- Page 1 EOP0001C01 DUAL 3G/HD/SD-SDI OPTICAL TO/FROM ELECTRICAL PORT Version 1.0 Albalá Ingenieros, S.A. 23 August 2016 - © Albalá Ingenieros S.A. - All rights reserved Medea, 4 - 28037 Madrid - Spain...
- Page 2 EOP0001C01...
- Page 3 When the module incorporates any optional SFP optic fiber transmitter provided by Albalá Ingenieros, the EOP0001C01 is a CLASS 1 LASER product as per the IEC 60825-1 standard. Please read the safety instructions included in this manual carefully before using this module.
- Page 4 EOP0001C01...
-
Page 5: Table Of Contents
EOP0001C01 DUAL 3G/HD/SD-SDI OPTICAL TO/FROM ELECTRICAL PORT Version 1.0 1. DESCRIPTION ........................7 1.1. The EOP0001C01 ..........................7 1.2. Features ............................. 8 1.3. Block diagram ..........................9 2. SPECIFICATIONS ....................... 11 3. INSTALLATION ........................13 3.1. Initial inspection .......................... 13 3.2. - Page 6 EOP0001C01...
-
Page 7: Description
The EOP0001C01 operates with 270 Mbit/s (SD-SDI and DVB-ASI), 1.5 Gbit/s (HD-SDI) and 3 Gbit/s (3G-SDI) signals. The EOP0001C01 provides one cage for an optical SFP module that can function as a dual transmitter or dual receiver. Two BNC connectors are also provided that can function either as inputs or outputs, depending upon how the unit will be used. -
Page 8: Features
• The two BNC connectors function as inputs or outputs depending upon the SFP module installed in the corresponding cage. • The EOP0001C01 can function as: - An optical-to-electrical converter for two signals. - An electrical-to-optical converter for two signals. -
Page 9: Block Diagram
Albalá Ingenieros | Manual EOP0001C01 1.3. Block diagram... - Page 10 Albalá Ingenieros | Manual EOP0001C01 EOP0001C01...
-
Page 11: Specifications
Albalá Ingenieros | Manual EOP0001C01 2. SPECIFICATIONS SD/HD/3G-SDI digital video signal input Connector Impedance 75 Ω ± 1 % Return loss: Up to 3 GHz >10 dB Up to 1.5 GHz >15 dB Number of inputs Equalizable cable length: Belden 1694A, SD 270 Mbit/s >350 m... - Page 12 Albalá Ingenieros | Manual EOP0001C01 Power supply input Connector 2.5 mm locking DC power jack Voltage range 7 .. 15 V Rated current 380 mA General Operating temperature range 0 .. 50 °C Dimensions 134 mm x 35 mm x 112 mm...
-
Page 13: Installation
The EOP0001C01 is a desktop unit and does not require installation in a rack or similar housing. However, it has threaded fasteners for M4 screws at its base for attachment to a panel or other surfaces if necessary. -
Page 14: Environmental Considerations
The power supply's negative output is connected to the metal case. • The EOP0001C01 is designed to be operated indoors and should not be used outside. It should also not be used in explosive, corrosive or radioactive environments or in applications that could endanger the lives of people or animals. -
Page 15: Attachment
EOP0001C01 3.4. Attachment The EOP0001C01 has four rubber feet for desktop operation. It also has threaded fasteners to hold it in any position on any surface. These fasteners accept M4x0.7 screws and penetrate 3 mm into the device. Installation must be away from heat sources and there should be no obstacles to airflow. -
Page 16: Interconnection
The equipment is supplied with a suitable wall power supply. This power supply can provide power to a single EOP0001C01. It is possible to connect several devices to the same power supply as long as it is able to supply the necessary current. Read the following information carefully before connecting the EOP0001C01 to a power supply other than the one delivered with the equipment. -
Page 17: Optical Sdi Video Connections
Albalá Ingenieros | Manual EOP0001C01 The use of analog video coaxial cables RG-59 type or similar is not recommended for digital video except for very short distances. 3.6.3. Optical SDI video connections The inputs or outputs of the SFP module are labeled on the overlay with arrows over the SFP MODULE tag. - Page 18 Albalá Ingenieros | Manual EOP0001C01 EOP0001C01...
-
Page 19: Operation
The appearance of the upper panel and the elements it contains are shown in the following illustration. Upper panel of the EOP0001C01 The upper panel of the EOP0001C01 displays the signal path for the unit. It includes six indicator LEDs. -
Page 20: Functional Description
The EOP0001C01 is a dual 3G/HD/SD-SDI and DVB-ASI digital video signal converter for optical-to-electrical format conversion and vice versa. The EOP0001C01 provides one cage for an optical SFP module that can function as a dual transmitter or dual receiver. Two BNC connectors are also provided that can function either as inputs or outputs, depending upon how the unit will be used. -
Page 21: Glossary
Albalá Ingenieros | Manual EOP0001C01 5. GLOSSARY 3G-SDI 3G - Serial Digital Interface for high definition digital television capable of transmitting bitrates of 2.970 Gbit/s and 2.967 Gbit/s. 3G/HD/SD-SDI 3G/HD/SD - Serial Digital Interface for high definition or standard definition digital television capable of transmitting bitrates of 2.970 Gbit/s, 2.967 Gbit/s, 1.485 Gbit/s,... - Page 22 Albalá Ingenieros | Manual EOP0001C01 EOP0001C01...
-
Page 23: Regulations
Albalá Ingenieros | Manual EOP0001C01 6. REGULATIONS EN 60950-1 (2003) Information Technology Equipment - Safety- Part 1: General Requirements See also: EN 60950-1 A11, EN 60950-1 Corrigendum IEC 60825-1 (2008) Safety of laser products, Part 1: Equipment classification, requirements and user's guide. - Page 24 Albalá Ingenieros | Manual EOP0001C01 EOP0001C01...
-
Page 25: Versions
Albalá Ingenieros | Manual EOP0001C01 7. VERSIONS Ver. Date Description 12-08-2016 Preliminary Version 23-08-2016 First version... - Page 26 Albalá Ingenieros, S.A. Medea, 4 - 28037 Madrid Spain +34 913274453 www.albalaing.com info@albalaing.com...
