KIWI/CLOVER
User Guide
Document Type:
Document Number:
Document Issue:
Document Status:
Product Name:
Product Code:
Issue Date:
PROPRIETARY:
The information contained in this document is the property of TEKTELIC Communications Inc. Except as specifically
authorized in writing by TEKTELIC, the holder of this document shall keep all information contained herein
confidential, and shall protect the same in whole or in part from disclosure to all third parties.
© 2023 TEKTELIC Communications Inc., all rights reserved.
All products, names, and services are trademarks and registered trademarks of their respective companies.
TEKTELIC Communications Inc.
th
7657 10
Street NE
Calgary, AB, Canada T2E 8X2
Phone: (403) 338-6900
AGRICULTURE SENSOR
User Guide
T0005978_UG
2.1
Release
KIWI/CLOVER Agricultural Sensor
T0005982 (Agricultural Sensor, CLOVER Module, LoRa)
T0005986 (Agriculture Sensor, KIWI Module, LoRa)
November 16, 2023
