Sauder Shoal Creek 418655 Manual

Panel tv stand
Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
Panel TV Stand
Shoal Creek Collection | Model 418655
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Smart stand
for the idiot box.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-20
Français pg 21-24
Español pg 25-28
Lot # 370392
05/18/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading
Need help?

Need help?

Do you have a question about the Shoal Creek 418655 and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder Shoal Creek 418655

Summary of Contents for Sauder Shoal Creek 418655

  • Page 1 Shoal Creek Collection | Model 418655 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 70 pounds. Never use with a TV that weighs more.
  • Page 3 SUPPORT FOOT (2) BOTTOM (1) END MOLDING (2) FIXED SHELF (2) RIGHT DRAWER SIDE (2) BACK (1) LEFT DRAWER SIDE (2) ADJUSTABLE SHELF (2) DRAWER BACK (2) RIGHT FRONT/LEFT REAR LEG (2) D969 DRAWER BOTTOM (2) D969 D969 www.sauder.com/services 418655 Page 3...
  • Page 4 BLACK 1-7/8" FLAT HEAD SCREW - 2 3S GOLD 5/16" FLAT HEAD SCREW - 16 BLACK 1-1/8" MACHINE SCREW - 4 30S BLACK 1-9/16" FLAT HEAD SCREW - 8 BLACK 9/16" FLAT HEAD SCREW - 4 Page 4 418655 www.sauder.com/services...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Push thirty HIDDEN CAMS (1F) into the ENDS (A and B), å...
  • Page 6 Step 2 Turn twelve CAM SCREWS (8F) into the LEGS (I and J). å Remember: Righty tighty. Lefty loosey. (12 used) Page 6 418655 www.sauder.com/services...
  • Page 7 Shoulder Apply pressure with your hands These edges as you guide the MOLDINGS over should be even. the SCREWS and onto the ENDS. BLACK 9/16" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 418655 Page 7...
  • Page 8 Step 4 Fasten the LEGS (I and J) to the ENDS (A and B). Tighten å twelve HIDDEN CAMS. These surfaces should be even. Edge with CAM DOWELS These surfaces should be even. Angled edge Angled edge Page 8 418655 www.sauder.com/services...
  • Page 9 SCREWS (3S) through holes #1 and #3. NOTE: The CABINET RAILS are marked "CABINET å RIGHT" and "CABINET LEFT" for easy identifi cation. Roller end Roller end Finished edge GOLD 5/16" FLAT HEAD SCREW Roller end (8 used in this step) www.sauder.com/services 418655 Page 9...
  • Page 10 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 10 418655 www.sauder.com/services...
  • Page 11 Edge with CAM DOWELS Finished edge Finished edge i t h f a c S u r D E N H I D S u r f a c H I D D E N i t h www.sauder.com/services 418655 Page 11...
  • Page 12 Fasten the RIGHT END (A) to the FIXED SHELF (F). å Tighten two HIDDEN CAMS. Side Step: Make nachos. (Optional, but recommended.) i t h o f a c S u r D E N H I D Maximum Arrow 210 degrees Minimum 190 degrees Page 12 418655 www.sauder.com/services...
  • Page 13 Fasten the BOTTOM (E) to the UPRIGHT (C). Use two å BLACK 1-7/8" FLAT HEAD SCREWS (2S). Finished edge S u r f a c H I D D E N i t h BLACK 1-7/8" FLAT HEAD SCREW (2 used in this step) www.sauder.com/services 418655 Page 13...
  • Page 14 Fasten the TOP (D) to the ENDS (A and B) and UPRIGHT (C). å Tighten six HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees r f a w i t o l e Unfi nished edge Page 14 418655 www.sauder.com/services...
  • Page 15 NOTE: Perforations have been provided for access å through the BACK. Carefully cut out the holes needed. These holes must line up over the UPRIGHT (C) NAIL and FIXED SHELVES (F). (45 used in this step) www.sauder.com/services 418655 Page 15...
  • Page 16 NOTE: Line up the groove in the FEET with the teeth on å the BRACKET. Push a FOOT CAP (5E) into the grooves of the SUPPORT å FEET (M). BLACK 9/16" LARGE HEAD SCREW (3 used in this step) Page 16 418655 www.sauder.com/services...
