Summary of Contents for Fenix G12-2
- Page 1 Fenix G12-2 Fenix G12-2 Rev. 0.0.2 January 2024 G12-2 Rev. 0.0.2...
- Page 2 Before building and operating your G12-2, YOU MUST read through all of the operating instructions and instruction manual and fully understand them to get the maximum enjoyment and prevent unnecessary damage. Read carefully and fully understand the instructions before beginning assembly.
- Page 3 When the nut hit the carbon fibre, before insert it fully, you can add a tiny drop of thin slow cure CA glue. Very tiny…. Tip 3: Don’t use electric tools to drive the screw, most likely you’ll end damaging the carbon fibre…. G12-2 Rev. 0.0.2...
- Page 4 Be sure that the sphere holder fit easily, you might have to enlarge the hole with Make 2 mirror sets. some sandpaper. Insert OPT-038 Oring around sphere holder. Insert 2 HW026 M3x12 countersunk screw into G122-1 chassis Insert 2 FX088 (5mm thick) over the screw and tight the lower arm G562-11. G12-2 Rev. 0.0.2...
- Page 5 G56-039 using 2 HW004 M3x10mm Hex button screw. You have to prepare 2 mirror sets. Install the 2 arm holders using 4 x HW007 M3x8 countersunk screws. Active caster settings. 0 Degrees are default setting. G12-2 Rev. 0.0.2...
- Page 6 Steering hub, make 2 sets Insert the kingpin into the steering hub. Thread portion will be a tight, enlarge a bit the hole with a body reamer and add a drop of oil while treading it into the hub. G12-2 Rev. 0.0.2...
- Page 7 Assemble the FX0061 ball stud using the HW- 003 M3x8 button screw as shown. The dimension shown is a starting point, final refinement will be done while setting the model Make 2 sets G12-2 Rev. 0.0.2...
- Page 8 Bag B Servo Mount Servo is not included, G12-2 need a Mini servo. G12-2 can carry the following servos fixed directly on the chassis: PowerHD M8 Pro Sanwa PSG HR SXR To use other servos, you can use the “bridge” provided, following instructions are meant for this situation.
- Page 9 Motor Pod Bag C NOTE: Before start to assembly the rear end of G12-2, we strongly suggest you, to visit the Fenix Racing Youtube channel and look the “V-link suspension setup” video. Just scan the QR code Also, in our Youtube page, you’ll...
- Page 10 Insert 2 x male ball stud into the V-link F2. Build 2 set of link using 2 x TR15 and 4 FX0037 - short Keep this dimensions. Fix the link over the V- link F2 G12-2 Rev. 0.0.2...
- Page 11 G12-10 brace and fix brace and G12-C using HW029 M3x12 button screws. Tight the screws evenly using an “X” pattern Note: the arrow show a screw that might interfere with some motors/certain gearing. Please check. G12-2 Rev. 0.0.2...
- Page 12 Insert 2 x 0.5mm shims under the link sphere. Not included in the carbon version How about a cup of coffee now? You deserve it! While drinking it, maybe you can also visit our FB pages G12-2 Rev. 0.0.2...
- Page 13 G122-3 Fix the body post using HW003 M3x8 button screw. Fix the FX0061 using HW008 M3x6 button screw. Insert side spring group into the carbon fibre Assembly the M20 V-link1 chassis, using 2 x G12-2 Rev. 0.0.2...
- Page 14 1 x HW001 M3x20 countersunk screw and 1 HW020 M3x15 countersunk screw. Make both sides. Note: Do not tighten fully the screws You can insert 1 x HW003 M3x8 button screw plus 1 HW018 M3 washer Both sides G12-2 Rev. 0.0.2...
- Page 15 Chassis and motor pod must lay flat on the setup board. Take proper time for this setting. Check our channel on Youtube for some explicative video. G12-2 Rev. 0.0.2...
- Page 16 Insert the male stud FX0061-M in the post. Install front body post to the bumper using 2 x HW003 M3x8 button screws. Fix the bumper to the chassis using 2 x HW004 M3 x 10 countersunk screws and M3 Nylocks G12-2 Rev. 0.0.2...
- Page 17 Start assembling the piston . 4 holes . Slide the 3mm shim over the shock shaft. Lubricate and insert the o-ring into the setting ring. Slide the setting ring over the shock body. G12-2 Rev. 0.0.2...
- Page 18 Fill the shock absorber with your favourite oil… A good starting point will be #600 with 4 holes Close the shock absorber with rubber seal, ball joint and cap. Slide the spring and spring holder in position. Blue spring is a good starting point. G12-2 Rev. 0.0.2...
- Page 19 On the left side, slide the FD12-3 4.5mm spacer over the axle, then insert the drive clamp and , fix it with the 2.5mm x 8 screw. Leave a tiny bit of axial play (0.1/0.2mm) G12-2 Rev. 0.0.2...
- Page 20 Fenix G12-2 Tech area G12-2 represent a major breakthrough in the 1/12 class. Nothing comes close to this 1/12 model. We’ve had several drivers developing the car, from Club racers to ETS and Nationals A-main finalist, and we’d like to thank all of them for the time and dedication they put in this project.
- Page 21 Fenix G12-2 As rule of thumb, low to normal grip = A, normal to high = B V-link suspension, has the ability to handle a certain degree of self steering, this can be “phased” or “counter phased” G12-2 Rev. 0.0.2...
- Page 22 Outdoor starting point 45mmpr check temp often during the setup There are a bunch of free app to be downloaded on your smartphone… Check for instance “Gears”, made by Nor-Cal Hobbies, Here you can download "Gears" https://play.google.com/store/apps/details?id=com.seamusoft.gears&hl=it G12-2 Rev. 0.0.2...
- Page 23 Fenix G12-2 Stay in touch with us! Facebook pages… Instagram Twitter Youtube Fenix-Racing Fenix racing shop G12-2 Rev. 0.0.2...
