sauder.com

Dresser

Shoal Creek Collection | Model 411201

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.

Prefer the phone? Call 1-800-523-3987.

Share your journey!

WARNING

CHOKING HAZARD - Small Parts

Not for children under 3 years.

Adult assembly required.

NOTE: THIS INSTRUCTION

BOOKLET CONTAINS IMPORTANT

SAFETY INFORMATION.

PLEASE READ AND KEEP FOR

FUTURE REFERENCE.

English pg 1-24

Français pg 25-28

Español pg 29-32

Lot # 528691

04/22/19

Purchased: __________________

Be sure to give us a ring before

making any returns. 1-800-523-3987

Need help?

Do you have a question about the Shoal Creek 411201 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sauder Shoal Creek 411201

Page 1 Shoal Creek Collection | Model 411201 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
Page 2 D138 LEFT DRAWER SIDE (4) (Hidden part using recycled material. Color may vary.) D166 SMALL DRAWER BACK (2) END MOLDING (2) D167 DRAWER BACK (4) RIGHT DRAWER FRONT (2) D975 DRAWER BOTTOM (6) LEFT DRAWER FRONT (2) Page 2 411201 www.sauder.com/services...
Page 3 Part Identiﬁ cation D166 D975 D166 D975 D132 D167 D975 D138 D167 D132 D975 D138 www.sauder.com/services 411201 Page 3...
Page 4 10A SLIDE CAM - 12 ADJUSTABLE FOOT - 1 HIDDEN CAM - 22 CAM DOWEL - 10 KNOB - 4 CAM SCREW - 12 PULL - 8 FURNITURE TIPPING NAIL - 47 METAL PIN - 4 RESTRAINT KIT - 1 Page 4 411201 www.sauder.com/services...
Page 5 3S GOLD 5/16" FLAT HEAD SCREW - 48 SILVER 3/4" MACHINE SCREW - 16 BLACK 1-1/8" MACHINE SCREW - 4 BLACK 2-1/4" FLAT HEAD SCREW - 6 30S BLACK 1-9/16" FLAT HEAD SCREW - 30 BLACK 9/16" FLAT HEAD SCREW - 4 www.sauder.com/services 411201 Page 5...
Page 6 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted ﬂ oor or on the empty å carton to avoid scratching your unit or the ﬂ oor. Scan this QR code or go to this address: http://qr.sauder.com/?ID=2558...
Page 7 å and B2) and DRAWER BRACES (M65). Some assembly (and snacks) required. Arrow (12 used) Arrow Arrow Hole Arrow The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. www.sauder.com/services 411201 Page 7...
Page 8 Step 3 Turn twelve CAM SCREWS (8F) into the FRONT LEGS (G å and H) and DRAWER FRONTS (K2, L2, Q2, and R2). (12 used) Page 8 411201 www.sauder.com/services...
Page 9 Shoulder These edges Apply pressure with your hands should be even. as you guide the MOLDINGS over BLACK 9/16" FLAT HEAD SCREW the SCREWS and onto the ENDS. (4 used in this step) www.sauder.com/services 411201 Page 9...
Page 10 Edge with CAM DOWELS S u r f a c Edge with w i t h CAM DOWELS H I D D E N The LEGS will overhang this edge. These surfaces should be even. Angled edge Page 10 411201 www.sauder.com/services...
Page 11 B2) and UPRIGHT (C2). Use twenty-four GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #4. *patent pending glide system å Glide end Glide end Finished edge Glide end GOLD 5/16" FLAT HEAD SCREW (24 used in this step) www.sauder.com/services 411201 Page 11...
Page 12 Safety strap Unﬁ nished edge Use this hole if you prefer the SAFETY STRAP on the left side of the UPRIGHT. Use this hole if you prefer the SAFETY STRAP on the right side of the UPRIGHT. Page 12 411201 www.sauder.com/services...
Page 13 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 411201 Page 13...
Page 14 H I D i t h D E N S u r f a c H I D i t h D E N BLACK 1-7/8" FLAT HEAD SCREW Finished edge (2 used in this step) (4 used) Page 14 411201 www.sauder.com/services...
Page 15 Fasten the RIGHT END (A2) to the TOP (D2) and å BOTTOMS (E2). Tighten four HIDDEN CAMS. Maximum Arrow 210 degrees NOTE: Be sure the METAL PINS in the BOTTOMS å insert into the holes in the RIGHT END. Minimum 190 degrees www.sauder.com/services 411201 Page 15...
Page 16 NOTE: Be sure to tap NAILS into the holes that line up over å NAIL the UPRIGHT (C2). (47 used in this step) These holes must line up Before fastening the BACK, over the UPRIGHT (C2). push the SAFETY STRAP through one of these holes. Page 16 411201 www.sauder.com/services...
Page 17 BOTTOM (E2). Use four BLACK 9/16" LARGE HEAD SCREWS (1S). NOTE: Adjustments to the ADJUSTABLE FOOT will be å made in Step 13 once your unit is standing upright. BLACK 9/16" LARGE HEAD SCREW (4 used in this step) www.sauder.com/services 411201 Page 17...
Page 18 IMPORTANT: The ADJUSTABLE FOOT should not extend å beyond the bottom edges of the LEGS (G, H, and I). With your No. 2 Phillips Screwdriver, turn the ADJUSTABLE FOOT downward until it touches the ﬂ oor. Floor Page 18 411201 www.sauder.com/services...
