- Page 1 SPL3005C01 DUAL PASSIVE 1:5 POWER SPLITTER FOR THE DISTRIBUTION FROM 1 INPUT TO 5 OUTPUTS OF 10 MHz REFERENCE SIGNAL Version 1.0 Albalá Ingenieros, S.A. 16 January 2017 - © Albalá Ingenieros S.A. - All rights reserved Medea, 4 - 28037 Madrid - Spain...
- Page 2 SPL3005C01...
-
Page 3: Table Of Contents
DUAL PASSIVE 1:5 POWER SPLITTER FOR THE DISTRIBUTION FROM 1 INPUT TO 5 OUTPUTS OF 10 MHz REFERENCE SIGNAL Version 1.0 1. DESCRIPTION ........................5 1.1. The SPL3005C01 ..........................5 1.2. Features ............................. 5 1.3. Block diagram ..........................6 2. SPECIFICATIONS ......................... 7 3. - Page 4 SPL3005C01...
-
Page 5: Description
1. DESCRIPTION 1.1. The SPL3005C01 The SPL3005C01 is a dual, one input to five output splitter that divides a 10 MHz input signal among five outputs. It has been designed for distribution of 10 MHz reference signals used by the GPS3000 or GPS3002 modules from Albalá Ingenieros. This device is completely passive, has a characteristic impedance of 50 Ω... -
Page 6: Block Diagram
Albalá Ingenieros | Manual SPL3005C01 1.3. Block diagram... -
Page 7: Specifications
Albalá Ingenieros | Manual SPL3005C01 2. SPECIFICATIONS Passive splitter Connector Impedance 50 Ω Number of outputs Input return loss >28 dB at 10 MHz Output return loss >28 dB at 10 MHz Insertion loss <7.5 dB a 10 MHz, all outputs loaded Insertion loss >6.5 dB a 10 MHz, only output under... - Page 8 Albalá Ingenieros | Manual SPL3005C01 SPL3005C01...
-
Page 9: Installation
ELECTROSTATIC DISCHARGE. Always use antistatic bags clearly identified with a high degree of shielding for storage and transportation. The SPL3005C01 is comprised of a sole PCB: the rear board, SPL3005P01. This board should be installed in a UR3000 or UR3100 mounting frame following the instructions found in the the corresponding section of that portion of this manual. -
Page 10: Environmental Considerations
3.5. Installing the module in the mounting frame The steps needed to install the SPL3005C01 module with the rear board in the mounting frame are: 1 - Disconnect all power cords from the power supplies of the mounting frame. - Page 11 Albalá Ingenieros | Manual SPL3005C01 Details for installation of the module in 1 RU mounting frames 4 - Attach the rear board to the mounting frame with two M3 metric screws and tighten. After these steps, the module is ready to be connected to other equipment.
-
Page 12: Interconnection
The following figure shows the SPL3005C01 module rear board connector layout. Rear view of the SPL3005C01 The SPL3005C01 module provides two inputs (IN-A and IN-B) and five outputs per section (OUT1-A to OUT5-A and OUT1-B to OUT5-B) for 10 MHz reference signals. -
Page 13: Operation
Albalá Ingenieros | Manual SPL3005C01 4. OPERATION 4.1. Module remote control and supervision The SPL3005C01 CANNOT be remotely controlled or supervised. - Page 14 Albalá Ingenieros | Manual SPL3005C01 SPL3005C01...
-
Page 15: Glossary
Albalá Ingenieros | Manual SPL3005C01 5. GLOSSARY... - Page 16 Albalá Ingenieros | Manual SPL3005C01 SPL3005C01...
-
Page 17: Regulations
Albalá Ingenieros | Manual SPL3005C01 6. REGULATIONS... - Page 18 Albalá Ingenieros | Manual SPL3005C01 SPL3005C01...
-
Page 19: Versions
Albalá Ingenieros | Manual SPL3005C01 7. VERSIONS Ver. Date Description 13-06-2013 Preliminary Version 16-01-2017 First version... - Page 20 Albalá Ingenieros, S.A. Medea, 4 - 28037 Madrid Spain +34 913274453 www.albalaing.com info@albalaing.com...
