Shoal Creek Collection | 417678 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
Page 2
• Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 95 pounds. Never use with a TV that weighs more.
Page 3
RIGHT DOOR (1) W BOTTOM MOLDING (1) RIGHT UPRIGHT (1) LEFT DOOR (1) SIDE BOTTOM MOLDING (2) LEFT UPRIGHT (1) RIGHT LEG (3) END MOLDING (2) TOP (1) LEFT LEG (3) BOTTOM (1) BASE (1) ROLL-OUT BOTTOM (1) www.sauder.com/services 417678 Page 3...
Page 4
3S GOLD 5/16" FLAT HEAD SCREW - 8 BLACK 7/8" LARGE HEAD SCREW - 6 BLACK 1-1/8" MACHINE SCREW - 6 SILVER 3/4" MACHINE SCREW - 12 SILVER 5/8" FLAT HEAD SCREW - 16 BLACK 9/16" FLAT HEAD SCREW - 4 Page 4 417678 www.sauder.com/services...
Page 5
Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Push thirty-two HIDDEN CAMS (1F) into the ENDS (A and B), Arrow å...
Page 6
Step 2 Turn eighteen CAM SCREWS (8F) into the LEGS (P and Q). å Page 6 417678 www.sauder.com/services...
Page 7
Shoulder These edges Apply pressure with your hands should be even. as you guide the MOLDINGS over the SCREWS and onto the ENDS. BLACK 9/16" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 417678 Page 7...
Page 8
Carefully turn your ENDS over. å Fasten the LEGS (P and Q) to the ENDS (A and B). å Tighten twelve HIDDEN CAMS. These surfaces should be even. Angled edge These surfaces should be even. Angled edge Angled edge Page 8 417678 www.sauder.com/services...
Page 9
Push the black lever in and pull the SLIDE from the RAIL. Open end These surfaces should be even. Angled edge Open end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) These surfaces Angled edge should be even. www.sauder.com/services 417678 Page 9...
Page 10
Slide the BOTTOM MOLDING (W) onto the notched edge å of the BOTTOM (H) until it is centered on the middle notch of the BOTTOM. *U.S. Patent No. 5,499,886 å Notched edge Middle notch Slide the BOTTOM MOLDING (W) onto the notched edge. Page 10 417678 www.sauder.com/services...
Page 11
BOTTOM (H) until they are even with the short edges of the BOTTOM. *U.S. Patent No. 5,499,886 å These edges must be even. Slide the SIDE BOTTOM MOLDINGS (X) onto the notched edge. www.sauder.com/services 417678 Page 11...
Page 12
Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 12 417678 www.sauder.com/services...
Page 13
Fasten the LEFT UPRIGHT (F) to the TOP (G). Tighten two å HIDDEN CAMS. i t h f a c S u r D E N H I D Maximum Arrow 210 degrees Minimum 190 degrees www.sauder.com/services 417678 Page 13...
Page 14
Fasten the LARGE BACK (U) to the TOP (G). Tighten two å HIDDEN CAMS. S u r f a c H I D D E N i t h Maximum Arrow 210 degrees Minimum 190 degrees Page 14 417678 www.sauder.com/services...
Page 15
Fasten the RIGHT UPRIGHT (E) to the TOP (G). Tighten å two HIDDEN CAMS. i t h o f a c S u r D E N H I D Maximum Arrow 210 degrees Minimum 190 degrees www.sauder.com/services 417678 Page 15...
Page 16
Fasten the BOTTOM (H) to the UPRIGHTS (E and F) and å LARGE BACK (U). Use six BLACK 1-7/8" FLAT HEAD SCREWS (2S). BLACK 1-7/8" FLAT HEAD SCREW (6 used in this step) Maximum Arrow 210 degrees Minimum 190 degrees Page 16 417678 www.sauder.com/services...
Page 17
Tighten four HIDDEN CAMS. Don't worry. It isn't Rome. This can be built in a day. i t h o f a c S u r D E N H I D Maximum Arrow 210 degrees Minimum 190 degrees www.sauder.com/services 417678 Page 17...
