INSTALLATION AND OPERATING INSTRUCTIONS
Please read this book thoroughly and familiarise yourself with all instructions before commencing
installation and keep it for future reference.
The mixer shower installation MUST be carried out by a suitably qualified person, in the sequence
of this instruction book.
IMPORTANT SAFETY ADVICE
The shower head and hose supplied with
this product are a safety critical part of your
shower. Failure to use genuine Triton parts may
cause injury and invalidate your guarantee.
2181681B - August 2023
86006260

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VELINO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Triton VELINO

  • Page 1 (FROM THE LABEL ON THE FRONT OR TOP OF THE BOX) this product are a safety critical part of your shower. Failure to use genuine Triton parts may cause injury and invalidate your guarantee. ALTERNATIVELY REGISTER BY TEL: 024 7637 8321...
  • Page 2: Table Of Contents

    FAULT FINDING ................16 - 17 GUARANTEE, SERVICE POLICY, ETC.......... rear cover nstallers please note these InstructIons are to be left wIth the user To check the product suitability for commercial and multiple installations, please contact Triton’s speci cation advisory service before installation. Telephone:...
  • Page 3: Dimensions & Main Components

    Bar Mixer Shower DIMENSIONS - All dimensions regarding the product and installation are approximate. 305mm A. Bar mixer valve B. Wall brackets C. Compression brackets...
  • Page 4: Introduction & Site Requirements

    Bar Mixer Shower INTRODUCTION Water Minimum Flow Rate For best performance within the specified running This book contains all the necessary fitting and pressure range a minimum flow of 8 litres per operating instructions for your mixer shower. minute should be available to both inlets. Please read them carefully and read through the whole of this book before beginning your installation.
  • Page 5 Bar Mixer Shower PLUMBING REQUIREMENTS Hard Water Areas a. If it is intended to operate the shower DO NOT use jointing compounds on any pipe in areas of hard water (above 200-ppm fittings for the installation. temporary hardness), a scale inhibitor DO NOT solder fittings near the mixer shower may have to be fitted.
  • Page 6: Typical Domestic Installations

    Bar Mixer Shower TYPICAL DOMESTIC INSTALLATIONS *Diagrammatic view – not to scale. *Fig.1 For illustration purposes only. Domestic Gravity Fed Systems ( fig.1) The mixer shower MUST be fed from a cold water cistern and hot water cylinder providing nominally equal pressures. There MUST be Stop valve a minimum of one metre head of water.
  • Page 7 Bar Mixer Shower Instantaneous Gas-heated Systems, *Diagrammatic view – not to scale. *Fig.3 e.g. combination boilers (fig.3) For illustration purposes only. The mixer shower MUST be installed with a multi-point gas water heater or combination boiler of a fully modulating design i.e. to maintain relatively stable hot water temperatures.
  • Page 8 Bar Mixer Shower Mains Pressurised Thermal Store Systems *Fig.5 *Diagrammatic view – not to scale. fig.5) For illustration purposes only. Packages of this type, fitted with a tempering valve (blender valve), can be used. A drop tight pressure reducing valve MUST be fitted if the supply pressures exceed 5 bar running.
  • Page 9: Preparing The Shower

    Bar Mixer Shower INSTALLATION *Fig.6 *Diagrammatic view – not to scale. For illustration purposes only. PREPARING THE SHOWER Check the contents to make sure all parts are present. Before starting the installation, make sure all the openings on the valve are carefully covered to stop ingress of any debris etc.
  • Page 10: Fitting The Shower

    Bar Mixer Shower FITTING THE SHOWER Fig.8 Offer the shower to the brackets, check that the sealing washers are in place, and carefully tighten the nuts. Care must be taken not to damage the chrome plated surface (fig.8). OPERATING THE SHOWER Fig.9 FLOW CONTROL - fig.9...
  • Page 11: Commissioning

    If, however, the temperature is above 43°C then it is likely there is contamination in the mixer shower stopping it from shutting off the hot supply. In this case refer to the maintenance section or contact Triton Customer Experience.
  • Page 12: Temperature Adjustment

    Bar Mixer Shower TEMPERATURE ADJUSTMENT Fig.12 Important Adjusting the Maximum Temperature Override Setting The mixer shower has a temperature stop to prevent accidental rotation to higher Remove the temperature control by removing temperatures. This is adjustable to provide a the end cap then unscrewing the retaining screw maximum temperature of 35°C –...
  • Page 13: Tmv2 Requirements (12 Monthly Verification)

    Bar Mixer Shower TMV2 REQUIREMENTS (12 MONTHLY VERIFICATION) It is a requirement that all TMV2 approved valves shall be verified against the original set temperature results once a year. On installation and on a yearly basis please perform the following check. 1.
  • Page 14: Maintenance

    Bar Mixer Shower MAINTENANCE Cleaning We recommend that all products are cleaned us- The following maintenance procedure is ing warm, soapy water and dried with a suitable recommended for domestic installations but cloth to help prevent limescale from forming. must be carried out for commercial installations. Regularly drying your product after use will help Maintenance of the unit is required to give prevent limescale build-up and watermarks.
  • Page 15: Spares

    Bar Mixer Shower To purchase a genuine Triton spare part for your product, please visit www.tritonshowers.co.uk/spares for product codes and prices. Alternatively please call our Customer Experience team on 024 7637 2222 to order direct. Please have your model name available.
  • Page 16: Fault Finding

    Bar Mixer Shower FAULT FINDING The following can be carried out by a competent person Problem Cause Action 1 Water too hot. 1.1 Temperature 1.1.1 Refer to the Commissioning section. control incorrectly commissioned. 1.2 Not enough cold 1.2.1 Reposition the temperature control knob. water flowing through shower.
  • Page 17 Bar Mixer Shower FAULT FINDING The following can be carried out by a competent person Problem/Symptom Cause Action/Cure 3 Water does not flow 3.1 Water supplies cut off. 3.1.1 Check water elsewhere in the house and if or shower pattern necessary, contact local water company.
  • Page 18 Bar Mixer Shower...
  • Page 19 Bar Mixer Shower...
  • Page 20 Trade Installer Hotline: 024 7637 8344 Nuneaton www.tritonshowers.co.uk Warwickshire, CV11 4NR E-mail: serviceenquiries@tritonshowers.co.uk E-mail: technical@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited Triton reserve the right to change product specifi cation without prior notice. E&OE. © TRITON SHOWERS 2023...
