Vulcan-Hart 2T2036D Specifications

SPECIFICATIONS:
2
Two 24 quart / jacketed tilting steam kettles mounted on a
3
36" wide cabinet base, Vulcan-Hart Model No. 2T2036D. Steam
jacketed kettles mounted on 28" high base cabinet with front full
height doors, slip-off stainless steel side and aluminized rear
panel with 6" adjustable legs with flanged feet for anchoring.
Fully welded hemispheric bottom kettle with type 304 stainless
steel jacket and type 316 stainless steel liner. Jacket tested to
2
50 psi (3.4 kg/cm ). Requires a total of 42 lbs./hr. of 5-50 psi
steam flow, 21 lbs./hr. of 5-50 psi steam flow per kettle. Steam
control valve on right trunnion leg. 12" single temperature deck
mounted faucet.
Exterior dimensions:
Cabinet: 36"w x 33"d x 28"h on 6" adjustable legs. Overall height
1
to the lip of the kettles - 47 / ", to the top of the handle - 56
2
Classified by U L to NSF Std. #4. Meets ASME code.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32384 (10-03)
1
/ ".
4
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MODEL 2T2036D
2
TWO 24 QUART / JACKETED TILTING
3
DIRECT STEAM KETTLES ON CABINET BASE
STANDARD FEATURES
2
Two / jacketed tilting steam kettles, 24 quart capacity each.
3
Steam jacketed kettles mounted on 28" high base cabinet
with front full height doors, slip-off stainless steel side and
aluminized rear panel with 6" adjustable legs with flanged
feet for anchoring.
Fully welded hemispheric bottom kettle with type 304 stainless
steel jacket and type 316 stainless steel liner. Jacket tested
2
to 50 psi (3.4 kg/cm ). Requires 21 lbs./hr. of steam flow at
5-50 psi per kettle.
Steam control valve on right trunnion leg.
12" single temperature deck mounted faucet.
One year limited parts and labor warranty.
OPTIONS
Correction package.
- Cabinet door with hasp (lock by others).
- Security type tamper resistant fasteners.
Tilting kettle strainer (one) (two).
12" dual temperature faucet.
Mount and interconnect kettle with boiler base at factory.
Includes steam supply piping. Shipped on one skid.
Second year extended limited parts and labor warranty.
ACCESSORIES
Stainless steel back panel.
Lift-off cover (one) (two).
Contour measuring strip.
Single perforated stainless steel basket (one) (two).
Ball float trap.
Pressure reducing valve.
C.S.I. Section 11420
