EcoFlow Smart Home Panel Installation Manual page 10

During installation - Wiring
When using split phase, the Channel 1, 3, 5, 7, 9 AC input should be connected with hot
1
wires on the same phase, the Channel 2, 4, 6, 8, 10 AC input should be connected with
hot wires on another phase.
For split phase operation, the Switching Connector should be removed
2
permanently from the SHP.
When using single phase, each load circuit AC input should be connected to the hot
3
wire.
Install the relay modules in the corresponding places and secure by tightening the
4
screws. Failure to do so may cause the relay module to come loose, which will produce
an error and disconnection of the load channel, as well as risk overheating and fire.
During installation - Check wiring
1
With a multimeter in continuity setting, confirm that the hot wire in of each SHP
channel is not shorted to neutral.
2
With a multimeter in continuity setting, confirm that the hot wire in of each SHP
channel is not shorted to ground.
Commissioning
1
Make sure the power stations are enabled and that the stop button is off (raised).
2
Close the upstream breaker of DELTA Pro and energize the DELTA Pro AC Input
channel. The grid indicator (white) will turn on if there is no fault.
3
Turn each branch circuit breaker back on one by one and check the indicator status of
each channel and power indicator. The indicators will stay white.
If you haven't done so already, download the EcoFlow app from Google Play or the
4
App Store and create an EcoFlow account. Open the app on your mobile device, log
into the app and add the Smart Home Panel to your device pool. For first time users,
the app will lead through a commissioning process to setup the SHP.
5
Update the firmware of the Smart Home Panel to the latest version, then check
whether there are any errors reported on the app.
Follow the instructions in the app to conduct device wiring testing. If the device wiring
6
testing fails, correct the wiring following the prompts in the app and re-run the wiring
test.
7
Turn on the DELTA Pro and update the firmware to the latest version.
8
