- Page 1 HDMI Video Transmitter over Cat5 Cable – 50m to 250m # 542 Operation Manual...
- Page 2 Introduction HDMI Video Transmitter over Cat5 Cable - 50m to 250m is the transmitter (Tx) unit of HDMI over CAT5 Tx/Rx solution, depends on the type of receiver (Rx) unit used, HDMI Video Transmitter over Cat5 Cable - 50m to 250m can extend HDMI signal through CAT-5 cables for a distance up to 50/100/150/250 meters.
- Page 3 1. VIDEO OUTPUT: Connect the VIDEO output to the VIDEO input of the receiver unit using CAT-5/CAT-5E/CAT-6 cable. 2. DDC OUTPUT: Connect the DDC output to the DDC input of the receiver unit using CAT-5/CAT-5E/CAT-6 cable. Note: For advanced user only, if it's known that the DDC or HDCP data are not required for the source and the display, you can use a single CAT-5 cable to connect the VIDEO ports of transmitter and receiver.
- Page 4 Connection and Installation ID #542...
