- Page 1 Electric Folding Treadmill 1608-2 Thank you very much for purchasing our product. Please read this manual carefully before useing it and keep the manual at the proper place .
- Page 2 As shoppers, we're always trying to find the perfect balance between quality & value. At FYC, we believe we've achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality &...
-
Page 3: Safety Notice
CAUTION To avoid injury please read this manual carefully before operating this machine For safety , do not stand on the running belt while starting. Ÿ Please stop using immediately if you feel vomiting or jerky during using. Ÿ Please speed up slowly if needed. Ÿ... -
Page 4: Caution During Use
CAUTION DURING USE Keep both the machine and power cord away from heated surfaces. If you do not feel well before using, please consult your doctor or coach. Ÿ Please unplug the equipment when not in use. Ÿ Please unplug the treadmill before cleaning, moving or change parts for the treadmill. Ÿ... -
Page 5: Tools Required
TOOLS REQUIRED ALLEN WRENCH SILICONE OIL SAPNNER (PROVIDED) (PROVIDED) (PROVIDED) HARDWARE Safety Key Round Washer Arc Washers 1 PCS 2 PCS 2 PCS Lock Knob Short Bolt Fixed Knob Stretch Knob 1 PCS 4 PCS 2 PCS 1 PCS PRODUCTS MAIN PARTS Cup Holder 1、... - Page 6 PARTS PARTS RUNNINGDECK DESK PARTS PRODUCT ASSEMBLY Take the treadmill and spare parts bag out from the box, and place them on the floor.
- Page 7 PARTS PRODUCT ASSEMBLY Unsrew the preset bolts & nuts at the top of tubes. Attach the desk to the tubes, use the preset bolts & nuts to fix the desk to the tubes.
- Page 8 PARTS PRODUCT ASSEMBLY Lift up the whole panel. Use Short Bolt (Part 6) & Arc Washers (Part 3) to fix the front side of the tubes; use Short Bolt (Part 6) & Round Washers (Part 2) to fix the left/right side of the tubes. Check if the connecting wire cable is in good condition and connected well.
- Page 9 PARTS PRODUCT ASSEMBLY Lay down the desk, use Fixed Knob (part 7) to fix the desk with tubes. Use Lock Knob (Part 4) to fix the desk to the tubes. Screw in Stretch Knob (Part 5). Put the safety key and the assembly is finished.
- Page 10 PARTS PRODUCT ASSEMBLY Lift the pad holder, and lift the clip at the back of pad holder, you can adjust the angle of pad holder.
-
Page 11: Folding Up And Setting Down
Unscrew the Lock Knob (Part 4) on the base frame. Lift the base frame to the place where the Stretch Knob (Part 5) can put in to fix the base frame. FOLDING UP AND SETTING DOWN Product name JK1608-2 Voltage 110V Frequency... - Page 12 PARTS CONSOLE INSTRUCTON Check that the red power switch on the back of the machine is turned off. The power supply socket should be turned off at the wall, then insert the power cable into the socket. Turn on the power supply at the wall and turn on the red power switch at the back of the machine.
- Page 13 TOTAL 12 PROGRAMS AS BELOW When machine is in standby status, press this" "key to select P1-P12." Then press " "key: the machine will run at the selected program. When program is selected, the default time value is 30 minutes. User can press "+"or "-"key to increase or decrease the time.
- Page 14 PARTS REMOTE CONTROL INSTRUCTION 1. Function of the Remote Control 2.1 "Start/Stop": (1) In standby or countdown mode: Press" " button to start themachine. Please note that the default speed is 0.5MPH. Choose the preset program: Press " " to choose P1-P12, andthen press " " to start the machine, the speed will changeaccording to the preset speed.
-
Page 15: About The Remote Control
" ": Press the " " button, the data will be reset to its default data. It only works when the treadmill is in standby mode. ABOUT THE REMOTE CONTROL 3.1 Pull out the insulating sheet, you can use the remote control directly. 3.2 The remote control can directly control the treadmill. - Page 16 PARTS USAGE OF SILICONE OIL Foryourconvenience,youcanscanthisQRcodetoseethevideofor lubricatingtherunningbeltonYouTube,orinputthislinktowatch. https://youtu.be/MksJIoi8Obo PARTS RUNNING BELT ADJUSTMENT After installation video tutorial RUNNING BELT SKEWS TO THE LEFT Then make the machine running without loading 1-2 minutes.Please Please adjust the belt like this to the middle position. RUNNING BELT SKEWS TO THE RIGHT Please adjust the belt like this to the middle position.
- Page 17 RUNNING BELT DEVIATE TO LEFT Foryourconvenience,youcanscanthisQRcodetoseethevideoon YouTube,orinputthislinktowatch. https://youtu.be/uoXqZXk1Bx8 RUNNING BELT DEVIATE TO RIGHT Foryourconvenience,youcanscanthisQRcodetoseethevideo onYouTube,orinputthislinktowatch. https://youtu.be/LGKKCk-yivM RUNNING BELT LOGJAM Foryourconvenience,youcanscanthisQRcodetosee thevideoonYouTube,orinputthislinktowatch. STEP1:https://youtu.be/Xqri9ug5J7c STEP2:https://youtu.be/nyZ75WFTZZw （STEP1） （STEP2） PARTS DAILY MAINTENANCE 1. Please disconnect power before checking the machine or cleaning. 2.
- Page 18 PARTS EXERCISE GUIDE Before beginning any exercise program, consult your physician. PLEASE NOTE: This is important especially if you are over the age of 45 or individuals with pre-existing health problem. Warm-up Start each workout with 5 to 10 minutes of stretching and some light exercises.
- Page 19 HEART RATE MAXIMUM COOL DOWN THIS IS HOW YOUR PULSE SHOULD BEHAVE DURING GENERAL FITNESS EXERCISE. REMEMBER TO WARM UP AND COOL DOWN FOR A FEW MINUTES The most important factor here is the amount of effort you put in. The harder and longer you work the more calories you will burn.
- Page 20 PARTS TROUBLE SHOOTING Nosafetykeyonthepanel Putthesafetykeyonthepanel. Connectingwirecableloose/damage Removethemotorcoverandch eckalltheconnectingwirecable. fromthecontrolboard Nosafetykeyonthepanel Putthesafetykeyonthepanel. ------ Removethemotorcoverandchec Connectingwirecableloose/damage kalltheconnectingwirecable. fromthecontrolboard Pleaselubricatetherunningbelt andcheckifthemotorworkswell. OverloadProtection MotororControlBoarddamaged, pleasereplaceit. Checkwhetherthemotorwireis damagedorbroken. MOSProtection Replacethecontrolboard. Removethemotorcoverandcheck Connectingwirecableloose/damage alltheconnectingwirecable. fromthecontrolboard Electricmotordamage/broken Replacethemotor. Connectingwirecableloose/damage Removethemotorcoverandcheck alltheconnectingwirecable. fromthecontrolboard If you are not sure about how to do that, please contact our customer service and we will provide the best solution for you.
-
Page 22: Warranty
February 24, 2018 Great product so far. Fast delivery, easy setup, and working without any issues. With your inspiring rating, FYC will be more consistent to offer you EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE! If you have any issues with your orders, logistics, items, etc, please contact us bythe following way.
