  • Page 3 SHP = Automatic Smart Switch? EcoFlow Smart Home Panel(hereinafter referred to as SHP) is a smart load side transfer switch, it can be used as a fast-charging docking station for the DELTA Pro in the grid mode and can switch 10 downstream load circuits between the grid and the backup power station when the power grid goes down.
  • Page 4 Introduction...
  • Page 5 Introduction Wiring Commission FAQs...

  • Page 6: Single Phase

    Scenario 1 Single Phase without AFCI/GFCI Key Points: 1. The current rating of relay modules should match the upstream circuit breaker. 2. All input wires should be routed through the lower conduit into the SHP and output wires through the upper conduit.
  • Page 7 Realistic Scenario1...
  • Page 8 Scenario 2 Single Phase with AFCI/GFCI Key Points: 1. All upstream AFCI/GFCI breakers should be replaced with conventional breakers and you may connect existing AFCI/GFCI breakers or use AFCI/GFCI outlets downstream to SMART HOME PANEL.
  • Page 9 Scenario 2 Single Phase with AFCI/GFCI Key Points: 2. Ecoflow would provide the AFCI/GFCI conjunction box(as the right figure) if AFCI/GFCI breakers are needed on the loads. 3. AFCI/GFCI conjunction box only support Plug-in type breakers,...
  • Page 10 Typo Scenario2...
  • Page 11 Scenario 3 Split Phase without AFCI/GFCI Key Points: 1. The current rating of relay modules should match the upstream circuit breaker. 2. For split phase(240V), the Switching Connector should be removed permanently from the SHP.
  • Page 12 Scenario 3 Split Phase without AFCI/GFCI Key Points: 3. The Channel 1, 3, 5, 7, 9 AC input should be connected with hot wires on the same phase, the Channel 2, 4, 6, 8, 10 AC input should be connected with hot wires on the another phase.
  • Page 13 Scenario 3 Split Phase without AFCI/GFCI Key Points: 5. The total output wattage (3600W for single Pro or 7200W for two Pros) should be greater than the total continuous running wattage of all backed up loads plus the largest start-up wattage of the loads with compressor building in like Pump, Refrigerator, Air Conditioner and Dryer.
  • Page 14 Realistic Scenario3...
  • Page 15 Scenario 4 Split Phase with AFCI/GFCI Key Points: 1. All upstream AFCI/GFCI breakers should be replaced with conventional breakers and you may connect existing AFCI/GFCI breakers or use AFCI/GFCI outlets downstream to SMART HOME PANEL.
  • Page 16 Scenario 4 Split Phase with AFCI/GFCI Key Points: 2. Ecoflow would provide the AFCI/GFCI conjunction box(as the right figure) if AFCI/GFCI breakers are needed on the loads. 3. AFCI/GFCI conjunction box only support Plug-in type breakers.
  • Page 17 Realistic Scenario4...
  • Page 18 Introduction Wiring Commissioning FAQs...
  • Page 19 Commissioning Grid Mode Close upstream breakers of 10 loads and DELT PRO For more details, please refer to the checklist on the appendix...
  • Page 20 Commissioning Back up Mode Switch from grid mode to back up mode For more details, please refer to the checklist on the appendix...
  • Page 21 Commissioning Charging DELTA Charge the battery via manual setting or set up Automation For more details, please refer to the checklist on the appendix...
  • Page 22 Commissioning APP Initial Setup Set up the DELTA Select country, PRO 1 and DELTA region, voltage, 10 circuits setting Set the circuit name, select the The 10 load circuits setup You are all set ! PRO 2 frequency interfaces usage scenario, and the rated overview charge-discharge current...
  • Page 23 Introduction Wiring Commission FAQs...
  • Page 24 FAQs 1. Why there’s no responding when pressing the AC1/AC2 button on the SHP with DELTA PRO plugged in? Firmware incompatibility. Update the firmware for DELTA PRO to the latest version Check the discharge/charge level setting on DELTA PRO setting page, the current SOC of the DELTA PRO must be greater than the discharge level .
  • Page 25 FAQs 3. Is it possible to plug and unplug the relay with power on? a. For safety reasons, it is prohibited to plug and unplug relay modules with power on 4. Error prompts of Relay Module No Insert even the module has been installed a.
  • Page 26 Error code and solution of Smart Home Panel: Wiring diagram of Split phase: EcoFlow Smart Home Panel-APP User Manual: https://drive.google.com/file/d/11TPhQsdt4Zm68mmcuW5quMfa0ShWgYA6/view?usp=sharing Tutorial video of AFCI/GFCI conjunction box installation: https://www.youtube.com/watch?v=f5B3PCMIadc Tutorial video of Smart Home Panel Installation: https://www.youtube.com/watch?v=1WKt8I4vL3k&t=402s Tutorial video of How to use the Smart Home Panel: https://www.youtube.com/watch?v=8zn_Kdhepfo...