Page 18
Fasten four METAL BRACKETS (4G) to the BASES (R å and S). Use four BLACK 9/16" LARGE HEAD SCREWS (1S). NOTE: Be sure the BRACKETS are even with the edges å of the BASES. BLACK 9/16" LARGE HEAD SCREW (4 used in this step) Page 18 417678 www.sauder.com/services...
Page 19
B R A S u r T A L T A L B R A E T S i t h o f a c B R A S u r T A L www.sauder.com/services 417678 Page 19...
Page 20
Fasten the BASES (R and S) to the BOTTOM (H). Use four å BLACK 9/16" LARGE HEAD SCREWS (1S) through the METAL BRACKETS on the BASES and into the BOTTOM. BLACK 9/16" LARGE HEAD SCREW (4 used in this step) Page 20 417678 www.sauder.com/services...
Page 21
Fasten the BACKS (J) to your unit using the NAILS (1N). å NOTE: Perforations have been provided for access å through the BACK. Carefully cut out the holes needed. NAIL These holes must be here. (48 used in this step) These holes must be here. www.sauder.com/services 417678 Page 21...
Page 22
Fasten eight HINGE SPACERS (22H) and eight å HINGES (14H) to the DOORS (N, O, and V). Use sixteen SILVER 5/8" FLAT HEAD SCREWS (23S). SILVER 5/8" FLAT HEAD SCREW (16 used in this step) (8 used) Page 22 417678 www.sauder.com/services...
Page 23
SILVER 3/4" MACHINE SCREWS (20S). Repeat this step for the RIGHT DOOR (N). å Push two DOOR STOPS (4I) into the holes in the TOP (G). å SILVER 3/4" MACHINE SCREW (12 used in this step) www.sauder.com/services 417678 Page 23...
Page 24
Repeat this step for the other SMALL DOOR (V). å Push two DOOR STOPS (4I) into the holes in the å BOTTOM (H). See the next step for DOOR adjustments. å BLACK 1-1/8" MACHINE SCREW (4 used in this step) Page 24 417678 www.sauder.com/services...
Page 25
To adjust the DOORS in or out (depth), loosen the mounting å screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) www.sauder.com/services 417678 Page 25...
Page 26
DRAWER BRACKETS to the ROLL-OUT ENDS (C and D). Use six BLACK 7/8" LARGE HEAD SCREWS (17S). NOTE: Be sure to position the DRAWER BRACKET SET å exactly as shown. BLACK 7/8" LARGE HEAD SCREW (6 used in this step) Page 26 417678 www.sauder.com/services...
Page 27
OUT BOTTOM (I). Use four BLACK 1-7/8" FLAT HEAD SCREWS (2S). Finished edge F i n i s h e u r f a BLACK 1-7/8" FLAT HEAD SCREW (8 used in this step) Finished edge www.sauder.com/services 417678 Page 27...
Page 28
Fasten the EXTENSION SLIDES (AA) to the ROLL-OUT å ENDS (C and D). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #4. Open end Open end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Page 28 417678 www.sauder.com/services...
Page 29
Fasten two KNOBS (24K) to the FLIP-UP DRAWER FRONT (T). å Use two BLACK 1-1/8" MACHINE SCREWS (21S). BLACK 9/16" LARGE HEAD SCREW (4 used in this step) BLACK 1-1/8" MACHINE SCREW (2 used for the KNOBS) www.sauder.com/services 417678 Page 29...
Page 30
å Insert the METAL PINS into the hole locations of your choice in the ENDS (A and B) and UPRIGHTS (E and F). Set the ADJUSTABLE SHELVES (L and M) onto the METAL PINS. (20 used) Page 30 417678 www.sauder.com/services...
Page 31
- The TV must weigh less than 95 lbs. - The base of the TV must be able to sit completely on this shelf. 25 lbs. 95 lbs. 25 lbs. 20 lbs. 25 lbs. 25 lbs. 60 lbs. total 25 lbs. www.sauder.com/services 417678 Page 31...
