Dresser
Shoal Creek Collection | Model 409937
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-22
Français pg 23-25
Español pg 26-28
Lot # 373325
05/26/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading

Related Manuals for Sauder Shoal Creek 409937

Summary of Contents for Sauder Shoal Creek 409937

  • Page 1 Shoal Creek Collection | Model 409937 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 DRAWER BRACE (6) D138 LEFT DRAWER SIDE (4) END MOLDING (2) D166 SMALL DRAWER BACK (2) RIGHT DRAWER FRONT (2) D167 DRAWER BACK (4) LEFT DRAWER FRONT (2) D975 DRAWER BOTTOM (6) BRACE (1) BOTTOM (2) Page 2 409937 www.sauder.com/services...
  • Page 3 Part Identifi cation D166 D975 D166 D132 D167 D975 D975 D138 D132 D167 D975 D138 www.sauder.com/services 409937 Page 3...
  • Page 4 This is a permanent label. Do not attempt to remove! 04/10 332296 (Refer to step 15 for proper location and application) WW SAFETY BRACKET - 1 FOOT - 1 FOOT BASE - 1 Page 4 409937 www.sauder.com/services...
  • Page 5 BLACK 1-1/8" MACHINE SCREW - 4 SILVER 3/4" MACHINE SCREW - 16 BLACK 9/16" FLAT HEAD SCREW - 4 BLACK 9/16" LARGE HEAD SCREW - 1 GOLD 5/16" FLAT HEAD SCREW - 48 NAIL - 47 www.sauder.com/services 409937 Page 5...
  • Page 6 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Scan this QR code or go to this address: http://qr.sauder.com/?ID=1444...
  • Page 7 Step 2 Turn twelve CAM SCREWS (BB2) into the FRONT LEGS (G å and H) and DRAWER FRONTS (K2, L2, Q2, and R2). (12 used) www.sauder.com/services 409937 Page 7...
  • Page 8 Step 3 Fasten the REAR LEGS (I) to the ENDS (A and B). Use six å BLACK 2-1/4" FLAT HEAD SCREWS (KK). Flat edge BLACK 2-1/4" FLAT HEAD SCREW (6 used in this step) Page 8 409937 www.sauder.com/services...
  • Page 9 Shoulder These edges Apply pressure with your hands should be even. as you guide the MOLDINGS over the SCREWS and onto the ENDS. BLACK 9/16" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 409937 Page 9...
  • Page 10 Step 5 Fasten the FRONT LEGS (G and H) to the other surface of å the ENDS (A and B). Tighten six HIDDEN CAMS. Angled edge Page 10 409937 www.sauder.com/services...
  • Page 11 LEFTS (40CB) to the ENDS (A and B) and UPRIGHT(C). Use twenty-four GOLD 5/16" FLAT HEAD SCREWS (QQ) through holes #1 and #4. Roller end Roller end Finished edge Roller end GOLD 5/16" FLAT HEAD SCREW (24 used in this step) www.sauder.com/services 409937 Page 11...
  • Page 12 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 12 409937 www.sauder.com/services...
  • Page 13 H I D D E N i t h S u r f a c H I D D E N i t h Finished edge BLACK 1-7/8" FLAT HEAD SCREW (4 used) (2 used in this step) www.sauder.com/services 409937 Page 13...
  • Page 14 Fasten the RIGHT END (A) to the TOP (D) and å BOTTOMS (E). Tighten four HIDDEN CAMS. Maximum Arrow 210 degrees NOTE: Be sure the METAL PINS in the BOTTOMS å insert into the holes in the RIGHT END. Minimum 190 degrees Page 14 409937 www.sauder.com/services...
  • Page 15 NOTE: Turn the screw end of the FOOT completely in. å Adjustments will be made to the FOOT after the unit is standing upright. BLACK 1-1/4" FLAT HEAD SCREW (4 used in this step) Turn completely in. www.sauder.com/services 409937 Page 15...
  • Page 16 UPRIGHT (C). NOTE: Perforations have been provided for access å through the BACK. Carefully cut out the holes needed. NAIL (47 used in this step) These holes must line up over the UPRIGHT (C). Cut-out Page 16 409937 www.sauder.com/services...
  • Page 17 FLAT HEAD SCREWS (30S). Repeat this step for the other DRAWERS using the DRAWER FRONTS (Q2 and R2). Use the SMALL DRAWER FRONTS (K2 and L2), SMALL DRAWER SIDES (D10 and D11), and SMALL DRAWER BACKS (D166) for the small drawers. www.sauder.com/services 409937 Page 17...
