Sparks are coming from the Electrode. Step 2 ①...
- Page 13 All manuals and user guides at all-guides.com Tip 1-4. Burner, Cap Inspection “Burner, Cap debris and mounting state” inspection. Check Point Step 1 ① Check if any Sparks are coming from the Electrode. ② Check if the gas supply valve is opened completely. Step 2 ①...
- Page 14 All manuals and user guides at all-guides.com Tip 1-5. Nozzle Inspection “Orifice debris and Orifice Diameter” inspection. Check Point Step 1 ① Check if Cooktop / Oven is operating properly. ② Check if the gas supply valve is opened completely. Step 2 ①...
- Page 15 All manuals and user guides at all-guides.com Tip 1-5. Nozzle Inspection “Orifice debris and Orifice Diameter” inspection. Check Point ※ Cooktop Orifice Diameter Spec Sheet per Product 1.01 1.01 1.92 - 15/36 -...
- Page 16 All manuals and user guides at all-guides.com Tip 1-6. Regulator, Gas Leak Inspection “Regulator damage, Shut-off lever, Gas leak” inspection. Check Point Step 1 ① Check if any Sparks are coming from the Electrode. ② Check if the gas supply valve is opened completely. Step 2 ①...
- Page 17 All manuals and user guides at all-guides.com Tip 2-1. HSI Inspection “HSI damage and ignition state” inspection. Check Point Step 1 ① Check if power comes on. ② Check if the gas supply valve is opened completely. ③ Check if HSI ignites properly when Oven starts. Step 2 ①...
- Page 18 All manuals and user guides at all-guides.com Tip 2-2. Temperature Sensor Inspection “Temp. Sensor connection and resistance value” inspection. Check Point Step 1 ① Check if power comes on. ② Check if the gas supply valve is opened completely. ③ Check the Temp. Sensor connection. Step 2 ①...
- Page 19 All manuals and user guides at all-guides.com Tip 2-3. Assy PCB Inspection “Temp. Sensor connection and resistance value” inspection. Check Point Step 1 ① Check the PCB terminal’s input voltage. ② Check connection on each PCB terminal. Step 2 ① Check the PCB input voltage (normal : 120V). ②...
- Page 20 All manuals and user guides at all-guides.com Tip 2-4. Safety Valve Inspection “Safety valve connection and resistance value” inspection. Check Point Step 1 ① Check the Safety valve connection. ② Check if HSI ignites properly when Oven starts. Step 2 ①...
- Page 21 All manuals and user guides at all-guides.com Tip 3-1. Temperature Selection Inspection “Conversion on / off state” inspection. Check Point Step 1 ① Verify with the customer the difference between actual temperature and the product’s Temp. sensor temperature. Step 2 ①...
- Page 22 All manuals and user guides at all-guides.com Tip 3-2. Door Close Inspection “Conversion on / off state” inspection. Check Point Step 1 ① Check if the Door closes properly. Step 2 ① Check the Display while the oven is operating for the word ‘Door’. ②...
- Page 23 All manuals and user guides at all-guides.com Tip 5-1. Cooktop Flame-Out / Low Flame is Large “Orifice debris and Orifice Diameter” inspection. Check Point Step 1 ① Check if the gas supply valve is open completely. ② Check if the unit is igniting when Cooktop start. Step 2 ①...
- Page 24 All manuals and user guides at all-guides.com Tip 6-1. Smell / Smoke Inspection “Air shutter opening area” inspection. Check Point Step 1 ① Check if the gas supply valve is open completely. ② Check if Self Clean was used at least once before first time use. Step 2 ①...
- Page 25 All manuals and user guides at all-guides.com Tip 6-2. Door / Drawer Open/Close Defect “Door / Drawer Assy and Open/Close interference “ inspection. Check Point Step 1 ① Check the Door / Drawer for any assembly issues. Step 2 ① Check the Hinge for any stuck debris or deformations. →...
- Page 26 All manuals and user guides at all-guides.com Tip 6-3. Cooktop Abnormal Noise “Orifice debris and orifice Diameter” inspection. Check Point Step 1 ① Check if it’s a Spark operating noise, or gas flow noise. Step 2 ① Check that there is no gas pressure above 7”WC. ②...
- Page 27 All manuals and user guides at all-guides.com Tip 6-4. Convection Operation Inspection “Convection operation and abnormal noise” inspection. Check Point Step 1 ① Check if the Conv. Fan motor is connected properly. ② Check for any abnormal noise during Conv. Mode operation. ③...
- Page 28 All manuals and user guides at all-guides.com Tip 6-5. Circuit Breaker Inspection “Wire harness coating condition inspection. Check Point Step 1 ① Check if the Breaker Spec is appropriate for product use (Allowable Current >20A). ② Check if the Extension cord is appropriate for product use (Allowable Current >...
- Page 29 All manuals and user guides at all-guides.com Tip 6-6. Wire Harness Connection Inspection “Wire harness coating condition inspection. Check Point Step 1 ① Check that the Power cord is connected properly. Step 2 ① Check that the PCB is connected properly. .
- Page 30 All manuals and user guides at all-guides.com Tip 6-7. Membrane Key Operation Inspection “Key operating conditions inspection. Check Point Step 1 ① Check if Keys operating properly. Step 2 ① Check if the Membrane ribbon cable is properly connected. ② If issue persists after reconnecting the ribbon cable, inspect the Membrane ribbon cable.
- Page 31 All manuals and user guides at all-guides.com Tip 6-8. Membrane Switch Deformation “Key operating conditions inspection. Check Point Step 1 ① Check if Keys operating properly. Step 2 ① Check if Membrane Switches are deformed or damaged. ② Explain to the customer that if an excessively large pot is used, or if pot is used too closely to the Control Panel, the heat from the Oven vent and burner can cause damage to the Membrane Switch.
- Page 32 All manuals and user guides at all-guides.com Tip 7-1. Key Panel Short (-SE-) Check “Key panel appearance” inspection. Check Point Step 1 ① Check for any imprints or dents on the Key Panel. Step 2 ① Check if Key Panel ribbon cable connector is inserted properly.
- Page 33 All manuals and user guides at all-guides.com Tip 7-2. Temperature Sensor Open(E-27), Short(E-28) Check “Temperature Sensor” assembly and component inspection. Check Point Step 1 ① If E-27 error is displayed, check that the Temp. Sensor is connected properly. Step 2 ①...
- Page 34 All manuals and user guides at all-guides.com Tip 7-3. E-08 (Preheat fail) Inspection “Gas supply “ or “HSI ignite” inspection. Check Point Step 1 ① Check if the gas supply valve is open completely. ② Check if the Cooktop is igniting. ③...
- Page 35 All manuals and user guides at all-guides.com Tip 7-4. E-0A (Overheating Defect) Inspection “Gas supply “ or “HSI ignite” inspection. Check Point Step 1 ① Check that the gas pressure is normal, at 7”(NG), 11”(LP) Step 2 ② Check that GBR is set up appropriately with NG / LP setting. ②...
- Page 36 All manuals and user guides at all-guides.com Tip 7-5. E-0E Error Inspection “Door Lock Motor” & “Door Lock Switch” connection inspection. Check Point Step 1 ① Check if Door Lock Motor is connected properly. ② Check if PCB is connected properly. (CN 501) Step 2 ①...
