- Page 1 AC/DC SMART DISTRIBUTION PANEL User Manual V1.0 EFM100-LD-HV...
- Page 3 EcoFlow is not liable for any loss caused by the user's failure to use the product in compliance with this user manual.
-
Page 4: Table Of Contents
Contents Technical Specifications Safety Instructions Getting Started System Overview Product Overview Product Usage Wiring Chart Product Installation Connect to Power Hub FAQs What's in the Box Care and Maintenance... -
Page 5: Technical Specifications
Technical Specifications Basic Information Net Weight 2.6 kg (5.8 lbs) 35.4 cm x 21cm x 9.8 cm Dimensions (L x W xH) (14" x 8.3" x 3.9") Output Spec Six circuits, maximum current 10 A each circuit AC Output 220-240 V, 50 Hz Six controllable circuits + Six regular circuits, DC Output maximum current 20 A each circuit... -
Page 6: Safety Instructions
8. Do not use wires or other metal objects that may result in a short circuit. 9. Do not use unofficial components or accessories. If components or accessories need to be replaced, purchase them from the EcoFlow official sales channels. 10. Strictly comply with the ambient temperature for use in this user manual when using this product. -
Page 7: Getting Started
Getting Started System Overview DC Appliance AC Appliance 1. EcoFlow Power Hub 6. Shore Power/Grid Power AC/DC Smart Distribution Panel Rigid/Flexible Solar Panel Power Kit Console Foldable / Portable Solar Panel 4. EcoFlow 2kWh/5kWh LFP Battery Vehicle Alternator EcoFlow Smart Generator... -
Page 8: Product Overview
Product Overview 1.Surface Cover 2.Wire Cover 3.AC Output L Terminal 4.AC Output Breaker 5.AC Input Indicator DC Input Indicator (10-20V, white light stays on; 20-30V blue light stays on) 6.DC Output Fuse 7.DC Output Indicator 8.RJ45 CAN Bus Port 9.AC Input L Terminal 10.AC Input N Terminal 14.DC Output Negative Terminal (>20A) 15.DC Output Negative Terminal (<20A) -
Page 9: Product Usage
Product Usage Wiring Chart Gauge (AWG) UL1015 Wire Current (A) THHN Wire Current (A) Product Installation Flush Installation Guide 1. Select installation position, position the framing template and find level with a leveling instrument. Draw cutting lines along the template, and use sawing tools to cut a 325 mm x 181 mm rectangular opening for flush intallation. - Page 10 2. Remove the surface cover and the wiring cover plate to expose the inner panel. 3. Remove the retainers near the input inlets and the load outlets. 比例 1.000 4. Connect AC wires from the left side and DC wires from the right side. It is recommended to route wires through corresponding inlets and outlets (e.g.
- Page 11 5. Insert the RJ45 CAN Bus cable to the CAN Bus Port. Ensure connection of the RJ45 CAN Bus cable to activate the six controllable DC circuits and essential load informations. 6. Use a Phillips screwdriver to fasten the AC and DC input wires to corresponding input terminals with screws (AC: M4*10 screws;...
- Page 12 2 . From left to right, the first six DC circuits are controllable circuits, which can be switched on and off from EcoFlow App and Power Kit Console. 3 . It is recommended to select fuses with rated current greater than 1.35 times of corresponding load current.
- Page 13 Wall-Mount Installation Guide 1. Use M3*12 screws to fix the wall-mount lugs on both sides of the Smart Distribution Panel M3*12 2. Use M4*20 self-tapping screws to fix the Smart Distribution Panel on the wall. M4*20 比例 1.000...
- Page 14 Remove the surface cover and the wiring cover plate to expose the inner panel. 4. Remove the retainers near the input inlets and the load outlets. 5. Connect AC wires from the left side and DC wires from the right side. It is recommended to route wires through corresponding inlets and outlets (e.g.
- Page 15 Insert the RJ45 CAN Bus cable to the CAN Bus Port. Ensure connection of the RJ45 CAN Bus cable to activate the six controllable DC circuits and essential load informations. 7. Use a Phillips screwdriver to fasten the AC and DC input wires to corresponding input terminals with screws (AC: M4*10 screws;...
-
Page 16: Connect To Power Hub
2 . From left to right, the first six DC circuits are controllable circuits, which can be switched on and off from EcoFlow App and Power Kit Console. 3 . It is recommended to select fuses with rated current greater than 1.35 times of corresponding load current. -
Page 17: Faqs
FAQs 1. What installation methods does this product support and which tools are required during installation? This product supports two installation methods: inline installation and wall-mount installation. Tools required during installation include: a Phillips screwdriver, crimping tools, sawing tools, and insulation tape. 2. -
Page 18: Care And Maintenance
Care and Maintenance 1. Use or store this product in an environment with a temperature ranging from –25°C (-13°F)to 60°C (140°F) and keep it away from water sources, heat sources, and metal objects. 2. For safety reasons, do not store this product in an environment where the temperature is higher than 60°C (140°F) or lower than 0°C (32°F) for a long time. - Page 19 Ecoflow App...
