- Page 1 Fenix Team Lotus 49 Fenix Team Lotus type 49 Manual Rev. 0.1 June 2019 Approved and licensed by Classic Team Lotus ltd ww.classicteamlotus.co.uk Rev. 0.1...
- Page 2 We have made every effort to make these instructions as easy to understand as possible. However, if you have any difficulties, problems, or questions, please do not hesitate to contact the Fenix support team at racing@fenixwaterjet.com . Also, please visit our Web site at www.
- Page 3 Fenix Team Lotus 49 Please note. Classique is not the usual rc model car. The assembly procedure, although very simple, is a little unusual, being the body “part” of the car. So, please, read the manual before start the assembly. Body should be painted before the installation.
- Page 4 Fenix Team Lotus 49 Lower body preparation Let’s start with lower part of the body Cut as shown – Open the grey holes Drill grey holes - Open the grey area Rev. 0.1...
- Page 5 Fenix Team Lotus 49 Open the grey rectangle. You might want to paint the lower body this moment. Rev. 0.1...
- Page 6 Fenix Team Lotus 49 Bag A Rev. 0.1...
- Page 7 Fenix Team Lotus 49 Make 2 sets Use 2 x HW0014 Note: Put a drop of oil M2x 6 screws and over the sphere and 1 x FX002 sphere carefully tight the M2x6 screws. The sphere should move easily, but w/o too much play.
- Page 8 Fenix Team Lotus 49 Using 6 x HW008 fix as show the shock holder and the rear brace. Note: Keep the remaining parts from Bag A for a later use. Rev. 0.1...
- Page 9 Fenix Team Lotus 49 Bag B Rev. 0.1...
- Page 10 Fenix Team Lotus 49 Using 4 HW M3 x 10 (from bag A) fix the T-bar group main chassis. On the front pivot use the HW027 M3 nut and on the rear pivot FX1045 10mm posts. Take the main chassis and the lower body, align the holes.
- Page 11 Fenix Team Lotus 49 Tight the M4 self- locking – Note: Almost full, screw should be able to rotate a little Assembly bumper with the M3 x 10mm countersunk screws Tight the 2 M3 self-locking nuts FX0053 posts Make 2 sets as Note: show.
- Page 12 Fenix Team Lotus 49 special attention when “thread” the grub screw in the carbon fibre, lubricate the grub screw often during operation insert it slowly. Insert the FUFX48 and fix it with 1 x HW008 M3x6 button screw Slide the HS7 rear...
- Page 13 Fenix Team Lotus 49 Using 1 x HW0012 fix the FUFX48 at the HS5 central shock holder. Use 2 HW008 M3 x 8 button screw to fix this group to the FX0054 Battery installation. This model can use only “Super shorty lipo pack”...
- Page 14 Fenix Team Lotus 49 Slide the 2 x HW021 M4 x 35 HW024 M3 x 25 through the lower body chassis. Insert the 51381 lower arms over the screws. Slide the 51381 spacer and the central element 51831 over the HW021 screws.
- Page 15 Fenix Team Lotus 49 Fix 2 x FX1045 over the HW026 screws and slide 2 x FX02009 2mm alu shims over the HW024. Take servo holder. Note: the flat area goes to the front of the model Insert profile servo (not included) in the servo holder.
- Page 16 Fenix Team Lotus 49 Insert 4 x HW032 M3 x 10 grub screw as shown. Leave them protrude for 5mm Fix and tight 4 x FUFX48 over the protrudring part of the HW032 Insert 2 x HW003 into servo saver and screw 2 x FUFX48.
- Page 17 Fenix Team Lotus 49 Insert, as shown, plastic spheres in the arms. Using 1 x HW003 fix 1 FUFX48. Put the plastic shims upper area, the alu shim in the lower portion. Make 2 set mirror like. Steering hubs. Use 1 x HW0014...
- Page 18 Fenix Team Lotus 49 Make 2 sets Install the assembled rods over the FUFX48. You can set the required toe after the proper radio settings. Rev. 0.1...
- Page 19 Fenix Team Lotus 49 Rev. 0.1...
- Page 20 Fenix Team Lotus 49 Rev. 0.1...
- Page 21 Fenix Team Lotus 49 Insert the left wheel hub over the differential axle and secure it with 2 x HW003 Cut the upper part of the body as show. Open the side grey holes and front ones. Front ones should be about Ø...
- Page 22 Fenix Team Lotus 49 Cut the nosecone as show Using the dimples as reference drill 4 by Ø 3mm Fixing the nose cone. Using 4 by M3x6 button screw, fix the nose cone to the upper body. 1 - Slide the upper...
- Page 23 Fenix Team Lotus 49 Typical electrical layout Optional parts: You can futher improve the look of your Classic Team Lotus 49, installing the optional Classique Velocity stacks, alluminium machined Cpn HS11 Rev. 0.1...
