C331-55-885
Issue G / Ausgabe G / Edition G
Instruction Manual | Betriebsanleitung | Mode d'emploi
Speedivalves
„Speedivalves"-Ventile
Speedivalves

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Speedivalve SP5 and is the answer not in the manual?

Questions and answers

Related Manuals for Edwards Speedivalve SP5

Summary of Contents for Edwards Speedivalve SP5

  • Page 1 C331-55-885 Issue G / Ausgabe G / Edition G Instruction Manual | Betriebsanleitung | Mode d’emploi Speedivalves „Speedivalves“-Ventile Speedivalves...
  • Page 2 This page has been intentionally left blank. Leerseite. Cette page a été laissée blanche intentionnellement.

  • Page 3: Table Of Contents

    Change the diaphragm ......19 Membran auswechseln ......19 Changement de la membrane ....19 © Edwards Limited 2007. All rights reserved. Page i / Seite i / Page i Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 4 Ventils (mm) ........9 Abmessungen der SP10K-, SP16K-, SP25K-, SP25T- und SP40T-„Speedivalve“- Ventile (mm) ......... 10 Page ii / Seite ii / Page ii © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 5: Introduction

    SI d’unités de mesure. Die in dieser Betriebsanleitung verwendeten Maßeinheiten entsprechen dem Internationalen Einheitensystem (SI). © Edwards Limited 2007. All rights reserved. Page 1 / Seite 1 / Page 1 Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 6: General Description

    SP16K et SP25K ont un repère visuel qui indique que la Abbildungen dargestellt. Die SP10K-, SP16K- und vanne est ouverte. SP25K-„Speedivalve“-Ventile haben eine Stellungsanzeige. Page 2 / Seite 2 / Page 2 © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 7: Connections

    1.3.3 SP40K Das SP40K-Ventil ist mit Kleinflanschen ausgestattet und eignet sich nur zur Montage in Leitungen. © Edwards Limited 2007. All rights reserved. Page 3 / Seite 3 / Page 3 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 8 C331-05-885 Issue G / Ausgabe G / Edition G Figure 1 - Component parts of the SP5 Speedivalve: Abbildung 1 - Komponenten des SP5-„Speedivalve“- Figure 1 - Composants du modèle Speedivalve SP5 - Ventils: Legende légende 1. Control knob 1. Regelknopf 1.
  • Page 9 Abbildung 1 - Komponenten des SP5-„Speedivalve“- Figure 1 - Composants du modèle Speedivalve SP5 Ventils © Edwards Limited 2007. All rights reserved. Page 5 / Seite 5 / Page 5 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 10 This page has been intentionally left blank. Leerseite. Cette page a été laissée blanche intentionnellement. Page 6 / Seite 6 / Page 6 © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 11: Technical Data

    Mit SC5-Kupplung und O-Ring † Mit Co-Seal Avec raccord SC5 et joint torique † Avec joint Co-seal © Edwards Limited 2007. All rights reserved. Page 7 / Seite 7 / Page 7 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 12 3. Panel fixing holes 3. Befestigungslöcher für die Bedientafel-Montage 3. Trous de fixation du tableau Page 8 / Seite 8 / Page 8 © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 13 Abbildung 3 - Abmessungen des SP40K- Figure 3 - Dimensions de la SP40K Speedivalve (mm) „Speedivalve“-Ventils (mm) Speedivalve SP40K (mm) © Edwards Limited 2007. All rights reserved. Page 9 / Seite 9 / Page 9 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 14 Befestigungslöcher für die Bedientafel-Montage (4 Stück)/Quatre trous de fixation du tableau 1. SP10K & SP16K 2. SP25K Page 10 / Seite 10 / Page 10 © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 15: Item Numbers

    C332-05-000 Fluoroelastomer/Fluorelastomer/Fluoroélastomère C332-55-000 SP25K Speedivalve Nitrile/Nitril/Néoprène C333-05-000 Fluoroelastomer/Fluorelastomer/Fluoroélastomère C333-55-000 SP40K Speedivalve Nitrile/Nitril/Néoprène C334-05-000 Fluoroelastomer/Fluorelastomer/Fluoroélastomère C334-55-000 © Edwards Limited 2007. All rights reserved. Page 11 / Seite 11 / Page 11 Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 16: Female Threaded Port Speedivalves

    1” NPT Nitrile/Nitril/Néoprène C33405400 SP40T Speedivalve 1” BSP Fluoroelastomer/Fluorelastomer/Fluoroelastomère C33455300 SP40T Speedivalve 1” NPT Fluoroelastomer/Fluorelastomer/Fluoroelastomère C33455400 Page 12 / Seite 12 / Page 12 © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 17: Installation

    Einsatz bestimmt ist, das Ventil wieder verpacken. Das adéquates, comme indiqué à la Section Ventil bei entsprechend geeigneten Bedingungen lagern, siehe Abschnitt © Edwards Limited 2007. All rights reserved. Page 13 / Seite 13 / Page 13 Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 18: Install The Speedivalve

    5. Die schwarzen Kupplungsmuttern (4) festziehen. 5. Resserrez les écrous noirs du raccord (4). Page 14 / Seite 14 / Page 14 © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 19: Sp5 Vacuum Connections

    Co-seal (qui ne sont pas fournis). und O-Ringe oder Co-Seals (nicht im Lieferumfang enthalten). © Edwards Limited 2007. All rights reserved. Page 15 / Seite 15 / Page 15 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 20 This page has been intentionally left blank. Leerseite. Cette page a été laissée blanche intentionnellement. Page 16 / Seite 16 / Page 16 © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 21: Operation

    Tournez ce bouton de commande dans le sens des aiguilles d’une montre pour fermer votre Speedivalve. © Edwards Limited 2007. All rights reserved. Page 17 / Seite 17 / Page 17 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 22 This page has been intentionally left blank. Leerseite. Cette page a été laissée blanche intentionnellement. Page 18 / Seite 18 / Page 18 © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 23: Maintenance

    8. Remettez en place le capot sur le corps de la vanne et immobilisez-le bien à l’aide des quatre vis de fixation. © Edwards Limited 2007. All rights reserved. Page 19 / Seite 19 / Page 19 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 24 This page has been intentionally left blank. Leerseite. Cette page a été laissée blanche intentionnellement. Page 20 / Seite 20 / Page 20 © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 25: Storage And Disposal

    Umweltvorschriften sicher entsorgen. matière de sécurité et de protection de l’environnement. © Edwards Limited 2007. All rights reserved. Page 21 / Seite 21 / Page 21 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 26 This page has been intentionally left blank. Leerseite. Cette page a été laissée blanche intentionnellement. Page 22 / Seite 22 / Page 22 © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 27: Spares And Accessories

    (le cas échéant) le numéro de code et la désignation de la pièce © Edwards Limited 2007. All rights reserved. Page 23 / Seite 23 / Page 23 Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 28: Spares

    Beschreibung Bestellnummer Réducteur SC5-NW10 C105-11-435 SC5 to NW10 reducer C105-11-435 Reduzierstück SC5 auf NW10 C105-11-435 Page 24 / Seite 24 / Page 24 © Edwards Limited 2007. All rights reserved. Edwards and the Edwards logo are trademarks of Edwards Limited.
