3 x lamp emitter heater, canada & usa models, weatherproof infrared heaters suitable for outdoor and indoor use - commercial and industrial, residential 240v outdoor use only in non-hazardous areas, 240v-3375w/4500w / 277v-4500w/6000w, candel low light
1 x lamp emitter heater, canada & usa models, weatherproof infrared heaters suitable for outdoor and indoor use - commercial and industrial, residential 240v outdoor use only in non-hazardous areas, 240v-1125w/1500w / 277v-1500w/2000w, candel low light (18 pages)
Standard/stainless steel frontage/fascia heater models for canada & usa, weatherproof infrared heaters suitable for outdoor and indoor use - commercial and industrial, residential 240v outdoor use only in non-hazardous areas, 240v-1125w/1500w / 277v-1500w (14 pages)
Standard/stainless steel frontage/fascia heater models for canada & usa, weatherproof infrared heaters suitable for outdoor and indoor use - commercial and industrial, (residential 240v outdoor use only in non-hazardous areas, 208v-2 x 1125w/1500w 2250w/3 (12 pages)
Standard/stainless steel frontage/fascia heater models for canada & usa, weatherproof infrared heaters suitable for outdoor and indoor use - residential, commercial and industrial in non-hazardous locations, 208v-1125w/1500w / 240v-1500w/2000w (12 pages)
Page 2
I M P O R TA N T I N S T R U C T I O N S When using electrical INFRARED HEATERS, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1.
Page 3
I M P O R TA N T I N S T R U C T I O N S 8. Do not insert or allow foreign objects to enter any opening as this may cause an electric shock or fire, or damage the heater. 9.
Page 4
It is mounted on an adjustable bracket that allows the heat to be directed exactly where it is required. The Alpha H3 can also be used in a modular system in that more than one heater can be connected together - see ‘Configurations’ later in the manual.
Page 6
C O N F I G U R AT I O N S The Alpha H3 heater contains three lamp emitters. It can be installed as a single unit or joined to one other single unit with joining bars that are available to connect the heaters together and increase the size and output of the installation.
Page 7
Always allow the heater to cool before attempting to Fig. B reposition/move. Never attempt to move the heater while it is switched on! Observe the minimum safe distance between the heater SEE SPEC. body and inflammable surfaces and objects when Fig.
Page 8
C AU T I O N Always isolate the heater from the mains supply when mounting or adjusting the heater position. When two Alpha H3 heaters are joined they should only be hung from a ceiling on chains - do not wall mount! Always allow the heater to cool before attempting to reposition/move.
Page 9
Fix the heater assembly to the chains via the hole in the centre of the joining bar as shown in Fig. E. and ensure the heaters face directly down when hanging. Secure the supply cable so it is not resting on the body or obstructing the air-vents. Always isolate the heater from the mains supply when adjusting the position.
Page 10
M AI N T E N A N C E ( 2 7 7 V C I R C U I T ) NOTE: For replacement lamp emitters or spare parts please contact your local distributor quoting model type and rating from rating label. It is very important that your replacement lamp emitters are exactly the same as the one it was supplied with.
Page 12
R E P L A C I N G A L A M P E M I T T E R C AU T I O N Disconnect from the mains power before any attempts are made to replace the lamp emitter.
Page 13
6. At the front of the heater, remove the screws from the grille tabs at both sides of the grille as shown in Fig. N (taking care to retain the spring washers) then remove the grille by pulling it out from the centre and prizing the prongs away from their locating holes at one end (Fig.
Page 14
Fig. R Fig. S 10. The lamp emitter can now be removed away from the heater leaving it ready for the new lamp emitter to be fitted as shown in Fig. T. Fig. T 11. Refit the new lamp emitter in reverse order making sure that no wires can get trapped.
Page 15
13. When fitting the middle grille, insert the 2 × prongs into the holes in the grille holder (Fig. W) and gently flex the grille to insert the 2 × opposite prongs into the opposite grille holder holes as shown in Fig. X. Fig.