Page 32
EXTRÉMITÉ DROITE ..........1 (ENSEMBLE DE GLISSIÈRE ILLUSTRÉ À PART) pour future référence. EXTRÉMITÉ GAUCHE ..........1 GLISSIÈRE D'EXTENSION ........2 Pour contacter Sauder en ce qui concerne cet EXTRÉMITÉ DROITE COULISSANTE ...1 COULISSE D'EXTENSION ........2 élément, faire référence EXTRÉMITÉ GAUCHE COULISSANTE ..1 EXCENTRIQUE ESCAMOTABLE ....
Page 33
• Vérifi er la taille et le poids du téléviseur. Le comparer au diagramme ci-dessous avant de commencer l'assemblage ! Séparer les COULISSES D'EXTENSION (AA) des GLISSIÈRES • Cette unité Sauder est conçue pour les téléviseurs pesant moins D'EXTENSION (Z) comme l'indique le schéma ci-dessous. Faire attention car les pièces sont graissées.
Page 34
VIS TÊTE PLATE 48 mm NOIRES (2S). ÉTAPE 16 Fixer les SOCLES (R et S) au DESSOUS (H). Utiliser quatre VIS TÊTE LARGE 14 mm NOIRES (1S) à travers les CONSOLES EN MÉTAL sur les SOCLES et dans le DESSOUS. Page 34 417678 www.sauder.com/services...
Page 35
fi gurant sur les pages arrière du manuel d’instructions. COULISSANT (I). Utiliser quatre VIS TÊTE PLATE 48 mm NOIRES (2S). Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. www.sauder.com/services 417678 Page 35...
Page 36
EXTREMO IZQUIERDO ............1 PASADOR DE EXCÉNTRICO ......14 pour future référence. EXTREMO DERECHO DESLIZANTE ......1 BIELA DE EXCÉNTRICO ........18 Pour contacter Sauder EXTREMO IZQUIERDO DESLIZANTE ..... 1 SOPORTE DE METAL ..........4 en ce qui concerne cet élément, faire référence PARAL DERECHO ..............
Page 37
- antes de comenzar el ensamblaje! Separe las CORREDERAS DE EXTENSIÓN (AA) de los RIELES • Esta unidad Sauder está diseñada para ser usada con DE EXTENSIÓN (Z) como se muestra en el diagrama inferior. Prepárese, las piezas son grasientas.
Page 38
PASO 16 Fije las BASES (R y S) al FONDO (H). Introduzca cuatro TORNILLOS NEGROS DE CABEZA GRANDE de 14 mm (1S) por entre los SOPORTES DE METAL en las BASES y por entre el FONDO. Page 38 417678 www.sauder.com/services...
Page 39
Utilice cuatro TORNILLOS NEGROS DE CABEZA PERDIDA de 48 mm (2S). muebles preferido o un paño húmedo. Seque con un paño. Luego, fi je los EXTREMOS DESLIZANTES (C y D) al FONDO DESLIZANTE (I). Utilice cuatro TORNILLOS NEGROS DE CABEZA PERDIDA de 48 mm (2S). www.sauder.com/services 417678 Page 39...
Page 40
• Physical injury. Furniture can be very heavy. • Do not push furniture, especially on a carpeted fl oor. Have a friend help you lift the item and set it in place. Page 40 417678 www.sauder.com/services...
Page 41
équipé. • Blessure physique. Le mobilier peut être très lourd. • Ne pas pousser le mobilier, surtout sur la moquette. Se faire aider par une autre personne pour soulever l’élément et le mettre en place. www.sauder.com/services 417678 Page 41...
Page 42
• Lesión física. El mobiliario puede ser • No empuje la unidad, especialmente muy pesado. sobre un piso alfombrado. Pide la ayuda de otra persona en levantar la unidad y colocarla en lugar. Page 42 417678 www.sauder.com/services...
Page 43
GARANTIE LIMITÉE DE 5 ANS 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période de cinq ans à...
Page 44
Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
