Vulcan-Hart SG44D Specifications

Shown with optional casters
SPECIFICATIONS:
Double section gas convection oven, Vulcan-Hart Model No.
SG44D. Stainless steel front, sides, top, rear enclosure panel and
legs. Independently operated stainless steel doors with double
pane windows. Non-sag insulation applied to the top, rear, sides,
bottom and doors. Porcelain enamel on steel oven interiors
measure 29"w x 22 / "d x 20"h. Two interior oven lights per
1
8
section. Five nickel plated oven racks per section measure 28
" x 21 / ". Eleven position nickel plated rack guides with positive
1
4 4
rack stops. Two 30,000 BTU/hr. burners per section, 120,000
BTU/hr. total input. Electronic spark igniters. Furnished with two
speed / H.P. oven blower motors. Side mounted solid state
1
2
temperature controls adjust from 150° to 500°F. Power Level
controls allows the operator to adjust the heat input from 15,000
BTU/hr. to a maximum input of 60,000 BTU/hr. in each oven
section. 60 minute timers with audible alarm. Oven cool switch for
rapid cool down. 120 volt, 60 Hz, 1 ph power supply required. 6'
cord and plug. 9 amps per section, 18 amps total draw.
Exterior dimensions: 40"w x 42
measurement includes door handles.
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32263 (03-08)
/ "d x 72"h on 8" legs. Depth
1
4
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
MODEL SG44D
DOUBLE DECK GAS CONVECTION OVEN
STANDARD FEATURES
■ Stainless steel front, sides, top, rear enclosure panel and legs.
■ Independently operated stainless steel doors with double
pane windows.
■ Two 30,000 BTU/hr. burners per section, 120,000 BTU/hr. total
input.
■ Electronic spark igniters.
■
/ H.P. two speed oven blower motors. 120/60/1 with 6' cord
1
2
and plug. 9 amps per section, 18 amps total draw.
■ Solid state temperature controls adjust from 150° to 500°F.
■ Energy saving "Power Level" controls allow the operator to
adjust the heat input to the size of the load.
■ 60 minute timers with audible alarm.
■ Oven cool switch for rapid cool down.
■ Porcelain enamel on steel oven interiors.
■ Five nickel plated oven racks with eleven rack positions per
section.
■ / " rear gas connection with combination gas pressure
3
4
regulator and safety solenoid system.
■ One year limited parts and labor warranty.
OPTIONS
Five hour timer in place of 60 minute timer.
Casters.
Second year extended limited parts and labor warranty
contract.
ACCESSORIES
Extra oven rack(s).
Rack hanger(s).
/
1
Stainless steel drip pans.
Flexible gas hose with quick disconnect and restraining
device. Consult price book for available sizes.
Down draft flue diverter for direct vent connection.
Item # __________________________
C.S.I. Section 11420