  • Page 18 Roller end Screw head - turn CAM to line up holes in the SLIDES with holes in DRAWER SIDES D138 Roller end D132 (4 screws per drawer) GOLD 5/16" FLAT HEAD SCREW (24 used in this step) Page 18 409937 www.sauder.com/services...
  • Page 19 Fasten the PULLS (EE) to the RIGHT DRAWER FRONT (Q2). å Use four SILVER 3/4" MACHINE SCREWS (NN). Repeat this on sauder.com. step for the other drawers. BLACK 1-1/8" MACHINE SCREW (4 used for the KNOBS) SILVER 3/4" MACHINE SCREW (16 used for the PULLS) www.sauder.com/services...
  • Page 20 Once applied, do not try to remove it. Floor Turn the ADJUSTABLE FOOT downward until it touches the fl oor. IMPORTANT: The ADJUSTABLE FOOT should not extend beyond the bottom edges of the LEGS. Page 20 409937 www.sauder.com/services...
  • Page 21 FLAT HEAD SCREW (LL) into a stud in your wall. BLACK 1-7/8" FLAT HEAD SCREW (1 used into a stud in your wall) BLACK 9/16" LARGE HEAD SCREW (1 used into the top of your unit) 40 lbs. 20 lbs. 20 lbs. 35 lbs. each www.sauder.com/services 409937 Page 21...
  • Page 22 #4. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. Page 22 409937 www.sauder.com/services...
  • Page 23 EXTRÉMITÉ DROITE ..........1 40CA ÉLÉMENT DROITE............6 pour future référence. EXTRÉMITÉ GAUCHE ..........1 40CB ÉLÉMENT GAUCHE ..........6 Pour contacter Sauder en ce qui concerne cet MONTANT................1 40CC TIROIR DROIT ..............6 élément, faire référence DESSUS ................1 40CD TIROIR GAUCHE ............6 au numéro de lot et...
  • Page 24 Attention: Risque des dégâts ou blessures. Les Excentriques Escamotables doivent être serrés à bloc. Les Excentriques Escamotables que ne sont pas serrées à bloc peuvent desserrer et les pièces peuvent séparer. Pour serrer à bloc, faire tourner l'excentrique escamotable de 210 degrés. Page 24 409937 www.sauder.com/services...
  • Page 25 REMARQUE : Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. www.sauder.com/services 409937 Page 25...
  • Page 26 EXTREMO IZQUIERDO ..........1 CC2 PASADOR DE EXCÉNTRICO ......10 pour future référence. PARAL ...................1 TIRADOR ................8 Pour contacter Sauder en ce qui concerne cet PANEL SUPERIOR ............1 POMO ..................4 élément, faire référence D10 LADO DERECHO DE CAJÓN PEQUEÑO ..2 ESPIGA DE METAL ............4...
  • Page 27 Precaución: Riesgo de daños o heridas. Los Excéntricos Escondidos deben apretarse completamente. Los Excéntricos Escondidos que no se aprieten completamente se afl ojarán y las partes pueden separarse. Para apretar completamente, atornille el excéntrico escondido 210 grados. www.sauder.com/services 409937 Page 27...
  • Page 28 19 mm (NN). Repita este paso para los otros cajones. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 28 409937 www.sauder.com/services...
  • Page 29 équipé. • Blessure physique. Le mobilier peut • Ne pas pousser le mobilier, surtout sur la être très lourd. moquette. www.sauder.com/services 409937 Page 29...
  • Page 30 • No empuje la unidad, especialmente • Lesión física. El mobiliario puede ser sobre un piso alfombrado. muy pesado. Page 30 409937 www.sauder.com/services...
  • Page 31 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 32 Dear Valued Customer: So, how did it go? Set a world record for speed? Thanks so much for choosing Sauder® furniture. I hope the Feeling good about yourself? purchase and assembly process was a positive experience Nice. Get social with it on any and you feel good about the furniture you just built.
