Chapter 4
4.1.

Unpacking

Inspect the packing container for any damage that may have occurred during shipment. Contact your local
Thorlabs customer service office for assistance. Packing materials are specifically designed to protect against
shipping damage. Please keep this container and reuse it if your system needs to be returned to Thorlabs for
service or evaluation.
Carefully remove the laser system from the packing container. Inspect for damage, including dents and scratches.
There should not be anything rattling around inside the laser head. Rarely, during shipping, the glass tube may
break.
Power Supply Module

4.1.1. Shipping Inventory

The equipment included in this shipment should match the packing slip attached to the box. Verify that the correct
product was shipped to you by identifying the item number on the box. If the shipment is incomplete, or if an
incorrect item was shipped to you, please notify Thorlabs immediately.
This package should contain:

Cylindrical Laser Head

Power Supply

2 Keys for Power Supply

Remote Interlock for Power Supply

User Guide and Quick Start Guide
Page 10
Setup
Figure 3
Laser Head
Laser head with manual shutter and
power cord with Alden connector
Laser System
Chapter 4: Setup
Accessories
From left to right: power switch
keys, interlock connector
22172-D02
