Number of Battery
Clusters Connected
1
2
3
4
5
6
7
8
** Typical application is to connect the clusters in parallel, for series clustering the voltage
limit is 1000 VCD (18 batteries), never exceed this or the system could be damaged. Consult
Clusters connected in Parallel
- Standard
WARNING:
EndurEnergy if in doubt.
27
SW1 Slide DIP Switch
Clusters connected in Series**
