SUMAKE
Specification:
Free Speed
Bolt Size Capacity
Max. Torque
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
Air Impact Screwdriver
(Side Exhaust), Twin Hammer
8,500 r/min
9 – 10 mm
200 ft-lb (270 N-m)
8.5 CFM (240 L/min)
6.1" (155 mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
3.0 lbs (1.5 kg)
PNEUMATIC TOOLS
ST-4464
Noise and Vibration:
Vibration
EN ISO 28927-2
No Load:
1.5 m/s²
Uncertainty
K= 1.35 m/s
Noise
EN ISO 15744
Sound Pressure Level
No load: 75 dB(A)
Sound power level
No load: 86 dB(A)
Uncertainty
²
K= 3dB
ST-4464-S-1411D-OPF
Remark
Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
hearing!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sumake ST-4464
Summary of Contents for Sumake ST-4464
- Page 1 3/8” (10 mm) Air Hose (I.D.) risk of impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! ² K= 1.35 m/s K= 3dB Net Weight 3.0 lbs (1.5 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-4464-S-1411D-OPF...
- Page 2 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： AIR IMPACT SCREWDRIVER (SIDE EXHAUST), TWIN HAMMER Model/ Serial No.：ST-4464 to which this declaration applies, complies with these normative documents: ...
- Page 3 Clean the hose with a blast of compressed air Maintenance Sumake is a manufacturer and exporter of air failure or emitted from the workpiece. before connecting the hose to air tool. This will tools since established.
- Page 4 ST-4464 AIR IMPACT SCREWDRIVER (SIDE EXHAUST) (TWIN HAMMER) PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty 4464-01 Retaining Ring 4464-22 Rotor Blade 4464-02 Washer 4464-23 Rear Plate 4464-03 Spring 4464-24 Ball Bearing (R6) 4464-04 Bushing 4464-25 Hook 4464-05...
- Page 5 SCREWDRIVER Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 2. While using an assembly power tool for threaded fasteners, the operator should adopt a comfortable posture whilst maintaining secure footing and avoiding awkward or off-balanced postures. The operator should change posture during extended tasks, which can help avoid discomfort and fatigue. 3.
- Page 8 General preparation and connection: When using brand-new air hose or air pipe. Blow and clean the inside of air hose or pipe before installation. Keep inside of air hose or air pipe clean to prevent airdrop problem caused by the lots of drain and dust accumulated and possibly make the inside diameter smaller in the long use.
