Instruction Manual (C)
SCU-1601 Control Unit
for STP-XA2703BV155 / STP-XA3203BV155
Description
SCU-1601 Control Unit
STP pump consists of the three-volumed Instruction Manuals.
Instruction Manual (A):
Instruction Manual (B):
Instruction Manual (C):
(This Instruction Manual)
Instruction Manual (D):
Voltage
200 - 240 Va.c.
STP pump generic Instruction Manual
STP pump specific information
STP control unit Instruction Manual
Supplied with STP control unit
STC-U e-TMS unit for Turbomolecular
Pump
Copyright 2023 Edwards Japan Limited. All rights reserved. Printed in Japan.
MT-96E-1B1-0
2022.06
