Summary of Contents for FYC JK30F-9
- Page 1 UNDER DESK TREADMILL JK30F-9 Thank you very much for purchasing our product. Please read this manual carefully before useing it and keep the manual at the proper place .
- Page 2 As shoppers, we're always trying to find the perfect balance between quality & value. At FYC, we believe we've achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality &...
-
Page 3: Safety Notice
CAUTION To avoid injury please read this manual carefully before operating this machine NEVER attempt to mount the treadmill while the running belt is moving. Ÿ NEVER step off the treadmill while the running belt is moving. Ÿ NEVER operate the treadmill if it is damaged or is not working as it should be. Ÿ... -
Page 4: Caution During Use
CAUTION DURING USE Keep both the machine and power cord away from heated surfaces. Make sure you are wearing proper exercise clothing and shoes during a workout—no loose Ÿ clothing. Tie back long hair. Keep all loose towels away from the running surface. The running belt will not stop immediately if an object becomes caught in the belt or rollers. -
Page 5: Tools Required
TOOLS REQUIRED DO NOT ALLEN WRENCH SILICONE OIL NEED TO INSTALL (PROVIDED) (PROVIDED) This product is free of installation, home office can be used PRODUCTS MAIN PARTS Display 1、 Running Belt 2、 Side Rail 3、 End-Cap 4、... -
Page 6: Folding Up And Setting Down
FOLDING UP AND SETTING DOWN Product name JK30F-9 Voltage 110V Frequency 50-60Hz Speed 0.5-4MPH BLUETOOTH SETUP Bluetooth Bluetooth... - Page 7 CONSOLE INSTRUCTON PARTS (1). Display has two modes which shows the running time. 1.1 "TIME" window Forward counting time is from 0:00 to 99:59 minutes. Countdown is count to 0 from the set time (setting range: 5:00-99:00 minutes). The machine will stop slowly when it counts to 0:00 and shows "end", then the machine will come to the standby mode after 5 seconds.
- Page 8 Functional Instruction 1. Sports mode: Press " " key to start the machine and the SPEED window will count from "3 2 1". Please note that the default speed is 0.5 MPH and you can press "+" or "-" to adjust speed. 2.
- Page 9 PARTS REMOTE CONTROL INSTRUCTION 1. Function of the Remote Control (1) In standby or countdown mode: Pressing" "button to start the machine. Pleasenote that the default speed is 0.5MPH. (2) Choose the preset program: Pressing " "to start the machine and the speed will changes according to the preset speed.
-
Page 10: About The Remote Control
Press the " " button, the data will be reset to its default data. It only works when the treadmill is in standby mode. ABOUT THE REMOTE CONTROL 3.1 Pull out the insulating sheet, you can use the remote control directly. 3.2 The remote control can directly control the treadmill. - Page 11 PARTS USAGE OF SILICONE OIL Foryourconvenience,youcanscanthisQRcodetoseethevideofor lubricatingtherunningbeltonYouTube,orinputthislinktowatch. https://youtu.be/MksJIoi8Obo PARTS RUNNING BELT ADJUSTMENT After installation video tutorial RUNNING BELT SKEWS TO THE LEFT Then make the machine running without loading 1-2 minutes.Please Please adjust the belt like this to the middle position. RUNNING BELT SKEWS TO THE RIGHT Please adjust the belt like this to the middle position.
- Page 12 RUNNING BELT DEVIATE TO LEFT Foryourconvenience,youcanscanthisQRcodetoseethevideoon YouTube,orinputthislinktowatch. https://youtu.be/uoXqZXk1Bx8 RUNNING BELT DEVIATE TO RIGHT Foryourconvenience,youcanscanthisQRcodetoseethevideo onYouTube,orinputthislinktowatch. https://youtu.be/LGKKCk-yivM RUNNING BELT LOGJAM Foryourconvenience,youcanscanthisQRcodetosee thevideoonYouTube,orinputthislinktowatch. STEP1:https://youtu.be/Xqri9ug5J7c STEP2:https://youtu.be/nyZ75WFTZZw （STEP1） （STEP2） PARTS DAILY MAINTENANCE 1. Please disconnect power before checking the machine or cleaning. 2.
- Page 13 PARTS EXERCISE GUIDE Before beginning any exercise program, consult your physician. PLEASE NOTE: This is important especially if you are over the age of 45 or individuals with pre-existing health problem. Warm-up Start each workout with 5 to 10 minutes of stretching and some light exercises.
- Page 14 HEART RATE MAXIMUM COOL DOWN THIS IS HOW YOUR PULSE SHOULD BEHAVE DURING GENERAL FITNESS EXERCISE. REMEMBER TO WARM UP AND COOL DOWN FOR A FEW MINUTES The most important factor here is the amount of effort you put in. The harder and longer you work the more calories you will burn.
- Page 17 PARTS TROUBLE SHOOTING Connectingwirecableloose/damage Removethemotorcoverandch eckalltheconnectingwirecable fromthecontrolboard Removethemotorcoverandchec Connectingwirecableloose/damage ------ kalltheconnectingwirecable fromthecontrolboard Pleaselubricatetherunningbelt andcheckifthemotorworkswell OverloadProtection MotororControlBoarddamaged, pleasereplaceit Checkwhetherthemotorwireis damagedorbroken MOSProtection Replacethecontrolboard Removethemotorcoverandcheck Connectingwirecableloose/damage alltheconnectingwirecable fromthecontrolboard Electricmotordamage/broken Replacethemotor Removethemotorcoverandcheck Connectingwirecableloose/damage fromthecontrolboard alltheconnectingwirecable...
-
Page 18: Warranty
February 24, 2018 Great product so far. Fast delivery, easy setup, and working without any issues. With your inspiring rating, FYC will be more consistent to offer you EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE! If you have any issues with your orders, logistics, items, etc, please contact us bythe following way.
