Sauder Shoal Creek 418662 Manual

Armoire
Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
Armoire
Shoal Creek Collection | Model 418662
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-26
Français pg 27-29
Español pg 30-32
Lot # 372703
05/13/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading

Related Manuals for Sauder Shoal Creek 418662

Summary of Contents for Sauder Shoal Creek 418662

  • Page 1 Shoal Creek Collection | Model 418662 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 D27 LEFT DRAWER SIDE (1) TOP (1) LEFT FRONT LEG (1) D174 DRAWER BACK (1) SHELF/BOTTOM (2) REAR LEG (2) D981 DRAWER BOTTOM (1) BACK (1) DRAWER FRONT (1) M64 DRAWER BRACE (1) DOOR (2) END MOLDING (2) Page 2 418662 www.sauder.com/services...
  • Page 3 Part Identifi cation D174 D981 www.sauder.com/services 418662 Page 3...
  • Page 4 This is a permanent label. Do not attempt to remove! 04/10 332296 (Refer to Step 19 for proper location and application) NAIL - 43 METAL PIN - 8 SHELF SNAP - 8 Page 4 418662 www.sauder.com/services...
  • Page 5 GOLD 5/16" FLAT HEAD SCREW - 8 BLACK 1-1/8" MACHINE SCREW - 5 SILVER 5/8" FLAT HEAD SCREW - 8 BLACK 2-1/4" FLAT HEAD SCREW - 8 30S BLACK 1-9/16" FLAT HEAD SCREW - 5 BLACK 9/16" FLAT HEAD SCREW - 4 www.sauder.com/services 418662 Page 5...
  • Page 6 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Scan this QR code or go to this address: http://qr.sauder.com/?ID=1217...
  • Page 7 Step 2 Turn nine CAM SCREWS (8F) into the FRONT LEGS (H å and I) and DRAWER FRONT (K). Remember: Righty tighty. Lefty loosey. (9 used) www.sauder.com/services 418662 Page 7...
  • Page 8 END (A) and the CABINET LEFT (35GB) to the END (B). Use four GOLD 5/16" FLAT HEAD SCREWS (3S). GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Long edge with HIDDEN CAMS Roller end Long edge with HIDDEN CAMS Roller end Page 8 418662 www.sauder.com/services...
  • Page 9 Fasten the REAR LEGS (J) to the ENDS (A and B). Use å eight BLACK 2-1/4" FLAT HEAD SCREWS (26S). BLACK 2-1/4" FLAT HEAD SCREW (8 used in this step) These surfaces should be even. Angled edge Angled edge www.sauder.com/services 418662 Page 9...
  • Page 10 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 10 418662 www.sauder.com/services...
  • Page 11 Fasten the other SHELF/BOTTOM (D) to the ENDS (A å and B). Tighten four HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees Finished edge S u r f a c H I D i t h D E N www.sauder.com/services 418662 Page 11...
  • Page 12 BLACK 9/16" LARGE HEAD SCREWS (1S). Minimum 190 degrees (2 used) Long fi nished edge BLACK 9/16" LARGE HEAD SCREW S u r (2 used in this step) f a c i t h h o l Page 12 418662 www.sauder.com/services...
  • Page 13 Line up the grooves in the MOLDINGS over the heads of the SCREWS in the ENDS. Shoulder BLACK 9/16" FLAT HEAD SCREW (4 used in this step) Apply pressure with your hands as you guide the MOLDINGS over the SCREWS and onto the ENDS. www.sauder.com/services 418662 Page 13...
  • Page 14 Step 9 Fasten the FRONT LEGS (H and I) to the ENDS (A and B). å Tighten eight HIDDEN CAMS. Flat edge Flat edge Page 14 418662 www.sauder.com/services...
  • Page 15 Fasten the BACK (E) to your unit using the NAILS (1N). å NOTE: Be sure to tap NAILS into the holes that line up å over the SHELF/BOTTOM (D). NAIL (43 used in this step) These holes must line up over the SHELF/BOTTOM (D). www.sauder.com/services 418662 Page 15...
  • Page 16 Step 11 Fasten four HINGES (14H) and four HINGE SPACERS (22H) å to the DOORS (F). Use eight SILVER 5/8" FLAT HEAD SCREWS (23S). SILVER 5/8" FLAT HEAD SCREW (8 used in this step) Page 16 418662 www.sauder.com/services...
  • Page 17 Fasten a KNOB (24K) to the DOOR (F). Use a BLACK å 1-1/8" MACHINE SCREW (21S). Repeat this step for the other DOOR (F). å See the next step for DOOR adjustments. å Stop Mounting screw Hinge BLACK 1-1/8" MACHINE SCREW (2 used in this step) www.sauder.com/services 418662 Page 17...
  • Page 18 To adjust the DOORS in or out (depth), loosen the mounting screw one turn and move the DOORS in or out, as needed. å Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) Page 18 418662 www.sauder.com/services...
