Technical Support and E-Warranty Certificate www.vevor.com/support
QUICK SUPPORT ROD
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VEVOR XF-E004A-2
Summary of Contents for VEVOR XF-E004A-2
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support QUICK SUPPORT ROD USER MANUAL We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and doses not necessarily mean to cover all categories of tools offered by us.
- Page 2 CustomerService@vevor.com This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
-
Page 3: General Safety Rules
GENERAL SAFETY RULES WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in serious injury. Various dangers may occur if the hand lever grease gun is improperly handled during installation, commissioning and daily operation. Risk of injury and damage to material property because of improper handling. - Page 4 MODEL AND PARAMETERS Model XF-E004A-2 XF-E004A-4 Maximum Load Capacity 30kg 30kg Adjustable Range 115 ~ 290cm 115 ~ 290cm Support Feet 128*80mm 128*80mm Material Steel Steel Color Blue Blue Packing quantity 2pcs 4pcs - 3 -...
-
Page 5: Structure Diagram
STRUCTURE DIAGRAM 1. Adjusting leverⅠ 2. Release Button 3. Adjusting lever Ⅱ 4. Micro Adjustment Handle 5. Knob 6. Support Rod 7. Non-slip Pad - 4 -... - Page 6 COMPONENTS Model XF-E004A-2 XF-E004A-4 Parts Quick Support Rod Support Feet Knob(M6) Storage Bag User Manual - 5 -...
- Page 7 OPERATING INSTRUCTIONS Operation Preparation: 1. Please prepare gloves to avoid being scratched by sharp parts that may occur during installation. 2. Please open all the boxes to check that the accessories are complete and in good condition. Operation: Step1： Buckle the support feet into both ends of the support rod, as shown - 6 -...
- Page 8 Step2：Multiple support rods can be selected according to the working scenario, as shown in the following figure. Support rod adjustment operation: 1) Loosen the knob to extend or shorten the rod and then tighten the knob. - 7 -...
- Page 9 2) Press the handle to fine-tune the rod until it is fixed. 3) End of use and lift the release button to put away the rod. - 8 -...
- Page 10 Step3：The support rod can also be used at any Angle, as shown below Fully rotating head - 9 -...
-
Page 11: Maintenance
After use, please clean up before storage to avoid rusting of bolts affecting use. Check the knob regularly for damage. VEVOR STORE INC 9448 RINCHMOND PL #E RANCHO CUCAMONGA, California, 91730 United States of America Made in China - 10 -... - Page 12 TechnicalSupport and E-Warranty Certificate www.vevor.com/support...
