iTrans USB3-TR100
USB 3.0 Extender (100M)
User Manual V1.2
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully before
connecting, operating, or adjusting this product. Please keep this manual for future
reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical
spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is
highly recommended to protect and extend the life of your equipment.
Caution
The product requires the use of UTP connectors. Please connect in direct
interconnection method and do not cross connect.
INFOBIT AV
www.infobitav.com
info@infobitav.com
Advertisement
Related Manuals for infobit iTrans USB3-TR100
Summary of Contents for infobit iTrans USB3-TR100
- Page 1 USB3-TR100 USB 3.0 Extender (100M) User Manual V1.2 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating, or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.
- Page 2 ☆ Simple plug and play, no driver and setting installation required 3. Package Contents ① 1× USB 3.0 Extender (Transmitter) ② 1× USB 3.0 Extender (Receiver) ③ 1× 24V/2A Locking Power Supply ④ 2× 4pin-3.5mm Phoenix Connector (Male) INFOBIT AV www.infobitav.com info@infobitav.com...
- Page 3 ⑤ 4× Mounting Ear ⑥ 8× Machine Screw (KM3*4) ⑦ 1× User Manual 4. Spec Model iTrans USB3-TR100 Name USB 3.0 Extender (100M) USB Protocol USB 3.0 Transmission Rate Up to 5Gbps Network Bandwidth Transmission 100m/328ft over CAT6a (F/FTP) cable...
- Page 4 The default level is 3.3V. Firmware update port. 7 SERVICE 8 POWER The LED will be on when the Transmitter is powered on. 9 DC 24V DC 24V/2A power input port. 5.2. Receiver INFOBIT AV www.infobitav.com info@infobitav.com...
- Page 5 FSYNC port, receiving level pass-through from the Transmitter, and FSYNC synchronizing the external devices. Default level is 3.3V. SERVICE Firmware update port. POWER LED The LED will be on when the Receiver is powered on. DC 24V DC 24V/2A power input port. 6. Diagram INFOBIT AV www.infobitav.com info@infobitav.com...
- Page 6 INFOBIT AV www.infobitav.com info@infobitav.com...
