THORLABS HNL100R User Manual page 20

Red HeNe Laser Systems
Item #
Wavelength
Min Output Power (TEM
Min Polarization Ratio
Beam Diameter (TEM
Beam Divergence (TEM
Mode Purity (TEM
Longitudinal Mode Spacing
Max Noise (RMS) (30 Hz to 10 MHz)
Max Drift with Respect to Mean Power,
Over 8 hr
Max Mode Sweeping Contribution
Beam Pointing Stability (25 C)
From Cold Start
After 15 min Warm-up
Operating Voltage (±100 V)
Operating Current (±0.1 mA)
Max Starting Voltage
Physical/Mechanical Characteristics
Max Warm-up Time (95% power)
Expected Operating Lifetime
Storage Lifetime
Static Alignment
Laser Head Weight
Environmental
Temperature, Operating
Temperature, Non-operating
Altitude, Operating
Altitude, Non-Operating
Relative Humidity (non-condensing)
Shock
Safety
CDRH/IEC 60825-1 Class
TEM version only.
3
00
Rev C, March 29, 2017
, 633 nm)
00
, 1/e  points + 3%)
00
, + 3%)
00
)
00
3
HNL150L
632.8 nm
5.0 mW
500:1
0.70 mm
1.15 mrad
>95%
257 MHz
0.5%
±2.0%
1%
<0.20 mrad
<0.03 mrad
3800 VDC
6.5 mA
10 kVDC
HNL150L(R)
20 min
>40,000 hr
Indefinite (Hard-Sealed)
Center to Outer Cylinder within ±0.01".
Parallel to outer Cylinder within ±1 mR
2.6 lbs (1.2 kg)
HNL150L(R)
-40 to 70 °C
-40 to 150 °C
0 to 10,000 ft
0 to 70,000 ft
0 to 100%
25 g for 11 ms, 100 g for 1 ms
HNL150R(L)
IIIb/3B
Chapter 7: Specifications
HNL150R
Random
Page 17