Page 19 DRAWERS using the DRAWER FRONTS (Q2 and R2). Use the SMALL DRAWER FRONTS (K2 and L2), SMALL DRAWER SIDES (D10 and D11), and SMALL DRAWER BACKS (D166) for the small drawers. www.sauder.com/services 411201 Page 19...
Page 20 Glide end Screw head - turn CAM to line up holes in the SLIDES with holes in DRAWER SIDES D138 Glide end D132 (4 screws per drawer) GOLD 5/16" FLAT HEAD SCREW (24 used in this step) Page 20 411201 www.sauder.com/services...
Page 21 Fasten the PULLS (31K) to the RIGHT DRAWER FRONT (Q2). å Use four SILVER 3/4" MACHINE SCREWS (20S). Repeat this step for the other drawers. å BLACK 1-1/8" MACHINE SCREW (4 used for the KNOBS) SILVER 3/4" MACHINE SCREW (16 used for the PULLS) www.sauder.com/services 411201 Page 21...
Page 22 5. Continue to turn until the screw starts spinning freely. NOTE: Before moving your unit to a diff erent location, unscrew the SAFETY DRYWALL ANCHOR from your wall. The å nylon sheath will remain behind your wall. Washer Safety drywall anchor Safety strap Page 22 411201 www.sauder.com/services...
Page 23 • Ne r res eli mi at a -o ve no t of tip bu t Us e uc e, -o ve of tip 35 lbs. each www.sauder.com/services 411201 Page 23...
Page 24 #2. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. Page 24 411201 www.sauder.com/services...
Page 25 EXTRÉMITÉ DROITE ..........1 40DA GLISSIÈRE D'ÉLÉMENT UNIVERSELLE...12 pour future référence. EXTRÉMITÉ GAUCHE ..........1 40DC TIROIR DROIT ..............6 Pour contacter Sauder en ce qui concerne cet MONTANT................1 40DD TIROIR GAUCHE ............6 élément, faire référence DESSUS ................1 10A EXCENTRIQUE DE COULISSE .......12 au numéro de lot et...
Page 26 Escamotables que ne sont pas serrées à bloc peuvent desserrer les EXTRÉMITÉS. et les pièces peuvent séparer. Pour serrer à bloc, faire tourner l'excentrique escamotable de 210 degrés. REMARQUE : Si la MOULURE soulève au-dessus les VIS, l'enlever et l'enﬁ ler de nouveau. Page 26 411201 www.sauder.com/services...
Page 27 Fixer le PIED RÉGLABLE (34E) au DESSOUS (E2) supérieur. Répéter cette étape pour les autres tiroirs. Utiliser quatre VIS TÊTE LARGE 14 mm NOIRES (1S). REMARQUE : Les réglages du PIED RÉGLABLE se feront à l’étape 13 une fois l’unité en position verticale. www.sauder.com/services 411201 Page 27...
Page 28 REMARQUE : Avant de déplacer l’unité vers un emplacement diff érent, dévisser le DISPOSITIF DE SÉCURITÉ POUR Ceci complète l'assemblage. PLACOPLÂTRE du mur. La gaine en nylon restera Nettoyer avec un tissu humide. Essuyer. derrière le mur. Page 28 411201 www.sauder.com/services...
Page 29 40DC CAJÓN DERECHO .............6 su referencia futura. Si EXTREMO IZQUIERDO ..........1 necesita ponerse en 40DD CAJÓN IZQUIERDO ..........6 PARAL ...................1 contacto con Sauder en 10A EXCÉNTRICO DE CORREDERA .....12 PANEL SUPERIOR ............1 cuanto a esta unidad, 34E PATA ..................1 reﬁ érase al número D10 LADO DERECHO DE CAJÓN PEQUEÑO ..2...
Page 30 Escondidos que no se aprieten completamente se aﬂ ojarán y las partes pueden separarse. Para apretar completamente, atornille el NOTA: Si la MOLDURA se levanta de los TORNILLOS, retírela y excéntrico escondido 210 grados. deslícela sobre la parte otra vez. Page 30 411201 www.sauder.com/services...
Page 31 TORNILLOS NEGROS DE CABEZA GRANDE de 14 mm (1S). Repita este paso para los otros cajones. NOTA: Los ajustes a la PATA AJUSTABLE se realizarán en el paso 13, una vez que su unidad está en posición vertical. www.sauder.com/services 411201 Page 31...
Page 32 NOTA: Antes de trasladar la unidad a otra ubicación, desatornille Esto completa el ensamblaje. Limpiar con un trapo húmedo. el ANCLAJE DE SEGURIDAD PARA EL DRYWALL de su pared. La Seque con un paño. cubierta de nailon permanecerá detrás de su pared. Page 32 411201 www.sauder.com/services...
Page 33 TOUJOURS décharger les tablettes et les tiroirs, en commençant par les surface supérieures, avant de déplacer le meuble. NE JAMAIS pousser ou tirer un meuble sur de la moquette. Demander à une autre personne de le soulever correctement pour le déplacer et/ou le repositionner. www.sauder.com/services 411201 Page 33...
Page 34 SIEMPRE descargue los estantes y cajones, empezando con las superﬁ cies superiores, antes de moverlo. NUNCA empuje ni tire de los muebles sobre una alfombra. Obtenga que un amigo le ayude a levantarlo correctamente para moverlo y/o reposicionarlo. Page 34 411201 www.sauder.com/services...
Page 35 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
Page 36 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
