Sumake ST-SD151 Manual

Ind. air stall pistol grip screwdriver

Advertisement

Quick Links

SUMAKE
Ind. Air Stall Pistol Grip Screwdriver

Specification:

Free Speed
Motor
Torque Range
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
ST-SD151
1,400 r/min
1.0HP
106in-lbs(12Nm)
14 CFM (396 L/min)
8-1/4" (210 mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
2.2 lbs (1.0 kg)
Noise and Vibration:
Vibration
EN ISO 28927-2
Sound Pressure Level
No Load:
<2.5 m/s²
Uncertainty
²
K= 1.5 m/s
Noise
EN ISO 15744
Please always
load: 84 dB(A)
Sound power level
environment
load: 95 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
K= 3dB
ST-SD151-S-2203A-D5F
Remark
wear ear
protector at
hearing!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST-SD151 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sumake ST-SD151

  • Page 1 Air Hose (I.D.) risk of impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! ² K= 1.5 m/s K= 3dB Net Weight 2.2 lbs (1.0 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-SD151-S-2203A-D5F...
  • Page 2 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment: IND. AIR STALL PISTOL GRIP SCREWDRIVER Model/ Serial No.: ST-SD151 to which this declaration applies, complies with these normative documents: ...
  • Page 3 Maintenance Clean the hose with a blast of compressed air Sumake is a manufacturer and exporter of air failure or emitted from the workpiece. before connecting the hose to air tool. This will tools since established.
  • Page 4 ST-SD151 IND. AIR STALL PISTOL GRIP SCREWDRIVER PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty SD151-01 Retainer Ring M5213R-25 Reverseing Manifold SD151-02 Washer M5213R-26A O-Ring SD151-03 Spring M5213R-27 Housing SD151-04 Ball Retainer M5213R-28 Trigger SD151-05 Spindle M5213R-29 Trigger Sleeve...
  • Page 5 SCREWDRIVER Original instructions SUMAKE Industrial Co. Ltd.
  • Page 6 Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
  • Page 7 2. While using an assembly power tool for threaded fasteners, the operator should adopt a comfortable posture whilst maintaining secure footing and avoiding awkward or off-balanced postures. The operator should change posture during extended tasks, which can help avoid discomfort and fatigue. 3.
  • Page 8 General preparation and connection: When using brand-new air hose or air pipe. Blow and clean the inside of air hose or pipe before installation. Keep inside of air hose or air pipe clean to prevent airdrop problem caused by the lots of drain and dust accumulated and possibly make the inside diameter smaller in the long use.