  • Page 19 Fasten the DRAWER BACK (D174) to the DRAWER Fasten the DRAWER BRACE (M64) to the å å SIDES (D26 and D27) and DRAWER BRACE (M64). Use DRAWER FRONT (K). Tighten one HIDDEN CAM. five BLACK 1-9/16" FLAT HEAD SCREWS (30S). www.sauder.com/services 418662 Page 19...
  • Page 20 å hole in the SLIDE. Screw head - turn CAM to line up holes in the SLIDES with holes in DRAWER SIDES Roller end Roller end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Page 20 418662 www.sauder.com/services...
  • Page 21 Step 16 Fasten the KNOBS (24K) to the DRAWER FRONT (K). Use å three BLACK 1-1/8" MACHINE SCREWS (21S). BLACK 1-1/8" MACHINE SCREW (3 used in this step) www.sauder.com/services 418662 Page 21...
  • Page 22 Step 17 With a hammer, gently tap four SHELF SNAPS (6R) into å the holes in the ADJUSTABLE SHELF (G). Repeat this step for the other ADJUSTABLE SHELF (G). å (8 used) Page 22 418662 www.sauder.com/services...
  • Page 23 SHELF up with the palm of your hand. Peel the FELT DISC from the FELT DISC CARD (1M) and å stick them on the ADJUSTABLE SHELVES (G) where they come into contact with the DOORS. (8 used) www.sauder.com/services 418662 Page 23...
  • Page 24 -Never open more than one drawer at a time. -If equipped with a drawer interlock system, do not defeat or remove it. Use of tip-over restraints may only reduce, but not eliminate, the risk of tip-over. Page 24 418662 www.sauder.com/services...
  • Page 25 BLACK 1-7/8" FLAT HEAD SCREW (1 used into a stud in your wall) BLACK 9/16" LARGE HEAD SCREW (1 used into the top of your unit) 10 lbs. 25 lbs. 25 lbs. 30 lbs. 20 lbs. www.sauder.com/services 418662 Page 25...
  • Page 26 #3. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. Page 26 418662 www.sauder.com/services...
  • Page 27 EXTRÉMITÉ DROITE ..........1 10A EXCENTRIQUE DE COULISSE ......2 pour future référence. EXTRÉMITÉ GAUCHE ..........1 EXCENTRIQUE ESCAMOTABLE ....21 Pour contacter Sauder en ce qui concerne cet DESSUS ................1 CHEVILLE D'EXCENTRIQUE ......12 élément, faire référence TABLETTE/DESSOUS ..........2 VIS D'EXCENTRIQUE ..........9 au numéro de lot et...
  • Page 28 MÉTAUX 28 mm NOIRE (21S). EXCENTRIQUES ESCAMOTABLES. Répéter cette étape pour l'autre porte. Fixer deux CONSOLES EN MÉTAL (4G) au DESSUS (C). Utiliser deux VIS TÊTE LARGE 14 mm NOIRES (1S). Voir l'étape suivante pour réglages. Page 28 418662 www.sauder.com/services...
  • Page 29 À l'aide d'un marteau, enfoncer légèrement quatre CLIQUETS DE chiff on avec de l’eau du robinet et essuyer. TABLETTE (6R) dans les trous de la TABLETTE RÉGLABLE (G). Répéter cette étape pour l'autre TABLETTE RÉGLABLE (G). www.sauder.com/services 418662 Page 29...
  • Page 30 EXTREMO DERECHO ..........1 MÉNSULA DE SEGURIDAD .........1 et conserver le livret pour future référence. EXTREMO IZQUIERDO ..........1 SOPORTE DE METAL ..........2 Pour contacter Sauder PANEL SUPERIOR ............1 14H BISAGRA ................4 en ce qui concerne cet ESTANTE/FONDO............2 22H ESPACIADOR DE BISAGRA ........4 élément, faire référence...
  • Page 31 Fije dos SOPORTES DE METAL (4G) al PANEL SUPERIOR (C). Utilice dos TORNILLOS NEGROS DE CABEZA GRANDE de 14 mm (1S). NEGRO PARA METAL de 28 mm (21S). Repita este paso para la otra puerta. Consulte el próximo paso para los ajustes. www.sauder.com/services 418662 Page 31...
  • Page 32 Esto completa el ensamblaje. Para limpiar la unidad, humedezca un paño con agua de llave y limpie. Utilizando un martillo, ligeramente golpee cuatro FIADORES DE ESTANTE (6R) dentro de los agujeros del ESTANTE AJUSTABLE (G). Repita este paso para el otro ESTANTE AJUSTABLE (G). Page 32 418662 www.sauder.com/services...
  • Page 33 • Ne pas pousser le mobilier, surtout sur la être très lourd. moquette. Se faire aider par une autre personne pour soulever l’élément et le mettre en place • Cette unité doit être placée contre un mur.. www.sauder.com/services 418662 Page 33...
  • Page 34 • No empuje la unidad, especialmente sobre ser muy pesado. un piso alfombrado. Pide la ayuda de otra persona para levantar la unidad y colocarla en lugar. • Esta unidad debe ser colocada contra una pared. Page 34 418662 www.sauder.com/services...
  • Page 35 GARANTIE LIMITÉE DE 5 ANS 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période de cinq ans à...
  • Page 36 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
