DANGER
1. Multiple sources power this equipment.
2. Electrical equipment should be serviced by authorized personnel only.
3.
This equipment is not intended to be used as a service disconnect breaker.
4. Upon losing power, this product automatically switches to the power station.
5. This equipment and downstream load can only be de-energized by opening all upstream breakers
and physically unplugging all DELTA Pros.

2. Specifications

General Information
Weight
Dimensions
Mounting Type
Standard Connector
Type of Enclosure
Warranty Description
Maximum # of Circuits Controlled
Rated System Voltage
Max Total Input Current
Short Circuit Rating
Rated Relay Module Current
Rated Max DELTA Pro Input
DELTA Pro Charging Power
Max Connected Battery Energy
Operating Humidity (RH)
Note
The actual usable capacity may vary according to the variable environment and charging/discharging
conversion differences.
18.5 lbs (8.38 kg)
20 × 12.2 × 4.5 in (508 × 311 × 115 mm)
Wall Mount
EcoFlow Infinity Port
Type 1
5 Years
10
120V/240V
160A
10kA
30A, 20A, 15A
7200W Max (2 × 3600W)
6800W Max (2 × 3400W)(Max. charging time <3hrs)
21.6 kWh (6 × 3.6kWh)
5-85%
