  • Page 1 Fenix G56.2 Fenix G56.2 July 2023 Rev. 0.2 – G56.2...
  • Page 2 Before building and operating your G56.2, YOU MUST read through all of the operating instructions and instruction manual and fully understand them to get the maximum enjoyment and prevent unnecessary damage. Read carefully and fully understand the instructions before beginning assembly.
  • Page 3 Carbon Nut assembly Read me first!!! --------- --------- G56.2 use this kind of special nut in several places. Just take your time and the result will be great. Those comes already pre-assembled, but is always good to know “how to”, just in case of…...
  • Page 4: Front End

    G562-11 front arm – Fix the sphere holder with the provided O- ring Note: Be sure that the sphere holder fit easily, you might have to enlarge the hole with Make 2 mirror sets. some sandpaper. Rev. 0.2 – G56.2...
  • Page 5 G56-039 . The arrow is toward the front of the car. Secure G56-030 upper arm mount to the G56-039 using 2 HW004 M3x10mm Hex button screw. You have to prepare 2 mirror sets. Rev. 0.2 – G56.2...
  • Page 6 G56-031 arm – G56-033 eyelet- G56-032 turnbuckle G56-037 sphere Make 2 sets Slide the G56-013 front beam into the upper arm mounts, then insert the G56-034 hinge pins and secure them with the HW031 M2x4 screw Rev. 0.2 – G56.2...
  • Page 7 Assemble the FU-FX48 ball stud using the HW- 003 M3x8 button screw as shown. The dimension shown is a starting point, final refinement will be done while setting the model Make 2 sets Rev. 0.2 – G56.2...
  • Page 8 Fenix G56.2 Bag B Servo Holder Servo and servo saver are not included, G56.2 need a low profile servo. Note the dimension of the servo suggested Use the 2 x HW003 M3x8mm button to secure the FX-FU48 to the servo saver.
  • Page 9 HW003 M3x8 button screw Keep the provided 2 x 1.5mm shims and screws for a further step Bag C Motor pod Using 3 x HW012 M3x6 countersunk screw to fix the V- link2 to the motor Rev. 0.2 – G56.2...
  • Page 10 “X” pattern Note 1 G562-201 brace can be used to fix a 30*30mm or 40*40mm fan. Note, according the fan you choose, you might have to add some shims between the brace and the uprights. Rev. 0.2 – G56.2...
  • Page 11 How about a cup of coffee now? You deserve it! And… while you drink your coffee, you can start to familiarize with the V-link setting… Just scan the QR …. Rev. 0.2 – G56.2...
  • Page 12 Assembly the M20 V- link1 to the chassis, using 2 x HW012 M3x6 countersunk screw. Install the FX0061-M in the M20 V-link1 as shown. Rev. 0.2 – G56.2...
  • Page 13 M20 V-Link1 Assemble the FX-FU48 using 1 x HW008 3x6 button screw and the body post using 1 x HW007 button screw The side spring has to be inserted into the M3 Carbon nut Rev. 0.2 – G56.2...
  • Page 14 Check our channel on Youtube for some explicative video. Chassis and motor pod https://www.youtube.com/channel/UCDZqN09hr2EaI7qHCMjUcjQ must lay flat on the setup board. Take the proper time for this setting. Rev. 0.2 – G56.2...
  • Page 15 Install the front post holder over bumper. Fix them using 2 M3 x12 HW026 and 2 M3 Nylock HW027 Install the front end group over the chassis, using 4 M3x10 HW033. Rev. 0.2 – G56.2...
  • Page 16 Install steering turnbuckles as well There are 3 possible position Shorty Lipo: Longitudinal Fully rearward Fully frontward (7mm) difference Use G562-300 to set the proper position. Fix it with 2 x M3x6 HW012 Rev. 0.2 – G56.2...
  • Page 17 The countersunk hole should point to the front of the car, lower face. Longitudinal Lipo Fix 4 FX0054 26mm posts to the chassis using 4 M3x6 HW012 screws Then install the G562-005 shock holder using 4 M3x8 HW008 screws. Fix the FX-FU48 using 1 x M3x6 HW012. Rev. 0.2 – G56.2...
  • Page 18 Note 2 Long lipo (touring) are possible only with low profile servos. There are 2 shock holder options, according your lipo setting. The M20-K7 shock adjuster will be used to adjust the motor pod droop. Rev. 0.2 – G56.2...
  • Page 19 Start assembling the piston . 4 holes . Lubricate and insert the o-ring into the setting ring. Slide the setting ring over the shock body. Lubricate the o-ring and guide ring with shock oil or differential grease Rev. 0.2 – G56.2...
  • Page 20 (short) Fill the shock absorber with your favourite oil… Close the shock absorber with rubber seal, ball joint and cap. Slide the spring and spring holder in position. Blue spring is a good starting point. Rev. 0.2 – G56.2...
  • Page 21 Fenix G56.2 Rev. 0.2 – G56.2...
  • Page 22 Fenix G56.2 Rev. 0.2 – G56.2...
  • Page 23 Slide the left hub HDD4 on the rear axle, leave 0.1-0.2mm of axial play. Clamp it on the axle using 2 x HW008 3x8 button screws Tech area G56.2 allow several different major setting, according their main chassis Rev. 0.2 – G56.2...
  • Page 24 Most of the time, you’ll find a very comfortable setting using A2 or A3 position Of course the 2 connection link must have the same length!!! Here you can see how to set the V-link! As rule of thumb, low to normal grip = A, normal to high = B Rev. 0.2 – G56.2...
  • Page 25 Outdoor starting point 45mmpr check temp often during the setup There are a bunch of free app to be downloaded on your smartphone… Check for instance “Gears”, made by Nor-Cal Hobbies, Here you can download "Gears" https://play.google.com/store/apps/details?id=com.seamusoft.gears&hl=it Rev. 0.2 – G56.2...
