1 input to 6 outputs analog audio distributor with transformer balanced inputs and outputs and independent gain adjustments for each one of the outputs
BALANCED INPUTS AND OUTPUTS AND INDEPENDENT GAIN ADJUSTMENTS FOR EACH ONE OF THE OUTPUTS Version 1.0 1. DESCRIPTION ........................5 1.1. The AAD3001C01 ........................... 5 1.2. Features ............................. 6 1.3. Block diagram ..........................7 2. SPECIFICATIONS ......................... 9 3. INSTALLATION ........................11 3.1.
-4 to +12 dB. Each output also has its own amplifier circuitry, so that a short circuit at one output will not affect the others. The AAD3001C01 is a TL3000 terminal line module and can be housed in a three rack unit (3 RU) UR3000 mounting frame or a 1 RU UR3100 mounting frame.
• Low impedance outputs can drive loads of up to 600 Ω at maximum signal levels. • One UR3000 mounting frame can house up to 12 AAD3001C01 modules. If power supply redundancy is required and FA3000 or FA3001 modules are used then only 10 modules can be housed in the mounting frame.
Albalá Ingenieros | Manual AAD3001C01 2. SPECIFICATIONS Analog audio signal input Connector Plug-in terminal, 3.81 mm pitch Impedance >6 kΩ Type Transformer balanced Number of inputs Common mode rejection ratio (CMRR): at 50 Hz >75 dB at 20 kHz >60 dB Maximum common mode range ±50 V...
ELECTROSTATIC DISCHARGE. Always use antistatic bags clearly identified with a high degree of shielding for storage and transportation. The AAD3001C01 module is composed of two parts: one AAD3001P01 main board and one XAD3001P02 rear board. Both parts must be installed in a UR3000 or UR3100 mounting frame following the instructions in the corresponding section of this chapter.
4 - Attach the rear board to the mounting frame with two M3 metric screws and tighten. 5 - Insert the AAD3001P01 board (main board of the AAD3001C01 module) into the front of the mounting frame. The edges of the card slide into two plastic guides inside the mounting frame.
Page 13
Albalá Ingenieros | Manual AAD3001C01 Details for installation of the module in 3 RU mounting frames Details for installation of the module in 1 RU mounting frames...
The following figure shows the AAD3001C01 module rear board connector layout. Rear view of the AAD3001C01 The AAD3001C01 module provides one analog audio input (IN-A) and six outputs (OUT1, OUT2, OUT3, OUT4, OUT5, OUT6). The rear interconnection board is not designed to withstand mechanical stress. The wiring must be fastened properly to the frame where the mounting frame is housed to prevent the rear board from supporting the weight of the cables.
Page 15
Albalá Ingenieros | Manual AAD3001C01 The analog audio outputs are balanced, low impedance and use 3.81 mm pitch terminal block connectors. For analog audio connections two-wire shielded cable is preferred. The GND terminal allows connection of the cable shield.
Albalá Ingenieros | Manual AAD3001C01 4. OPERATION This section describes the significance of the front panel indicators of the AAD3001C01 module and their remote control and monitoring ability. 4.1. Front panel description The appearance of the front panel and the elements it contains are shown in the following illustration.
Albalá Ingenieros | Manual AAD3001C01 The gain adjustment range for each trimmer is -4 to +12 dB. 4.2. Module remote control and supervision The AAD3001C01 CANNOT be remotely controlled or supervised.
