ICR Series H2
STANDARD
&
SICR30240-C
&
SICR40240-C
&
C = COLOR CODE
INFORESIGHT CONSUMER PRODUCTS INC.
125 Traders Blvd. E Unit # 4, Mississauga, Ontario L4Z 2H3
Email: info@solairaheaters.com - Website: www.solairaheaters.com
I M P O R TA N T - S AV E T H E S E I N S T R U C T I O N S F O R F U T U R E R E F E R E N C E
Reference Manual
Solaira
DOUBLE EMITTER
CANADA & USA MODELS:
CANDEL
SICR30240LL-C
SICR40240LL-C
SHORTWAVE INFRARED HEATERS FOR
OUTDOOR AND INDOOR USE -
COMMERCIAL AND INDUSTRIAL
247748
Tel: 905-568-7655 - Fax: 905-568-7521
2250 / 3000W, 208 / 240V (SINGLE PHASE)
3000 / 4000W, 208 / 240V (SINGLE PHASE)
Advertisement
Related Manuals for Solaira ICR Series
Summary of Contents for Solaira ICR Series
- Page 1 Reference Manual Solaira ICR Series H2 DOUBLE EMITTER CANADA & USA MODELS: STANDARD & CANDEL SICR30240-C & SICR30240LL-C 2250 / 3000W, 208 / 240V (SINGLE PHASE) SICR40240-C & SICR40240LL-C 3000 / 4000W, 208 / 240V (SINGLE PHASE) C = COLOR CODE...
- Page 2 I M P O R TA N T I N S T R U C T I O N S I M P O R TA N T I N S T R U C T I O N S I M P O R TA N T I N S T R U C T I O N S I M P O R TA N T I N S T R U C T I O N S When using electrical INFRARED HEATERS, basic precautions...
- Page 3 I M P O R TA N T I N S T RU C T I O N S I M P O R TA N T I N S T RU C T I O N S I M P O R TA N T I N S T RU C T I O N S I M P O R TA N T I N S T RU C T I O N S 10.
- Page 4 The Solaira ICR Series H2 heater produces radiant heat like the sun, warming people and objects rather than the air in between. It is mounted on an adjustable bracket that allows the heat to be directed exactly where it is required. The Solaira ICR Series H2 heater is designed for outdoor and indoor use.
- Page 5 S P E C I F I C AT I O N T a b l e 1 . C a n a d a a n d U S A H e a t e r s SICR30240-C & SICR40240-C &...
- Page 6 M O U N T I N G - WA L L M O U N T E D C A U T I O N C A U T I O N C A U T I O N C A U T I O N Switch off/unplug the heater from the mains supply when mounting or adjusting the heater position.
- Page 7 FIXING BOLTS Securely fasten the L-shaped wall brackets to the mounting surface as shown in Fig. B (for wall mounting) Fig. (for overhead mounting). Refer to the mounted bracket hole centres detail in Fig. D. See Table 1 for recommended positioning of the heater. NOTE: WALL FIXINGS ARE NOT SUPPLIED.
- Page 8 M O U N T I N G - C H A I N H U N G C A U T I O N C A U T I O N C A U T I O N C A U T I O N Switch off/unplug the heater from the mains supply when mounting or adjusting the heater position.
- Page 9 M O U N T I N G - C E I L I N G R E C E S S E D C A U T I O N C A U T I O N C A U T I O N C A U T I O N Switch off/unplug the heater from the mains supply when mounting or adjusting the heater position.
-
Page 10: Typical Installation
DIMENSIONS OF FLANGE TRIM FOR ENCLOSURE BOX Fig. L KIT OF 4 × SIDES SHOWN AS ASSEMBLED TYPICAL INSTALLATION Fig. M... - Page 11 M AI N T E N A N C E In the event of heater failure or for spare parts or advice, please contact your service agent. CAUTION: Unplug/switch off unit from the mains supply before replacing an emitter or any maintenance procedure including cleaning.
- Page 12 R E P L A C I N G T H E E M I T T E R C A U T I O N C A U T I O N C A U T I O N C A U T I O N Unplug/switch off from the mains power to the heater power before any attempts are made to replace an emitter.
- Page 13 MALE CONNECTOR FROM EMITTER WIRE FEMALE CONNECTOR FROM LIVE SUPPLY Fig. T Fig. U Fig. S 5. Remove the emitter holding clips (Fig. V) by squeezing the clip together and lifting away as shown in Fig. W. 6. Slide the emitter out through the extrusion feeding one way first with the wire and then the opposite way to take out and remove.
- Page 14 Solaira ICR Series H2 SHORTWAVE INFRARED HEATERS FOR OUTDOOR AND INDOOR USE - COMMERCIAL AND INDUSTRIAL I M POR TANT - SAV E T H ES E I N STR UCT ION S FOR FU TU RE R EF E RE NC E 247748 CAN/CSA-C22.2 No.