  • Page 17 Fasten the DRAWER BACK (D72) to the DRAWER SIDES (D10 and D11). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S). å NOTE: Be sure the DRAWER BOTTOM (D969) inserts into the groove of the DRAWER BACK (D72). å Repeat this step for the left drawer using the LEFT DRAWER FRONT (L). å www.sauder.com/services 418655 Page 17...
  • Page 18 SIDES (D10 and D11). Use four GOLD 5/16" FLAT HEAD hardware kits available SCREWS (3S) through holes #1 and #3. on sauder.com. NOTE: The DRAWER SLIDES are marked "DRAWER RIGHT" å and "DRAWER LEFT" for easy identifi cation.
  • Page 19 Push eight CAM COVERS (13P) onto the HIDDEN CAMS that fasten the LEGS (I and J) to the ENDS (A and B). å Want options? Customize your item with add-on shelf kits available on sauder.com. 70 lbs. WARNING 25 lbs. Never use this furniture with a TV that is too large or too heavy.
  • Page 20 #3. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. Page 20 418655 www.sauder.com/services...
  • Page 21 élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 GLISSIÈRE DROITE D'ÉLÉMENT ....2 Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 GLISSIÈRE GAUCHE D'ÉLÉMENT ....2 en ce qui concerne cet MONTANT................1 COULISSE DROITE DE TIROIR ......2 élément, faire référence...
  • Page 22 MONTANT (C). Utiliser huit VIS TÊTE PLATE 8 mm DORÉES (3S) à travers les trous nº 1 et nº 3. • Cette unité Sauder est conçue pour les téléviseurs pesant moins REMARQUE : Les GLISSIÈRES D'ÉLÉMENT ont une inscription «...
  • Page 23 REMARQUE : S'assurer de bien enfoncer les CLOUS dans les trous qui sont alignés au-dessus le MONTANT (C) et les TABLETTES FIXES (F). REMARQUE : Des lignes perforées ont été prévues pour accéder facilement à l'ARRIÈRE. Découper avec précaution les trous nécessaires. www.sauder.com/services 418655 Page 23...
  • Page 24 Une fois apposée, ne pas essayer de la retirer. Enfoncer huit COUVERCLES D'EXCENTRIQUE (13P) sur les EXCENTRIQUES ESCAMOTABLES qui attache les PIEDS (I et J) aux EXTRÉMITÉS (A et B). Page 24 418655 www.sauder.com/services...
  • Page 25 10A EXCÉNTRICO DE CORREDERA .......4 et conserver le livret pour future référence. EXTREMO IZQUIERDO ............1 CUBIERTA DE PATA ............1 Pour contacter Sauder PARAL ....................1 SOPORTE DE PATA ............1 en ce qui concerne cet PANEL SUPERIOR ..............1 EXCÉNTRICO ESCONDIDO ......30 élément, faire référence...
  • Page 26 • Verifi que el tamaño y peso del televisor. ¡Compárelo al diagrama de los EXTREMOS. abajo - antes de comenzar el ensamblaje! • Esta unidad Sauder está diseñada para ser usada con PASO 4 televisores cuyo peso sea inferior a 31.75 Kg. Nunca la use para un televisor de mayor peso.
  • Page 27 Deslice las PATAS DE APOYO (M) sobre el SOPORTE DE PATA (6E). NOTA: Alinee la ranura de las PATAS a los dientecillos del SOPORTE. Inserte una CUBIERTA DE PATA (5E) en las ranuras de las PATAS DE APOYO (M). www.sauder.com/services 418655 Page 27...
  • Page 28 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Para limpiar la unidad, humedezca un paño con agua de llave y limpie. Page 28 418655 www.sauder.com/services...
  • Page 29 TOUJOURS décharger les tablettes et les tiroirs, en commençant par les surface supérieures, avant de déplacer le meuble. NE JAMAIS pousser ou tirer un meuble sur de la moquette. Demander à une autre personne de le soulever correctement pour le déplacer et/ou le repositionner. www.sauder.com/services 418655 Page 29...
  • Page 30 SIEMPRE descargue los estantes y cajones, empezando con las superfi cies superiores, antes de moverlo. NUNCA empuje ni tire de los muebles sobre una alfombra. Obtenga que un amigo le ayude a levantarlo correctamente para moverlo y/o reposicionarlo. Page 30 418655 www.sauder.com/services...
  • Page 31 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 32 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
