Summary of Contents for Reef Factory Reef flare Pro Series
- Page 1 ver. 2.0.1 Reef flare Pro User Manual Dear customer, thank you for your purchase. ENGLISH www.reeffactory.com...
-
Page 2: Table Of Contents
IMPORTANT! Please read the entire user manual carefully before setting up and using the device. There may be slight differences in the content between what is presented on the device's screen and the manual's descriptions. Reef Factory 2022 User Manual Reef Flare Pro ©... -
Page 3: Installation Of The Device
Use of Reef Factory mounts To properly mount the lamp, use one of the dedicated mounting systems offered by Reef Factory. Follow the instructions attached to it. You can find it by scanning the QR code next to it or at this link www.reeffactory.com/flaremountingkit. - Page 4 Make sure that the lamp's cooling system can work freely, taking in air from above and distributing it to the sides. The hose or fitting must not block the airflow. Reef Factory 2022 User Manual Reef Flare Pro ©...
-
Page 5: Initial Configuration
“Add an aquarium” in the lower left corner of the screen and provide the necessary information. If you already have your aquarium in the Smart Reef app, proceed to the next step. Reef Factory 2022 User Manual Reef Flare Pro ©... - Page 6 This allows the app to connect devices to Wi-Fi networks more easily. Select from the scrolling list the device you want to add to your Smart Reef account and press “NEXT”. Reef Factory 2022 User Manual Reef Flare Pro ©...
- Page 7 NOTE: Reef Factory devices only support the 2.4 GHz Wi-Fi network band. If your router generates 2.4 GHz and 5 GHz bands, indicate the name of the 2.4 GHz network.
- Page 8 Allow the Smart Reef app, to temporarily connect to set up a Wi-Fi network. Congratulations! The device has been correctly added to your Smart Reef account and will appear in the list of devices within 60 seconds. Reef Factory 2022 User Manual Reef Flare Pro ©...
-
Page 9: Lamp Operating Modes
In addition, you can export your own settings (e.g. in order to transfer them to another person) or import other settings (e.g. from other users). More about them in the chapter “Presets” Reef Factory 2022 User Manual Reef Flare Pro ©... - Page 10 This will allow for more e cient heat dissipation to the environment by the lamp. Reef Factory 2022 User Manual Reef Flare Pro ©...
-
Page 11: Presets
Edit - an option that allows you to change the name of the "preset" Export - an option that allows you to export the current preset Import - option for uploading an external preset Reef Factory 2022 User Manual Reef Flare Pro ©... - Page 12 After that, the following steps will be displayed as in point 2. in Chapter II. "Device operation configuration", i.e.: operating hours of the device selection of corals that are in the aquarium device lighting intensity Reef Factory 2022 User Manual Reef Flare Pro ©...
- Page 13 At the end, an option will be displayed to name the setting that has just been edited Edit After pressing this option, a window will appear in which you can enter a new name . Reef Factory 2022 User Manual Reef Flare Pro ©...
-
Page 14: Additional Features
Thanks to it, you can brighten or dim the lamp faster without having to adjust individual colors. This function does not change the intensity of individual colors and maintains the color balance that you have set. Reef Factory 2022 User Manual Reef Flare Pro ©... - Page 15 - ACCLIMATIZATION - Reef Factory lamps are characterized by a very high intensity of light compared to other products on the market. Turning on the lamp at maximum power, e.g. due to the replacement of an old lamp from another manufacturer, may cause undesirable reactions of animals in your tank.
-
Page 16: Resetting The Device
Enter your current password (default is reeffactory) then press "OK". In the next step, enter a new password and press "OK", then confirm the new password and press "OK". Congratulations! The password has been changed successfully. Reef Factory 2022 User Manual Reef Flare Pro ©... -
Page 17: Device Update
After pressing the "OK" button, the device will automatically update. During the update, do not disconnect the device from the power supply. If the update doesn't complete within 30 minutes, reset your device. Reef Factory 2022 User Manual Reef Flare Pro ©... -
Page 18: Information And Warnings
Reef Factory 2022 User Manual Reef Flare Pro ©... - Page 19 Any changes or modifications not expressly approved by Reef Factory could void the user's authority to operate the RF Module and/or the product that incorporates the RF Module. The user is cautioned to maintain a 20 cm (8 inch) spacing from the product to ensure compliance with FCC regulations.
-
Page 20: Warranty Conditions
X. Warranty conditions Reef Factory Sp. z o. o. does not warrant uninterrupted or error-free operation of this product. The warranty covers only technical hardware problems that occurred within the warranty period and under normal conditions of use. Devices manufactured by Reef Factory are covered by a warranty for the period of: ●... - Page 21 17. The customer delivers the device for repair to the Authorized Service Center at his own expense, while the service, after performing the warranty repair, sends the device back to the customer at his own expense. Reef Factory 2022 User Manual Reef Flare Pro ©...
- Page 22 22. The Guarantor is not liable for direct or indirect damages caused as a result of a defect or failure of the device and for damages arising during the period of repairs or replacement of the device related to the inability to use the device. Reef Factory 2022 User Manual Reef Flare Pro ©...
-
Page 23: Dedicated Power Supply
Use only a damp cloth for wiping. 10. If you wish to dispose of this product, please contact your local, qualified recycler. Do not dispose of the power adapter in the mixed waste. Reef Factory 2022 User Manual Reef Flare Pro ©... - Page 24 Operating frequency: 47Hz - 63Hz Maximum input current 2.0A Output voltage: 24V DO [23.8V - 25.2V] Output current: 1L67A max Input connector type: R7BF 4 PIN R7B and R7BF connector description: Reef Factory 2022 User Manual Reef Flare Pro ©...
-
Page 25: Technical Information
3230 g 4250 g The device is manufactured with different versions of power cables and power sockets, depending on the country in which it will be used. Need our help? - support@reeffactory.com Reef Factory 2022 User Manual Reef Flare Pro ©... -
Page 26: Knowledge Base And Technical Support
Need our help? Check out our knowledge base! Help Center - Jira Service Management Do you have more questions? Use the form in the link above or write us an email - support@reeffactory.com Reef Factory 2022 User Manual Reef Flare Pro ©...
