Service LEDs

10.1 Status Display of Remote Control Inputs

10.2 Status Display of Digital Outputs

152/162 ekr 500 digital Unit Touch – Installation and Commissioning Manual
LED Meaning
Remote control input 1 active
H1
(1 signal (+24 V⎓) on terminal 10)
Remote control input 2 active
H2
(1 signal (+24 V⎓) on terminal 11)
Remote control input 3 active
H3
(1 signal (+24 V⎓) on terminal 12)
Remote control input 4 active
H4
(1 signal (+24 V⎓) on terminal 13)
Remote control input 5 active
H5
(1 signal (+24 V⎓) on terminal 14)
Remote control input 6 active
H6
(1 signal (+24 V⎓) on terminal 15)
Remote control input 7 active
H7
(1 signal (+24 V⎓) on terminal 18)
Remote control input 8 active
H8
(1 signal (+24 V⎓) on terminal 19)
Remote control input 9 active
H9
(1 signal (+24 V⎓) on terminal 20)
Remote control input 10 active
H10
(1 signal (+24 V⎓) on terminal 21)
Remote control input 11 active
H11
(1 signal (+24 V⎓) on terminal 22)
Remote control input 12 active
H12
(1 signal (+24 V⎓) on terminal 23)
The terminal assignment of the remote control inputs can be ob-
tained in chapter Terminal Assignment, page 65. The truth table
for the remote control inputs can be found in chapter Truth
Tables, page 136.
LED Meaning
Output 1 active
H13 (position of the guiding device corrected in operating mode
automatic)
Output 2 active
H14 (software limit switch active / motor overcurrent /
guiding device in end position)
H15 Output 3 active
H16 Output 4 active
